  1. Title Slide Learn How To Partition In Oracle 9i Release 2 By Eric Yen System Consultant Quest Software

  2. Agenda • Partitioning Defined • Evolution of Partitioning in Oracle • When to partition tables • Range Partitioning • Hash Partitioning • List Partitioning • Composite • Range-Hash • Range-List

  3. Agenda • Globally Partitioned Indexes • Locally Partitioned Indexes • Bringing It All Together • Other Sources Of Information • Summary • Questions and Answers • Short Survey . . . How did I do?

  4. Partitioning Defined • The concept of Divide and Conquer. • Breaking down a large problem into smaller manageable pieces. • Making a mountain into a mole hill. • Your definition here. • “Dividing Tables and Indexes into manageable pieces.”

  5. Evolution of Partitioning in Oracle • Oracle 8 • Range • Oracle 8i • Range • Hash • Composite • Range-Hash • Oracle 9i • Release 1 • Range • Hash • List • Composite • Range-Hash • Oracle 9i • Release 2 • Range • Hash • List* • Composite • Range-Hash • Range-List

  6. When to partition tables • For “large” table. Tables >= 2 Gigs* • Performance gain outweighs the management of partitioning. • Archiving of data is on a schedule and repetitive.

  7. Range Partitioning • Often used when there is a logical range. • Examples: • Dates • Start Date • Transaction Date • Close Date • Date of Payment • IDs • Product ID • Location ID • UPC

  8. Partition Method Partition Key Partition Definition Range Partitioning Code CREATE TABLE PARTITION_BY_RANGE ( . . . BIRTH_MM INT NOT NULL, BIRTH_DD INT NOT NULL, BIRTH_YYYY INT NOT NULL) PARTITION BY RANGE(BIRTH_YYYY, BIRTH_MM, BIRTH_DD) (PARTITION PARTITION_01 VALUES LESS THAN (1970, 01 ,01) TABLESPACE TS01, . . . PARTITION PARTITION_N VALUES LESS THAN (MAXVALUE, MAXVALUE, MAXVALUE) TABLESPACE TS05 ) ENABLE ROW MOVEMENT;

  9. Hash Partitioning • Hashing allows for distributed data by a hash key. • DBAs do not have to know the data. • Distribution is handled by Oracle. • Each partition can have its own tablespace.

  10. Partition Method Partition Key Partition Definition Hash Partitioning Code Hash Partitioning Code CREATE TABLE PARTITION_BY_HASH (FIRST_NAME VARCHAR2(10), MIDDLE_INIT VARCHAR2(1), LAST_NAME VARCHAR2(10), AGE INT NOT NULL) PARTITION BY HASH (AGE) (PARTITION P1_AGE TABLESPACE TS01, PARTITION P2_AGE TABLESPACE TS02, PARTITION P3_AGE TABLESPACE TS03, PARTITION P4_AGE TABLESPACE TS04) ENABLE ROW MOVEMENT;

  11. List Partitioning • Added in Oracle 9.1 • In 9.2 the “DEFAULT” partition method was added. • Allows DBAs to explicitly define what is in a partition. • Example • States into a Region • Departments into a Division

  12. Partition Method Partition Key Partition Definition List Partitioning Code List Partitioning Code CREATE TABLE PARTITION_BY_LIST (DEPTID NUMBER, DEPTNAME VARCHAR2(15), STATE VARCHAR2(2)) PARTITION BY LIST (STATE) (PARTITION DEPTS_IN_NORTH VALUES ('AK') TABLESPACE TS01, . . . PARTITION DEPTS_WITH_NO_REGION VALUES (DEFAULT) TABLESPACE TS05) ENABLE ROW MOVEMENT;

  13. Composite Range-Hash • Partition by Range • Stored by a Hash algorithm • DBAs can focus on both the ease of Range Partitioning and get the benefits of Hash Partitioning • Logically divide the data and let Oracle determine where to store.

  14. Composite Range-Hash Code Composite Range-Hash Code CREATE TABLE PARTITION_BY_RANGE_HASH ( FIRST_NAME VARCHAR2(10), MIDDLE_INIT VARCHAR2(1), LAST_NAME VARCHAR2(10), BIRTH_MM INT NOT NULL, BIRTH_DD INT NOT NULL, BIRTH_YYYY INT NOT NULL) TABLESPACE USERS

  15. Partition Key Partition Key Partition Partition Definition Composite Range-Hash Code continued Composite Range-Hash Code continued PARTITION BY RANGE (BIRTH_YYYY, BIRTH_MM, BIRTH_DD) <SUBPARTITION TEMPLATE> (PARTITION DOBS_IN_1971 VALUES LESS THAN (1972, 01 ,01), . . . PARTITION DOBS_IN_1975 VALUES LESS THAN (MAXVALUE, MAXVALUE, MAXVALUE)) ENABLE ROW MOVEMENT;

  16. Subpartition Method Subpartition Key Subpartition Name Composite Range-Hash Code continued Composite Range-Hash Code continued SUBPARTITION BY HASH(FIRST_NAME, MIDDLE_INIT, LAST_NAME) SUBPARTITION TEMPLATE( SUBPARTITION SP1 TABLESPACE TS01, SUBPARTITION SP2 TABLESPACE TS02, SUBPARTITION SP3 TABLESPACE TS03, SUBPARTITION SP4 TABLESPACE TS04, SUBPARTITION SP5 TABLESPACE TS05)

  17. Composite Range-List • Similar to Range-Hash partitioning. • Subpartition is by List method. • Allows for greater control by the DBAs. • Proper use of Range-List must be carefully thought out.

  18. Composite Range-List Code Composite Range-List Code CREATE TABLE PARTITION_BY_RANGE_LIST ( FIRST_NAME VARCHAR2(10), MIDDLE_INIT VARCHAR2(1), LAST_NAME VARCHAR2(10), BIRTH_MM INT NOT NULL, BIRTH_DD INT NOT NULL, BIRTH_YYYY INT NOT NULL, STATE VARCHAR2(2) NOT NULL) TABLESPACE USERS

  19. Partition Key Partition Key Partition Partition Definition Composite Range-List Code continued Composite Range-List Code continued PARTITION BY RANGE (BIRTH_YYYY, BIRTH_MM, BIRTH_DD) <SUBPARTITION TEMPLATE> (PARTITION DOBS_IN_1971 VALUES LESS THAN (1972, 01 ,01), . . . PARTITION DOBS_IN_1975 VALUES LESS THAN (MAXVALUE, MAXVALUE, MAXVALUE)) ENABLE ROW MOVEMENT;

  20. Subpartition Key Subpartition Method Subpartition Name Composite Range-List Code continued Composite Range-List Code continued SUBPARTITION BY LIST (STATE) SUBPARTITION TEMPLATE (SUBPARTITION IN_NORTH VALUES ('AK') TABLESPACE TS01, SUBPARTITION IN_EAST VALUES ('NY', 'NJ', 'VA', 'CT') TABLESPACE TS02, . . . SUBPARTITION NO_STATE VALUES (DEFAULT) TABLESPACE TS05)

  21. Globally Partitioned Indexes • Two types of Globally Partition Indexes. • Non-Partitioned • Partitioned • Globally Non-Partitioned Indexes are “regular” indexes used in OLTP. • Globally Partitioned Indexes are similar in syntax to Range partitioned tables.

  22. Index Method Index Partition Index Partition Globally Partitioned Index Code Globally Partitioned Index Code CREATE INDEX PARTITION_BY_RANGE_GPI ON PARTITION_BY_RANGE (BIRTH_YYYY) GLOBAL PARTITION BY RANGE (BIRTH_YYYY) (PARTITION DOBS_IN_1971_OR_B4 VALUES LESS THAN (1972) TABLESPACE ITS01, PARTITION DOBS_IN_1972_GPI VALUES LESS THAN (1973) TABLESPACE ITS02, . . . PARTITION DOBS_IN_1975_OR_L8R VALUES LESS THAN (MAXVALUE) TABLESPACE ITS05);

  23. Locally Partitioned Indexes • Oracle manages the rebuild of LPI • Extra time should be allocated for • Range-Hash • Range-List • LPI can “point” to partition or subpartition level. • No SUBPARTITION TEMPLATE

  24. Index Method Index Partition Locally Partitioned Index Code Locally Partitioned Index Code – Partition Level (LPI at Partition Level) CREATE INDEX PARTITION_BY_RANGE_HASH_LIP ON PARTITION_BY_RANGE_HASH (LAST_NAME) LOCAL ( PARTITION <PARTITION_NAME01> TABLESPACE ITS01, . . . PARTITION <PARTITION_NAMEN> TABLESPACE ITSN);

  25. Index Method Index Partition Index Subpartition Locally Partitioned Index Code Continued Locally Partitioned Index Code – Subpartition Level (LPI at Subpartition Level) CREATE INDEX <INDEX_NAME> ON <TABLE_NAME> (<COLUMNS>) LOCAL (PARTITION <PARTITION_NAME> TABLESPACE ITS0N ( SUBPARTITION <SUBPARTITION_NAME> TABLESPACE ITS01 , . . . SUBPARTITION <SUBPARTITION_NAME> TABLESPACE ITS0N ), . . .

  26. Index Partition Index Subpartition Locally Partitioned Index Code Continued Locally Partitioned Index Code – Subpartition Level (LPI at Subpartition Level) (PARTITION <PARTITION_NAME> TABLESPACE ITS0N ( SUBPARTITION <SUBPARTITION_NAME> TABLESPACE ITS01 , . . . SUBPARTITION <SUBPARTITION_NAME> TABLESPACE ITS0N ) );

  27. Bringing It All Together • 5 table partition methods • Range, Hash, List, Range-Hash, Range-List • 3 index partition methods • Global Non-partition, Global partition, Locally partition • Guidelines • Is the table the “right” size? • How volatile is the data? • What are your maintenance considerations?

  28. Other Sources Of Information • Oracle9i Database Concepts Release 2 (9.2) Part Number A96524-01 Chapter 11 Partitioned Tables and Indexes • Oracle9i Database Administrator's Guide Release 2 (9.2) Part Number A96521-01 Chapter 17 Managing Partitioned Tables and Indexes*

  29. Summary • Basics of partitioning • Definition, Evolution & When to partition • Table partitioning methods • Range, Hash, List, Range-Hash, Range-List • Index partitioning methods • Global Nonpartition, Global Partition, Locally Partition • Wrapped It Up • Bringing it all together, Other Sources Of Information

  30. Question and Answer Question and Answer

  31. THANK YOU FOR LISTENING
