Oracle Virtualization Strategy and Roadmap

2. Oracle Virtualization Strategy and Roadmap Mark Atkinson Mark.Atkinson@oracle.com

3. Safe Harbor Statement The following is intended to outline our general product direction. It is intended for information purposes only, and may not be incorporated into any contract. It is not a commitment to deliver any material, code, or functionality, and should not be relied upon in making purchasing decisions. The development, release, and timing of any features or functionality described for Oracle’s products remains at the sole discretion of Oracle.

4. Agenda • State of Virtualization • Oracle’s Virtualization Portfolio • Desktop Virtualization • Server Virtualization • Engineered for Oracle • Succeed with Oracle Virtualization

5. Cloud Transforming IT Needs Datacenters are becoming Service Centers Integrated Stack Management IT Needs to Deliver Ready to Run Services Scalability & Availability & Agility Isolated Hypervisors are not good enough Certified Interoperability

6. Application-Driven Virtualization Delivering Value Beyond Server Consolidation Ensured Compatibility Easy to Deploy Simplicity for the Entire Computing Stack Easy to Support Easy to Manage

7. Contact Service Center Software Delivery Cloud VM VM VM VM VM VM Oracle’s Virtualization PortfolioThe Full Stack,End-to-End DATA CENTER USERS BROWSER E-Business Suite VMs Oracle Enterprise Manager 12c Application Stack Oracle Desktop Virtualization Oracle Secure Global Desktop Oracle VM Servers THIN CLIENTS Oracle Sun Ray Clients Network Oracle VM Templates & Assemblies Servers Servers Servers PCs, MACs, MOBILE DEVICES Storage Storage Oracle Virtual Desktop Client Desktop Virtualization Server Virtualization Network Virtualization • Oracle Virtual Desktop Infrastructure • Sun Ray Clients • Oracle Secure Global Desktop • Oracle VM VirtualBox • Oracle Xsigo Data Center Fabric • Oracle VM Server for x86 • Oracle VM Server for SPARC (LDoms) • Oracle Solaris Zones • DynamicDomains

8. Agenda • State of Virtualization • Oracle’s Virtualization Portfolio • Desktop Virtualization • Server Virtualization • Engineered for Oracle • Succeed with Oracle Virtualization

9. The Desktop Cloud: Maximize User Productivity Centralize Information But Distribute Access • “Bring Your Own Device” becoming the norm • Centralize everything the users need to be productive (applications & data) • Access from more locations • Access from more devices • Unobtrusively secured Data Center

10. Oracle Desktop Virtualization Portfolio • The user’s entire desktop, hosted on the server • Access from any Oracle Virtual Desktop Client enabled device (Windows, Linux, Mac, iPad, Sun Ray) Oracle VirtualDesktop Infrastructure • Individual applications, hosted on the server • Extremely easy, web browser based access to virtually any application on nearly any major platform Oracle SecureGlobal Desktop • Software clients for Windows, Linux, Mac, iPad • Hardware Sun Ray Clients for maximum security and eco-benefit Oracle Desktop Virtualization Clients

11. Oracle Virtual Desktop Infrastructure Your Desktop on a PC Your Desktop on a Mac Your Desktop on a Sun Ray client You Desktop on iPad

12. Sun Ray Clients An Ideal Client for Virtual Desktops • No configuration necessary, connect immediately to servers • Displays full Windows, Oracle Linux, and Oracle Solaris desktops • Up to 1920x1080 HD resolution, 2 DVI ports, 5 USB ports, Gigabit Ethernet, fiber optic networking, two-way audio support and more • Energy efficient: as low as 6 watts, 98% recyclable and EPEAT Silver and Energy Star 5.0 qualified

13. Oracle VM VirtualBox The World’s Most Popular Open Source, Cross-Platform Workstation Virtualization • Run nearly any X86 OS, including Windows 8 • Run on any major X86 OS: Windows, Mac including Mountain Lion), Linux, Solaris • Supports VM Groups, iSCSI, local hardware acceleration, OpenGL, Windows Aero • Award winning workstation virtualization • Over 80 million downloads

14. Agenda • State of Virtualization • Oracle’s Virtualization Portfolio • Desktop Virtualization • Server Virtualization • Engineered for Oracle • Succeed with Oracle Virtualization

15. Oracle VM – Foundation for Cloud Application-Driven Virtualization • At the core of Oracle’s middlewareand cloud strategy • Cloud platform for Oracle applications • Integrated cloud management solution with Oracle Enterprise Manager 12c and Ops Center • Rapid application deployment and management • The only server virtualization software supported and certified with Oracle products

16. Oracle VM Server Virtualization • Available for both x86 and SPARC • Virtualization solution for both Oracle and non-Oracle applications • The only x86 server virtualization software supported and certified for all Oracle software • Boosted to “Challenger” position • 2012 Gartner Magic Quadrant • High Performance • Faster application deployment • Free to download • Enterprise-quality support • Integrated full-stack management

17. Oracle VM Manager Oracle VM Manager Fully Centralized Virtualization Management • Oracle VM Manager • Browser UI • Manage numerous server pools • Create, configure, clone, share, boot, migrate VMs • Convert other virtual machine formats • Networks • Separate… • Guest • HA • Live Migration • Storage • Management Oracle VM Servers Server Pool 2 Server Pool 2 • Server pools • HA groups • Resource groups • Live Migration groups • Policy-based power management • Virtual Machines • Oracle Solaris • Oracle Linux • Red Hat Enterprise Linux • Microsoft Windows • X86 architecture • SPARC architecture Server Pool 1 Storage Repository • Shared Storage Repositories • NFS, Fibre Channel, iSCSI • Support heterogeneous configurations • Share storage between multiple pools and clusters. • Ability to share raw device between VMs Sun Storage Partner Storage

18. Oracle VM Manager Enhancements • Enhanced GUI: streamlined operations • Fewer clicks and drag-and-drop operations • More logical, efficient layout and flow in wizards • Infrastructure for multi-hypervisor management: • Oracle VM Server for SPARC and for x86 Servers together • Storage Connect expansion: • Hitachi, Fujitsu, EMC, and Oracle on the list of plug-ins VM VM VM VM VM VM

19. Oracle VM Server for x86 Enhancements • Updated Server Software • Now with Unbreakable Enterprise Kernel 2 • Oracle Linux drivers = Oracle VM Server drivers • Rapid driver availability, streamlined partner certifications • Latest Xen hypervisor version to support the latest hardware • Storage / Network Enhancements • Performance improvements • Expanded configuration options • Export server storage for backup and recovery • Move storage repositories around allowing easier disaster recovery or standby server pools. VM VM VM VM VM VM

20. Oracle VM Server for SPARC For Your Enterprise Server Workloads Isolated OS and applications in each logical (or virtual) domain Firmware-based hypervisor SPARC Hypervisor Each logical domain runs in dedicated CPU thread(s) T-Series Server Optimized for SPARC / Oracle Solaris

21. Oracle VM for SPARC 2.2 Secure Live Migration and Advanced I/O • Live Migration on the same or different generations of SPARC T-Series Systems • On-chip Crypto Accelerators Deliver Secure, Wire-Speed Encryption for Live Migration • No additional hardware required • Eliminates requirement for dedicated network • Support for SR-IOV (Single Root IO Virtualization) • Directly share I/O device resources to guest domains • Also support for PCIe Direct I/O • Assign individual PCIe cards to guest domains Shared Storage

22. Oracle VM Manager Oracle VM Servers Easy Integration: Oracle Enterprise Manager • Full management functionality • Everything you can do from Oracle VM Manager • Integrated life-cycle management Lifecycle Management Test Provision • Easy integration • New- or existing Oracle VM Manager instance • Just point Enterprise Manager instance to Oracle VM Manager instance • No migration or re-discovery required • No new EM agent deployments required Configure Oracle Enterprise Manager 12c Deploy Monitor Change & Patch • Easy to use, flexible access • Access from EM GUI or Manager GUI or both • Use one GUI if the other is off-line • EM GUI for application admins, Oracle VM Manager GUI for virtualization admins Application Driven Full Stack Management

23. Oracle VM Enables Cloud Management Capabilities Self-ServiceProvisioning Metering and Chargeback Policy-Driven Resource Mgmt Capacity Planning AssemblyPackaging Foundation Capabilities for Managing Datacenters Application Performance & Quality Management ConfigurationandCompliance Lifecycle Management Oracle VM 3.0 Virtualization Management Full Apps to Disk Management Oracle Enterprise Manager 12c Cloud Management with Oracle VM 3

24. Building for the Cloudwith Software Defined Infrastructure

25. There are Challenges in Your Network Physical management requirements inefficient Virtual Resource Admin Physical Resource Admin Cloud API • Network topologies are closely tied to physical network layout, inhibiting easy scalability • Often physical action required to reconfigure • Virtualization admins lack complete toolset to control provisioning, limiting operational agility • Lack of unified API inhibits full cloud automation VLAN VLAN VLAN Network Physical Server VM VM VM Servers Physical Storage / Volume File vDisk vDisk Storage

26. Xsigo Data Center Fabric and Oracle VM Applying a Profile to Provision a New Standard Server through Software Add resources to live servers Migrate virtual I/O on demand VM1 VM2 Create & configure VMs normally from Oracle VM Manager Oracle VM • Apply Standard Server Profile from Xsigo Fabric Manager • Std. DB Server Profile • 3 vNICs • 2 vHBAs XSIGO FABRIC DIRECTOR vHBA vHBA vNIC vNIC vNIC 1G 10G FC iSCSI NAS Storage Network 1G 10G

27. Oracle RAC with Xsigo Data Center Fabric Oracle VM Template for Fast Deployment; High Bandwidth for High Performance Add resources to live servers Migrate virtual I/O on demand • Create software defined I/O fabric with private interconnects • Rapidly deploy RAC via existing Oracle VM Template • Set unique QoS policies for different networks (RDMA, live migration, storage, etc.) • Faster live migration under load • Fabric interconnect with other app tiers for high performance VM1 RAC Node 2 RAC Node 1 VM2 Oracle VM Oracle VM 40Gb/s fabric XSIGO FABRIC DIRECTOR vNIC vNIC vNIC vNIC vNIC vNIC 1G 10G FC iSCSI NAS Storage Network 1G 10G

28. Agenda • State of Virtualization • Oracle’s Virtualization Portfolio • Desktop Virtualization • Server Virtualization • Engineered for Oracle • Succeed with Oracle Virtualization

29. Oracle VM 3 Engineered for Oracle • At the core of Oracle’s middlewareand cloud strategy • Virtual platform for Oracle applications • Integrated management of the virtual stack with Oracle Enterprise Manager 12c • Rapid application deployment and management

30. Oracle VM & Engineered Systems Engineered for Cloud Infrastructure • Oracle VM integrated into Exalogic Elastic Cloud • Exalogic Elastic Cloud • Physical x86 servers, Infiniband fabric • SPARC SuperCluster T4-4 System • Integrates Oracle VM Server for SPARC to host Oracle Solaris VMs • Virtualization Engineered for optimum performance SPARC SuperCluster Exalogic Elastic Cloud Oracle VM

31. Software Delivery Cloud Siebel CRM File Oracle VM Templates for Applications Rapid Deployment; 100+ Templates Available • Pre-built, pre-configured, production-ready VMs • Apps, Databases, Middleware, OS; Siebel CRM, Oracle RAC, More… • Near zero knowledge of OS, Application installation required • Automate deployment of a complete production ready 8 node RAC cluster in minutes through a simple single configuration file Oracle VM Servers Siebel CRM File Siebel CRM VM 1 Server Pool 2 Import to Oracle VM Manager Start-up in Oracle VM Pool Customize & Save as Golden Image Download

32. Oracle VM Templates Accelerate Application Deployment Deploy E-Business Suite 7x faster than VMware vSphere Evaluator Group Lab Validation: “Oracle VM – Quantifying The Value of Application-Driven Virtualization”

33. Oracle VM Templates Accelerate Application Deployment vSphere 5 & Management Oracle VM & Management Oracle RAC on vSphere 39.75 hours DBA time 5 steps to implement 3.92 hours DBA time Oracle RAC on Oracle VM 13 steps to implement 40 hrs x $50 = $2,000 4 hrs x $50 = $200 Evaluator Group Lab Validation: “Oracle VM – Quantifying The Value of Application-Driven Virtualization”

34. Agenda • State of Virtualization • Oracle’s Virtualization Portfolio • Desktop Virtualization • Server Virtualization • Engineered for Oracle • Succeed with Oracle Virtualization

35. Oracle VM Roadmap OVM 3.2.1 • Updated Server Software • Unbreakable Enterprise Kernel 2 • Oracle Linux drivers = Oracle VM Server drivers • Rapid driver availability, streamlined partner certifications • Latest Xen hypervisor version to support the latest hardware • Storage / Network Enhancements • Performance improvements • Expanded configuration options • Export server storage for backup and recovery • Move storage repositories around allowing easier disaster recovery or standby server pools.

36. Oracle VM 3.2.1 Roadmap • Support for Oracle VM Server for SPARC • New Dom0 kernel in Oracle VM server. *Same Oracle Unbreakable Enterprise Kernel UEK2 as used by Oracle Linux. • MySQL Database Support • New Oracle VM Command Line Interface • UI Accessibility options (screen readers, font size) • UI Health Tab • UI Multi-select of Objects • UI Search for Objects • Present repository to one or more server pools

37. Solving Virtualization Challenges for Customers

38. Oracle Virtualization • Home Pageoracle.com/virtualization • Blogblogs.oracle.com/virtualization • Downloadedelivery.oracle.com/oraclevm

39. Join the conversation @ORCL_Virtualize facebook.com/OracleVirtualization youtube.com/OracleVirtualization

41. Use Case: Healthcare Instant, Secure Access • Healthcare requires instant, secure access from anywhere • To help with compliance, centralized data and logging of user locations and activities is crucial • “Caregiver mobility” allows healthcare workers to move from patient to patient, room to room, with no disruptions

42. Use Case: Contact Center Work Anywhere • Contact centers demand maximum location flexibility • Workers can be at different workspaces every day, different offices, or working from home • Oracle desktop virtualization provides simple, reliable access to all applications and data from anywhere on nearly any device

43. Use Case: Public Sector The Highest Security • State and local governments and other public sector entities have incredibly strict security policies • Public sector organizations also have many disparate data locations and application platforms • Centralizing all data and applications dramatically increases security and enables better access control

44. Oracle Desktop Virtualization: The Year In Review… • Oracle VM VirtualBox 4.2 • Windows 8, VM Groups, autostart, network enhancements • Oracle Secure Global Desktop 4.7 • Audio-in, security enhancements, multi monitor application support • Oracle Sun Ray Server 5.3, Oracle VDI 3.4 • 720p HD video • Copy/paste with soft client(ovdc) • USB 2.0 devices, improved smartcard stack, local storage • Oracle Virtual Desktop Client for ipad

45. Oracle Secure Global Desktop Your Cloud Access Portal • Provides central access to “everything” users need • Oracle, web-based, Windows, Unix, and Mainframe/Mid-frame applications • Lightweight browser-based client for PC, Linux, and Mac • SSL: No VPN infrastructure and associated support costs • Lightweight / non-intrusive client installation • Certified Access to Oracle’s web-based applications • Rapid deployment with Oracle VM Templates • Industrial-grade network security VMs Server-based browsers Data Center Server Applications WAN / Internet LAN Secure Global Desktop Secure Global Desktop Desktops VMs Gateway

46. Oracle Secure Global Desktop Future Directions: More Devices Means More Locations • Future plans: HTML5 Client • Enables SGD access from more devices… • Tablets • Phones • Pause and resume sessions across more devices • Start session on work desktop… • Continue on the train home from your tablet… • Wrap-up on your home system… • Quick check-in from your phone VMs Server-based browsers Data Center Server Applications WAN / Internet LAN Secure Global Desktop Secure Global Desktop Desktops Gateway

47. Oracle Desktop Virtualization Complete, Open, Integrated • Better performance and reliability • Designed for security • Shorter deployment times • Easier to manage and upgrade • Lower cost of ownership • Reduced change management risk • One-stop support

48. Oracle Desktop Virtualization Clients Comprehensive Options To Access Apps and Data • Software and hardware clients to fit any deployment scenario • Run simple client software on Windows, Mac, Linux, or iPad for BYOD • Or deploy Sun Ray Clients for the ultimate in security, manageability, and eco-responsibility • Work from anywhere, instantly move between devices and pick up where you left off

49. Enterprise Manager Support for Oracle VM: Highlights • Enterprise Manager provides cloud systems based on Oracle VM for x86 or SPARC • Enterprise Manager automates key operations (provisioning, scale up) via the underlying Oracle VM Manager • Easier for customers to adopt, scale up and diagnose • Enterprise Manager creates additional value on top of native Oracle VM Manager based operations • Assembly Provisioning • Policy based capacity on demand • Metering and Chargeback • Incident and Configuration Management …. • The new architecture enables faster support for new versions • Oracle VM 3.1.1 was supported within a week of release • Several customer implementations active or in progress

50. Oracle VM Templates Accelerate Application Deployment vSphere 5 & Management Oracle VM 3 & Management Oracle RAC on vSphere Oracle RAC on Oracle VM Evaluator Group Lab Validation: “Oracle VM – Quantifying The Value of Application-Driven Virtualization”
