WITSML Update

creda avatar
creda
13 diapositives · 550 Views · Jul 25, 2014

WITSML Update. Presentation to Energistics Regional Meeting, London By: Julian Pickering, Deputy Chairman, WITSML Executive Team June 31 , 2011. “The ‘ right-time ’ seamless flow of well-site data between operators and service companies to speed and enhance decision-making ”

WITSML Update - slide 1
01 / 13WITSML Update
1 / 17

Télécharger la présentation

WITSML Update
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. WITSML Update Presentation to EnergisticsRegional Meeting, London By: Julian Pickering, Deputy Chairman, WITSML Executive Team June 31, 2011

  2. “The ‘right-time’ seamless flow of well-site data between operators and service companies to speed and enhance decision-making” An Open Information Transfer Standard for the Oilfield Wellsite Information Transfer Standard Markup Language

  3. WITSML SIG: Member Companies • Petris Technology • Petrolink • Pioneer Natural Res. • Roxar • RPS Group • Saudi Aramco • Schlumberger • SDC Geologix • SMT • Shell • Smith (now Schlumberger) • Statoil • TCS • Total • Weatherford • Wellstorm • Woodside Energy • Accenture • AspenTech • Atman Consulting • Baker Hughes • BJ Services • BP • Chevron • US DOI • Digital Oilfield Sol. • DrillScan • Dynamic Graphics • ExxonMobil • Geolog SPA • Geoservices • Halliburton • HRH Limited • IBM • IDS • InstitutFrancais du Petrole • INT • Kongsberg • LIOS Technology • Mahindra Satyam • Merrick Systems • Microsoft • Moblize • National Oilwell Varco • Oil Teams S.R.L. • ONGC • OpenSpirit • Paradigm • Pason • Peloton • Perfomix

  4. Why is WITSML important? • is the result of an industry collaboration to update the widely used American Petroleum Institute WITS standard for moving drilling data between rig and office based computer systems. • It provides data in a consistent XML format which is independent of service company systems and geographic location. • It underpins the key objective to achieve leading edge productivity in well delivery by providing enhanced real-time information sharing. • It facilitates standardisation in collaboration environments. • It provides a framework for smart tools deployment.

  5. WITSML Roadmap Planning

  6. WITSML Data Object Schemas (XML) • General • Well • Message • Operations Report • Real Time • Wellbore • Wellbore Geometry • Risk • stimJob fracturing report • Communication • Subscription • Server Capabilities • Coordinate Ref Sys • Drill Report • Attachment • Rig Instrumentation • Rig / Rig Equipment • Cement Job • Fluids Systems • Fluids Report • Surface Logging • Mud Log • Coring • Sidewall Core • Conventional Core • Surveying • Survey Program • Target • Trajectory • Directional Drilling Systems • Tubular / • Bit Record • BHA Run • Logging While Drilling • Log  Well Log (includes Wireline) • Formation Marker • Original • Updated • Added Source: BakerHughes/Paradigm

  7. 2011 Release – 1.4.1 • June 30 – Candidate Release for public review • September 23 – 1.4.1 Published • Marketing name = WITSML 2 • Product launch • IADC Annual Conference March 2012 (San Diego, CA, US) • Intelligent Energy – March 2012 (Utrecht, The Netherlands) • 1.4.1 Product Certification • More robust testing • Testing application to automate • Publically available test data • Commercial terms (particularly for non-members to be defined) • Bug fixes to be issued as necessary • New object process to continue development as industry requirements are identified and defined beyond 1.4.1

  8. Reasons to Upgrade to v1.4.1 • Simpler • The WellLog and RealTime objects have been removed with the important parts of their purpose being taken up by support in the Log object.  • More efficient • Compression.The WITSML standard supports HTTP and Gzip compression resulting in less on-wire data for the same information. • Query Optimizations. High frequency small row count data updates for Logs had a high overhead of Log header to data block ratio in 1.3.1; This has been greatly improved with support for headerless Log updates. • Change Logs. The introduction of Change Logs enables clients to query servers more efficiently. • Less ambiguous • Improved documentationof the WITSML 1.4.1 API. • WITSML Certification. Unlike WITSML 1.3.1 which had a weak and self-certified approach, 1.4.1 servers can be tested against a published set of standard query sequences on a defined set of data and the results compared against pre-defined results enabling vendors to prove conformance to the WITSML 1.4.1 standard.

  9. Cross-theme components Foundation for all development • Regulatory • Security • New data • Certification • Data quality/provenance/context • Data management - life cycle data use • Horizontal integration to data standards in drilling or other domains • Technology overlay - new API, binary API, etc.

  10. IADC 2011 WITSML StandFunctional Layout

  11. IADC 2011 WITSML StandData Exchange Schlumberger Perform Toolkit Real-timeVisualisation GeologixGeo Toolkit MSE Data GEO Data Office Store OnshoreStore Rig Data Store IDS Operations Report Real-timeVisualisation

  12. The future is data standards – Questions?
