Working with Applications

DESCRIPTION

Working with Applications. Lesson 7. Objectives. Administer Internet Explorer Secure Internet Explorer Configure Application Compatibility Configure Application Restrictions. Administering Internet Explorer. Configuring Internet Explorer. Compatibility view Managing add-ons

1 / 41

Télécharger la présentation

Working with Applications

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Working with Applications Lesson 7

  2. Objectives • Administer Internet Explorer • Secure Internet Explorer • Configure Application Compatibility • Configure Application Restrictions

  3. Administering Internet Explorer

  4. Configuring Internet Explorer • Compatibility view • Managing add-ons • Search options • Accelerators • RSS feeds • Printing with IE

  5. Compatibility View

  6. Managing Add-Ons

  7. Configuring Search Options

  8. Configuring Accelerators

  9. Configuring RSS Feeds

  10. Printing with IE

  11. Securing Internet Explorer • Protected Mode • Security Zones • SmartScreen Filter • InPrivate Mode • Pop-Up Blocker • Privacy Settings • Browsing with Certificates

  12. Understanding Protected Mode • Prevents attackers from accessing vital system components • Runs IE with highly reduced privileges • Can only write data to low integrity disk locations, like the Temporary Internet Files folder, and History, Cookies, and Favorites

  13. Configuring Security Zones • Internet • Local intranet • Trusted sites • Restricted sites

  14. Configuring the SmartScreen Filter Warns users of potential phishing Web sites • Online lookup of phishing sites • Online lookup of download sites • Onsite analysis

  15. Using InPrivate Mode Enables you to surf the Internet without leaving any record of your activities • InPrivate Browsing • InPrivate Filtering

  16. Configuring Pop-Up Blocker

  17. Configuring Privacy Settings • Cookie – A file containing information about you or your web-surfing habits • Use privacy settings to limit the ability of Web sites to create cookies

  18. Browsing with Certificates

  19. Configuring application compatibility

  20. Troubleshooting Program Compatibility • Program Compatibility Troubleshooter • Tries to determine why an application is not running properly and gives you two options

  21. Setting Compatibility Modes • Can set compatibility modes manually through the executable’s Properties sheet

  22. Configuring Application Compatibility Policies

  23. Using the Application Compatibility Toolkit • Application Compatibility Manager • Compatibility Administrator • Internet Explorer Compatibility Test tool • Setup Analysis tool • Standard User Analyzer

  24. Application Compatibility Manager

  25. Compatibility Administrator

  26. Internet Explorer Compatibility Test Tool

  27. Setup Analysis Tool • Logging tool to analyze application setup programs for compatibility issues: • Installation of kernel mode drivers • Installation of 16-bit components • Installation of Graphical Identification and Authentication DLLs • Changes to files or registry keys that exist under Windows Resource Protection

  28. Standard User Analyzer

  29. Using Windows XP Mode • Creates a virtual machine running Windows XP on your Windows 7 system • Used for applications that will not run any other way • Free download from Microsoft • Has extensive hardware requirements

  30. Configuring Application Restrictions

  31. Using Software Restriction Policies • Rules that specify which applications users can run

  32. Creating Rules • Certificate rules • Hash rules • Network zone rules • Path rules • Default rule

  33. Configuring Rule Settings • The three possible settings: • Disallow • Basic User • Unrestricted • Most restrictive and secure way is to Disallow all applications and then create Unrestricted rules for the applications you want users to run

  34. Using AppLocker • New feature in Windows 7 Enterprise and Ultimate to create application restrictions more easily • Application Control Policies • Creation of rules is easier - Wizard-based • Only applies to Windows 7 and Windows Server 2008 R2

  35. Understanding Rule Types • Executable rules • Windows Installer rules • Script rules Criteria for resource access: • Publisher • Path • File Hash

  36. Creating Default Rules

  37. Creating Rules Automatically

  38. Creating Rules Manually • Wizard prompts you for the following information: • Action • User or group • Conditions • Exceptions

  39. Skills Summary • Compatibility View, in IE8, enables the browser to display older pages properly. • Add-ons are separate software components that interact with the basic functions of the web browser. • Accelerators enable users to send content to other resources in the form of applications running on the computer or other sites on the Internet. • Protected mode is a way to run Internet Explorer 8 with highly reduced privileges.

  40. Skills Summary (cont.) • A SmartScreen Filter examines traffic for evidence of phishing activity and displays a warning to the user if it finds any. • Security zones have different sets of privileges to provide levels of access. • A gold lock appears in the address bar of IE when a user connects to a secure site (SSL). • In Windows 7, administrators must take measures to ensure the compatibility of their legacy applications.

  41. Skills Summary (cont.) • Application Compatibility Toolkit is for application incompatibilities that are not readily solvable with the Windows 7 compatibility mode settings. • Software restriction policies enable administrators to specify the programs that are allowed to run on workstations. • AppLocker enables administrators to create application restriction rules more easily.
