1. Semi-Supervised Learning D. Zhou, O Bousquet, T. Navin Lan, J. Weston, B. Schokopf Presents: Tal Babaioff

2. Semi Supervised Learning • Use small number of labeled data to label large amount of cheap unlabeled data. • Basic idea: similar examples should be given the same classification. • Typical example : web page classification: unlimited amount of cheap unlabeled data, while labeling is expensive. Semi-Supervised Learning

3. The Cluster Assumption • The basic assumption of most Semi-Supervised learning algorithms: Two points that are connected by a path going through high density regions should have the same label. Semi-Supervised Learning

4. Example Semi-Supervised Learning

5. Basic Approaches • Using a weighted graph with weights representing point similarity: • K nearest neighbors – the most naive approach. • Random walk on graph: a particle start from unlabeled node i and move to node j with probability Pij, The walk continues until the particle hits a labeled node. The classification of node i is based on the label with maximum probability to hit. Semi-Supervised Learning

6. Basic Approaches • An electrical network: lets connect all the points labeled 1 to a positive voltage source, and all points labeled 0 to a negative one. The graph edges are resistors with conductance W. Each unlabeled point classification will be determined from the amount of voltage in the complete electricnetwork. Semi-Supervised Learning

7. Other Approaches • Harmonic energy minimization: use a Gaussian field over a continuous state space, with weights given as a similarity function between points. Semi-Supervised Learning

8. The Consistency Assumption • Points in the same local high density region are more similar to each other (and thus likely to have the same label) then to points outside this region (local consistency). • Points on the same global structure (a cluster or a manifold) are more similar to each other than to points outside of this structure (global consistency). Semi-Supervised Learning

9. Consistency Assumption Example Semi-Supervised Learning

10. Consistency Assumption Example Semi-Supervised Learning

11. Formal Representation • X = {x1..xl,xl+1..xn}  Rm • Label set L = {1,..c} • The first l points have labeled yi {1,..c} • For points with i>l yi is unknown. • The error is checked on the unlabeled examples only. Semi-Supervised Learning

12. Basic Ideas For The Algorithm • Define a similarity function that changes slowly locally in high density regions and changes globally on the manifold which the data points lie. • Define an activation network represented as a graph with weights determined by the similarity of each two points. Semi-Supervised Learning

13. Basic Ideas For The Algorithm • Use the labeled points as sources to pump the different classes labels via the graph, and use the new labeled points as additional source until a stable stage has been reached. • The label of each unlabeled point is set to be the class of which it has received most information during the iteration process. Semi-Supervised Learning

14. Algorithm : Data Structure • Given a set of points: X = {x1..xl,xl+1..xn} • The first l points have labeled Yi {1,..c} the rest are unlabeled. • The classification will be presented on an [n x c] non negative matrix F. The classification of point xi will be yi = argmax j<c Fij. Let YF be a [n x c] matrix with elements Yij =1 if point i has a label yi = j or 0 otherwise. Semi-Supervised Learning

15. The Consistency Algorithm • Form the affinity matrix W defined by Wij= exp(-||xi-xj||2 /22) if i j and Wii= 0. • Compute the matrix S defined by S = D-½ W D- ½ D is a diagonal matrix with its (i,i) element equal to the sum of the i-th row of W. The eigenvalues of S represents the spectral clusters of the data. Semi-Supervised Learning

16. The Consistency Algorithm • Iterate F(t+1) = SF(t) + (1-)Y until convergence.(0, 1). • Let F* denote the limit of the sequence {F(t)}. Label the unlabeled point xi by yi = argmax j≤c F*ij Semi-Supervised Learning

17. Consistency Algorithm – Convergence • Show the algorithm convergence to: F* = (1-)(I -S)-1Y • Without loss of generality, let F(0) = Y. • F(t+1) = SF(t) + (1-)Y • And therefore F(t) = (S)tY+ (1-)t-1i=0(S)iY. Semi-Supervised Learning

18. Consistency Algorithm – Convergence Show the algorithm convergence to: F* = (1-)(I -S)-1Y F(t) = (S)tY+ (1-)t-1i=0(S)iY. Since: 0< <1 and the eigenvalues of S is in [-1, 1]: lim t→ (S)t-1 = 0 lim t→ i=0t-1 (S)i = (I -S)-1 Hence: F* = lim t→ F(t) = (1-)(I -S)-1Y Semi-Supervised Learning

19. Regularization Framework • Define a cost function for the iteration stage: • The classifiying function is • smoothness constraint: a good classifying function should not change too much between nearby points. Semi-Supervised Learning

20. Regularization Framework • fitting constraint: a good classifying function should not change too much from the initial label assignment. •  >0 : Trade off between constraints Semi-Supervised Learning

21. Regularization Framework Semi-Supervised Learning

22. Results Two Moon Toy Problem Semi-Supervised Learning

23. Results Two Moon Toy Problem Semi-Supervised Learning

24. Results Two Moon Toy Problem Semi-Supervised Learning

25. Results Two Moon Toy Problem Semi-Supervised Learning

26. Results Two Moon Toy Problem Semi-Supervised Learning

27. Results Two Moon Toy Problem Semi-Supervised Learning

28. Results: Digit Recognition • Run the algorithm over USPS database with digits 1, 2, 3, 4. • Class sizes are 1269, 929, 824, 852 (Total 3874). • The test errors are averaged over 30 trials. • The samples were chosen so that they contain at least one labeled point of each class. Semi-Supervised Learning

29. Results: Digit Recognition Semi-Supervised Learning

30. Results: Digit Recognition Semi-Supervised Learning

31. Results: Digit Recognition Resultsaveraged over 100 trials Semi-Supervised Learning

32. Results: Text classification • Use Mac & Windows subsets from 20 newsgroups data set. • There are 961 and 985 examples in the two classes with 7511 dimensions. Semi-Supervised Learning

33. Results: Text Classification Semi-Supervised Learning

34. Results: Text Classification 2 • Use the topic “rec” which contains autos, motorcycles, baseball and hockey subsets. • Preprocessing: • Remove ending from all words (like ing, ed,…) • Don’t pass words on the SMART list (the, of …) • Ignore the headers • Use only words that appear in 5 or more articles. • Data base size: 3970 document vectors in a 8014-dimensional space Semi-Supervised Learning

35. Results: Text Classification 2 Semi-Supervised Learning

36. References: • Learning with Local and Global Consistency: Dengyong Zhou, Olivier Bousquet, Thomas Navin Lal, Jason Weston, Bernhard Scholkopf • http://www.kyb.mpg.de/publications/pdfs/pdf2333.pdf • Semi-Supervised Learning Using Gaussian Fields and Harmonic Functions: Xiaojin Zhu, Zoubin Ghahramani, John Lafferty • http://www.hpl.hp.com/conferences/icml2003/papers/132.pdf Semi-Supervised Learning
