Understanding Comparison Instructions: A Key Component of Efficient Programming

delano avatar
delano
11 diapositives · 261 Views · Aug 20, 2014

In programming, comparison instructions are essential for determining relationships between values. This lecture focuses on several types of comparison operations, such as Equal (EQU), Not Equal (NEQ), Less Than (LES), Less Than or Equal (LEQ), Greater Than (GRT), Greater Than or Equal (GEQ), Masked Comparison for Equal (MEQ), and Limit Test (LIM). Each of these operations has specific syntax and usage guidelines that programmers must follow. By mastering these instructions, developers can effectively control the flow of their programs and make informed decisions based on data comparisons.

#understanding comparison instructions: a key component of efficient programming #understanding comparison instructions: a key component of efficient programming ppt #powerpoint #presentation
Understanding Comparison Instructions: A Key Component of Efficient Programming - slide 1
01 / 11Understanding Comparison Instructions: A Key Component of Efficient Programming
1 / 17

Télécharger la présentation

Understanding Comparison Instructions: A Key Component of Efficient Programming
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. ECT 464 Lecture 10 Comparison

  2. Today’s Quote: You cannot win if you do not begin. Now finish the work, so that your eager willingness to do it may be matched by your completion of it, according to your means. 2 Corinthians 8:11

  3. Comparison Instructions • EQU – Equal • NEQ – Not equal • LES – Less than • LEQ – Less than or equal • GRT – Greater than • GEQ – Greater than or equal • MEQ – Masked comparison for equal • LIM – Limit test

  4. Equal (EQU) • Tests whether two values are equal • Source A must be an address • Source B can be an address or a constant

  5. Not Equal (NEQ) • Tests whether two values are not equal • Source A must be an address • Source B can be an address or a constant

  6. Less Than (LES) • Tests whether Source A is less than Source B • Source A must be an address • Source B can be an address or a constant

  7. Less Than or Equal (LEQ) • Tests whether Source A is less than or equal to Source B • Source A must be an address • Source B can be an address or a constant

  8. Greater Than (GRT) • Tests whether Source A is greater than Source B • Source A must be an address • Source B can be an address or a constant

  9. Greater Than or Equal (GEQ) • Tests whether Source A is greater than or equal to Source B • Source A must be an address • Source B can be an address or a constant

  10. Masked Comparison for Equal (MEQ) • Tests whether data at the Source is equal to data at the Compare • Source must be an address • Compare can be an address or constant • Mask is the address or a constant through which the data is compared. • Bits in the mask allow bits in the source and compare to be compared when set.

  11. Limit Test (LIM) • Tests whether data is within or outside a specified range • If Test is a constant, Low and High limits must be addresses • If Test is an address, Low and High limits can be addresses or constants. • If the Low limit is greater than the High limit, the instruction is false between the two limits.
