Cachebox 310 - For Large Network core

Cachebox 310 is a first web cache appliances which is using Solid State Drives (SSD) and delivers 3600 HTTP request per second in a 1 U format. It can support more than 20,000 user per appliance.

conduittechnlogies
Télécharger la présentation

Cachebox 310 - For Large Network core

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Cachebox 310 For Large Network core - Enterprise Class Web Caching Server

  2. Introduction of Cachebox 310 Cachebox 310 is basically designed for Huge network core i.e. for large network areas. It’s a perfect caching solution used for hundred of ISPs users worldwide. Cachebox is a High performance caching solution which is specially designed to manage modern Internet traffic with full security , reliability and problem solving technique. Cachebox 310 is a first web cache appliances which is using Solid State Drives (SSD) and delivers 3600 HTTP request per second in a 1 U format. It can support more than 20,000 user per appliance. CACHEBOX310 stores large file like internet video – include YouTube, Metacafe and many more…., It also caches the software updates for Operating system and Application that saves the vendor bandwidth up to 20 % - 40%. Cachebox is also compatible in heavy caching workload, You can cluster two or more Cachebox 310with WCCP or load balancer to increase its performance

  3. Features & Bandwidth Save bandwidth, save money Fully featured caching software support for HTTP Video caching (YouTube, Metacafe, Vimeo, Dailymotion, 4shared, Veohetc) Software update caching (MS Windows, Apple, Avast, Android, AVG Kaspersky etc) Pre-fetching and mirroring of content Browse safely and log activity • Secure HTTPS and SSH management interface • MS Active Directory integration via NTLM and Kerberos authentication • RADIUS/LDAP authentication

  4. Features & Bandwidth Easier to Manage Intuitive, secure web admin interface Setup and caching assistants On-box graphical reporting / scheduled reporting to monitor caching and network performance Automated on-box / off-box backups, alerting Multi-lingual interface Control and administer multiple users Validated and automated data entry Operating system runs from read-only industrial CompactFlash SNMP and Custom ACLssupport Logging

  5. Features & Bandwidth Flexible deployment • Supports multiple transparent and explicit deployment modes • Optional Fail-to-Wire resiliency • Clustering, load balancing and hierarchies • WCCP Support (v.2, GRE and Layer 2) • IP spoofing • Firewall with NAT forwarding for networking flexibility • iKVM remote access technology

  6. Specifications

  7. Why Cachebox 310 Cachebox 310 is used for Large network core based organization. Cachebox 310 is compatible for saving bandwidth in large network of 20,000 people or more than that. Cachebox serves web pages to user from local web cache, so that less data fetches from the Internet . It has an ability to add more users without increasing capacity Cache saving helps you to grow your revenue too. 1500 customers each spending an average $25 per month and you expect your hit rate to be 35%, your current monthly income is $37,500 and caching could help you make an additional $13,125. 1500 x $25 = $37,500 current income $37,500 x (35/100) = $13,125 additional monthly income That’s over $150,000 per year, dozens of times higher than the cost of an average CACHEBOX. For ISPs, in addition to bandwidth savings, you can typically provide a speed increase for customers of around 20-50%. An increase of this magnitude leads to increased customer satisfaction, reduced churn-rate, lower marketing costs and an opportunity to increase Average Revenue Per User (ARPU).

  8. Delay upgrade to your bandwidth 60Mb / 12 = 5Mb monthly growth => 4 months to fill the spare 20Mb Year one: 52Mb + 39Mb = 91Mb Year two: 91Mb + 39Mb = 130Mb (capacity reached after 3 months) 11 (upgrade delay in months) x$500 (cost difference) = $5,500 cost saving Cache upgrade your bandwidth as your traffic grows. It upgrade automatically so you keep on saving with a cache. For Example:you have a 100Mb connection with average peak load of 80% (80Mb) and growth of 60Mb per year. You would run out of bandwidth in 4 months: A cache saves up to 35 % would bring your current peak load down to 52Mb and your growth rate to 39Mb per year. This would keep you under your limit for 15months – an 11 month delay: If your current cost were $1000 per month and after upgrade it would be $1500, your saving before upgrade would be:

  9. Delay upgrade to your bandwidth After you upgrade, caching continues working to save you bandwidth and delay future upgrades. You continue to save money month after month.

  10. HOW to Deploy Cachebox Installation process of Cachebox is Flexible . Its Easy to deploy it in an network. It depends upon firewall rules you have to configured it. Cachebox will forward traffic sent via it, redirects on http traffic to its caching engine. It also configured with default proxy port, i.e. TCP port 800, It can changed on the basic setting page. Navigate to Cachebox> Basic It also configured with default web interface, i.e TCP Port 443. It can be changed on the service page. Navigate to Network > services.

  11. Thanks Lunkad Sky Station, Konark Nagar, Mhada Colony, Viman Nagar, Pune, Maharashtra 411014,India Tel : 020-4121 4112 | Fax : 020-4121 4113 sales@conduitechnologies.in | www.conduittechnologies.in
