1. Spoofing State Estimation William Niemira

2. Overview • State Estimation • DC Estimator • Bad Data • Malicious Data • Examples • Mitigation Strategies

3. State Estimation Finite transmission capacity Economic and security aspects must be managed Contingency analysis Pricing Congestion management Accurate state information needed

4. State Estimation • Networks are large • Thousands or tens of thousands of buses • Large geographical area • Many measurements to reconcile • Different types • Redundant • Subject to error

5. State Estimation • State estimation uses measurement redundancy to improve accuracy • Finds best fit for data • Differences between measures and estimates can indicate errors

6. DC Estimator • Overdetermined system of linear equations • Solved as weighted-least squares problem • Assumes: • Lossless branches (neglects resistance and shunt impedances) • Flat voltage profile (same magnitude at each bus) • Reduces computational burden

7. DC Estimator • is the vector of n states • is the vector of m measurements • is the m x n Jacobian matrix • is an m vector of random errors

8. DC Estimator • Residual vector • Estimated as where • Minimize: • Where is a diagonal matrix of measurement weights

9. DC Estimator • Differentiate to obtain • Where is the state estimate and is the state estimation gain matrix • Bad data assumed if where is some tolerance

10. 1-Bus Example PG = PGmeas PL1 = PL1meas – PL1 – PG = PL2meas

11. 1-Bus Example For variances of 0.004, 0.001, and 0.001 for PGmeas, PL1meas , PL2meas respectively

12. 1-Bus Example

13. 3-Bus Example – 50 θ2 – 100 θ3 = P1meas 150 θ2 – 100 θ3 = P2meas – 100 θ2+ 200 θ3= P3meas – 100 θ3 = P13meas

14. 3-Bus Example

15. 3-Bus Example

16. Bad Data • Bad data usually consists of isolated, random errors • These types of errors tend to increase the residual • Measurements with large residuals can be omitted to check for better fit • Works well for non-interacting bad measurements

17. 1-Bus Example Good Data Bad Data

18. Malicious Data • Malicious data (data manipulated by an adversary) need not be isolated or random • Adversary may inject multiple coordinated measurement errors • Errors could interact with each other or other measurements • Could change without increasing

19. Attack Formation • Given: • Attacked measurement vector • Attack vector • Estimated states due to attack • Clever adversary chooses

20. 1-Bus Example PG = PGmeas PL1 = PL1meas – PL1 – PG = PL2meas

21. 1-Bus Example Unobservable attack vectors: Any linear combination of

22. 1-Bus Example Unattacked Attacked

23. For Real? • In practice, state estimators are more complicated than previous examples • Assumed strong adversary: • Has access to topology information • Has some means to change measurements • Why would someone do this? • Simulate congestion—could affect markets • Reduce awareness of system operator

24. AC Estimator • AC model accounts for some effects neglected in the DC model • Attacks as generated earlier will affect residual • Attack may not have effect intended by adversary

25. AC Estimator • is the vector of n states • is the vector of m measurements • is nonlinear vector function relating measurements to states • is an m vector of random errors

26. AC Estimator • Solved using Gauss Newton method • Gain matrix: • is diagonal matrix of variances • Estimation procedure:

27. AC Estimator • DC approximation is pretty good • Harder to detect attack than random error • Relatively large attacks may escape detection • Grid state affects quality of DC attack

28. Detection • Focus on quantities neglected by DC model (VARs) • VARs tend to be localized • AttackLosses changeVAR flow and generation changes

29. Detection • Alternative approach is to estimate parameters simultaneously with states • Augment state vector with known parameters • Compare known values to parameter estimates to find bad data

30. Detection • Choose something known to the control center but not an attacker • Example: TCUL xformer tap position, D-FACTS setting • Attacks will perturb parameter estimates

31. Conclusions • State estimators, even nonlinear estimators, are vulnerable to malicious data • Malicious data is different from conventional bad data • Nonlinearity effects of the attack may be detectable • Parameter estimation can verify data

32. Questions? Thank you!
