1. New Technology Options

2. Today’s Topics • GNSS – UHF nTrip • TPS - Image Assisted Surveying • Software – Modern Software advancements. • Leica Active Assist & Leica Exchange • Scanning – New improvements

3. Leica GNSS • New Leica GS14 • Light Weight • (2.9kg all on the pole) • Internal Radio • CS15 Controller GS10 GS15 CS15

4. UHF • UHF is the primary method for RTK delivery • Long range broadcast (25 Watts) • Cheap licencing • Bandwith has always exceeded GPS requirements • Manufacturer Integration GS14 GS15 GS10

5. New Solution Needed? • New ACMA regulations • Higher Licencing costs • Reduction in the available channels • Reduction in output power • New Channel Spacing (25KHz, 12.5KHz and 6.25Khz offsets) • Bandwidth requirements for GPS & GLONASS (then add Galileo & Compass to the message)

6. nTrip Networked Transportation of RTCM over Internet Protocols • SmartnetAustralia • Joint venture between CR Kennedy & Leica • Provides RTK corrections anywhere within its network where phone signal is available • Proven around the world, UK, Mainland Europe, US and Eastern States

7. nTrip Server nTrip(NetworkedTransportation of RTCM over Internet Protocols)

8. Nearest Base nTrip Server MAC nTrip (NetworkedTransportation of RTCM over Internet Protocols)

9. Smartnet Australia

10. Smartnet WA

11. Benefits to a Surveyor • No Base Station • Take time to set up • Costs money for Security • Initial Hardware costs and maintenance Why not turn your base into a rover instead? • Available for Machine control applications • No Frequency interference • No Radio Licencing • No Radio Programming

12. Leica TPS • Built upon a Strong Foundation • Leica has 200 year History • CR Kennedy has 75 year History • The TS15 • 1” 3” 5” Angular Accuracy • R400 or R1000 EDM Specification 1100 Series 1000 Series 1200 Series Viva Series

13. Robotics • CS15 - its robotic partner • Viva easy to use software • Long Range Blue tooth radio Handle (RH16) • Tested and proven to communicate 800m from TS15

14. Image Assisted Surveying • TS15 Imaging model has an inbuilt camera • Allows real time streaming to the CS15 Controller • Sales Gimmick or useful?

15. Image Assisted Surveying • Capture – Sketch – Link • Capture: Capture a high-resolution image from the TS15. • Sketch: Enhance the image through sketching with any colour, line style and thickness. • Link: The final image can be stored & if desired, linked to any object of interest (point, line or area)

16. Image Assisted Surveying • Tap & Turn Capabilities • Use the Camera as an interaction between Surveyor & Instrument • Robotic & Two Man Applications • No more vertical eye piece

17. Image Assisted Surveying • 3D Data Overlay • Visible in the Camera Page Tab • Possible to View Points , Lines, Areas stored within the Job • A True Digital Overlay • Data Shapes Depend on Class • CTRL (Triangle) • Measured (Circle) • Distance Slider • Minimum & Maximum Distance View

18. Software Advancements GNSS & TPS

19. Where we have come from….. 1100 Series 1999-2004

20. Where We Are • New Viva software brings • Applications • Simplified & Customisable Screen • Map Screen Enhanced Survey COGO Calculations Stakeout

21. Apps Making Life Easier • Descriptions of Tasks • New Applications Stakeout 3D Polyline Expanded Roadrunner Options Ref Plane & Grid Scan

22. DXF Surveying • Bring your office to the field • No more points plans • Leica gives you full Cad Support • Colours, lines styles, fonts & formats • Better use of Map Screen Intelligence • Cogo , Compute Inverse, Create • See where you are on the map

23. XML Surveying • Bring your office to the field • No more points plans • Import lines, points and areas • Import Alignments • Import DTM’s

24. Leica Active Assist • Experienced Professional Help • A Direct Link to your Field System • One Button Registration • Reduce Delays & Downtime • Next Step in Technical Support • Benefits of Internet Enabled Equipment

25. Leica Exchange • Transfer objects easily between the Field & the Office with Leica Exchange • Field to office or office to field • Jobs, DXF, Code List, DTM, etc • With Instant Notification • Field and Office Solutions • Completed Jobs Sent to Office

27. RiMining New in Laser Scanning Scanstation P20 VZ-4000

28. Leica ScanStation P20 • 3D Position accuracy • 3mm@50m • 6mm@100m • Scanning up to 1,000,000 points/s • Ability to scan upside down • Ethernet or Wireless Lan • Check and Adjust • First and only scanner

30. VZ-4000 • Long range up to 4000m • Up to 22000points /sec • Multiple return capability • Built –in camera • Integrated L1 GPS, Compass and inclination sensor • L2 GNSS option using GNSS antenna (RTK means No backsight orientation) • Built-in Storage 64gb

31. Ri-Mining – For Pit SurveyingSurveying Pits has never been easier! • Uses an internal compass, GNSS and inclination sensor for position and orientation • Having at least 3 Scan Positions the MSA (Multi Station Adjustment ) calculations can compute the true north and level the scan data. Before Adjustment After Adjustment

32. Ri-MiningSurveying Pits has never been easier! Filtering machineries And vegetation After Adjustment Before Adjustment

33. Simple Workflow in RiMining

34. New Technology Options Thank you for your time
