1. A Survival Guide Tim Mitchell Real-World SSIS

2. What we’ll cover today • Lessons I’ve learned the hard way • Methodologies to solve real problems in SSIS • Tools to help out • Solutions for SQL 2012 as well as earlier versions • Demos

3. What we won’t cover • No intro to SSIS • Books Online

4. Housekeeping • Presentation materials • Lunch / breaks

5. Housekeeping • Let’s keep it informal • Ask questions • Ask questions • Ask questions

6. PSA: Community • Survival is easier in groups • Local user groups • Events (SQL Saturday, SQL Bits, PASS Summit) • Online communities • Twitter (#sqlhelp)

7. About me • Business intelligence consultant • Group Principal, Linchpin People • SQL Server MVP • TimMitchell.net / @Tim_Mitchell

9. Texas Dictionary • Whole mess: Bountiful amounts of something, usually referring to excess • More than one way to skin a cat: A pet-unfriendly phrase to indicate that there are usually multiple ways to solve the same problem • Ya’ll: A subgroup of the current group • All ya’ll: The whole of the current group

10. survival (noun) The state or fact of continuing to live or exist, typically in spite of an accident, ordeal, or difficult circumstances. Reference: Dictionary.com (http://dictionary.reference.com/browse/survival)

11. survival (noun) Survival is simply the state of existing. It’s just a small step above being dead. -- Me Photo credit: Elvis Ripley (http://www.flickr.com/photos/elvisripley/315439191/). Used under Creative Commons license.

12. Elements of Survival The dangers: • The elements • Predators • Foolishness of fellow survivors • The unexpected

13. Elements of Survival The dangers: • Dirty data • Complex or poorly defined ETL requirements • Unexpected metadata changes • Unstable sources/destinations • Project managers

14. Elements of Survival Means of survival: • Common sense of self preservation • Tools • Leaning on others • Learning from others’ mistakes

15. Elements of Survival Means of survival: • Best practices • Consistency • Document • Tools (buy/build) • Community

16. Plan to Fail Survival Tip #1:

17. Planning to Fail

18. Planning to Fail Data failures: • Missing or offline sources • Changed metadata • Partial loads • Validation issues • Unexpected domain values

19. If it happens… When X

20. Planning to Fail Planning for failure in the wild: • Build your shelter before it rains • Layers • Leaves • Bread crumbs

21. Planning to Fail Planning for failure, the ETL way: • Be a pessimist! • Fail gracefully • Capture error/warning data on failure • Build for restartability (where appropriate)

22. Failing Gracefully

23. Planning to Fail Why graceful failure? • Avoid leaving affected systems in an inconsistent state • Avoid repeating wholesale operations • Timely notifications to allow proper response from dev/admin staff

24. Planning to Fail Graceful failures in SSIS • Control flow: • Event handlers • Precedence constraints • Data flow: • Error row redirection • Lookup failure redirection • Conditional split

25. Planning to Fail Graceful failures in SSIS • Restartability • SSIS Checkpoints • SSIS transactions • Both methods have shortcomings • Custom restartability can be an option

26. Planning to Fail Natural failures • Simply stop processing on error • Default behavior • In some cases, can be the right pattern

27. Demo Designing for failure

28. Take Notes Survival Tip #2:

29. Take Notes What to note? • Trails, paths, and shortcuts • Water sources • Hazards • Enemy positions • Weather and wildlife patterns • Sunrise/sunset time http://www.flickr.com/photos/defenceimages/4993131844

30. Take Notes What to note? • Success and failure of operations • Row counts • Run times • Validation information • Warnings http://www.flickr.com/photos/mezdeathhead/3057797092/

31. Take Notes Why? • Know what to expect • Plan for growth • Cover your assets http://www.flickr.com/photos/mezdeathhead/3057797092/

32. Take Notes It’s all about the log. • SSIS logging • SQL Server log • Custom logging http://www.flickr.com/photos/rwphoto/3108504086/

33. Take Notes SSIS Package Logging • It’s already there • Easy to start • Flexible events and destinations • Can be unwieldy http://www.flickr.com/photos/raver_mikey/4285637209/

34. Take Notes SSIS Catalog Logging • Version 2012 only • Easiest to configure • Design time or runtime • Least flexible http://www.flickr.com/photos/raver_mikey/4285637209/

35. Take Notes Custom Logging • Roll your own • Most difficult to set up • Infinitely flexible http://www.flickr.com/photos/raver_mikey/4285637209/

36. Take Notes Server/engine logging • SQL Engine error log • DMVs • Third party tools • Windows log • PerfMon http://www.flickr.com/photos/raver_mikey/4285637209/

37. Demo Take Notes

38. Perform atyour best Survival Tip #3:

39. Perform at your Best http://www.flickr.com/photos/defenceimages/5786942640/ http://www.flickr.com/photos/defenceimages/4627096866/

40. Perform at your Best Soldier up! • Recognize and avoid quicksand • React appropriately when you’re stuck • Know your environment

41. Perform at your Best Soldier up! • Isolate and eliminate the things that slow you down • Recognize design patterns that are detrimental to performance • Look *outside* SSIS (gasp!)

42. Perform at your Best It’s not just SSIS • The majority of SSIS performance problems have nothing to do with SSIS • Limitations on sources and destinations

43. Perform at your Best It’s not just SSIS • Don’t just ‘pass the buck’, but do consider other factors: • SQL engine configuration • Disk configuration • Network speed/latency • Physical machine capabilities

44. Perform at your Best It’s not just SSIS • Proper query techniques for relational sources • Effective indexing for sources and destinations • Using OPTION (FAST <n>)

45. Perform at your Best Streamline your data flows • Transformations matter! • Know how the blocking properties of transformations

46. Perform at your Best Streamline your data flows • Nonblocking transforms do not hold buffers • Derived Column • Conditional Split • Row Count

47. Perform at your Best Streamline your data flows • Partially blocking transforms will queue up buffers as needed • Merge Join • Lookup • Union All

48. Perform at your Best Streamline your data flows • Fully blocking transforms will not pass any data through until all of the data has been buffered at that transformation • Sort • Aggregate

49. Perform at your Best Streamline your data flows • Be aware of memory use! • LOB (large object) columns will always spool to disk rather than staying in memory. • [N]VARCHAR(MAX) • Memory buffers may spill over to disk

50. Perform at your Best Streamline your data flows • Manage your sources • Don’t use table drop down list – specify your query including only the necessary columns • Be mindful of indexes when writing data retrieval queries
