  1. Post Break Week 4

  2. Coal Comments for Development • Subsidence • Try to produce contours of the amount by which surface areas will subside • Try to impose the subsidence on the surface contours to examine new surface contours • What will have to be modified as part of reclamation to provide drainage or control river courses?

  3. Direct Mining Costs • You are developing manning tables • You will know labor and benefit costs • Eventually you will add your support people • These will be case specific quantified costs • (a much better estimate than a cost curve) • Since you have a lump sum mining cost curve you will have to figure out how to combine high quality estimates with low quality. • Might want to see if info-mine cost models provide assumption guidance • This issue will come up again with ground control, ventilation, outby haulage, and water management where specific cost estimates exceed the quality of a cost curve

  4. Coal Preparation • You need to develop those grade recovery curves for your prep plant • You have coal quality as a function of time for run of mine • You will need to see what quality specs you can meet at what recoveries. • You should also see if you have viable contract markets you can use for coals such as #7 and #6 • Unless you have a contract market for #7 your previous analysis coupled with the drop in spot prices will make #7 uneconomic

  5. Dewatering • The problem of high flow rates • It is common to have high initial flow rates that reduce over time • Your flow rate maximums may be valuable in case for knowing what kind of extra pump capacity you may need if you hit something unexpected. • Info bit on Ground Freezing • AMC mining indicates that where one must cut through major water bearing formations the ground needs to be frozen for a year before cutting through • Ground Freezing by Hans L Jasberger was published by Elsiever on Dec. 2, 2012. A chapter deals with costs of freezing plants • There is also a seminar series on Ground Freezing • This is not a routine cost experienced by every mine

  6. More Dewatering • Calculations to date seem to deal with natural mine inflow • They do not deal with the water you will introduce in water sprays and other such equipment needs • You appear to be picking pumps that can deliver 3000 GPM and 360 ft of head • You appear to know about 300 ft of static lift • How do you know what your friction loss is without knowing your pipe size of material?

  7. Metal Clean-Up • Issues to Address • Take the pit drawings and add the road network with colors to those drawings to make sure the roads match-up • There are also problems with pits not being merged into topo in the same drawing that showed the roads • When you push-back to the side what is the size of the push-back (ie – how many meters do you push-back) • Is the push-back sized to be practical for your equipment? • Get detailed MSReserve reports that show grade, and type of other and other relevant calculations

  8. Cost Data Prep • You now have road configurations and crusher locations for each of your mining phases • Make sure you have haulage plans and mining costs for each phase of your mine • Cost for 25 year 30, 35 year, 40 year, 50 year mine out rate • (you had a version of this previously – it just needs checking and adjusting) • Make sure you have processing costs for 25 year, 30, 35, and 40, 50, 60, and 70 year mining rates • You probably already have this • Check to make sure you know where mining cost ends and processing cost begins • Example who pays the cost of the overland conveyor to the mill – mining or processing?

  9. Block Model • Add variables for value per ton • You will need multiple variables for different conditions • Run MSOPIT storing values per ton back into the block model for the cost rates of the following mine/mill lives • Mine 25 Mill 25 • Mine 25 Mill 30 • Mine 25 Mill 35 • Mine 25 Mill 40 • Mine 25 Mill 50 • Mine 30 Mill 30 • Mine 30 Mill 35 • Mine 30 Mill 40 • Mine 30 Mill 50 • Mine 30 Mill 60 • Mine 35 Mill 35 • Mine 35 Mill 40 • Mine 35 Mill 50 • Mine 35 Mill 60 • Mine 35 Mill 70 • Mine 40 Mill 40 • Mine 40 Mill 50 • Mine 40 Mill 60 • Mine 40 Mill 70 • Using Audit – pick a block in the main ore body and show its value under each scenario • Make sure you have the capital costs for each of these configurations • You will be using this data next week in VALP runs

  10. Write Your Hearts Out • This week writing portions of your final report will be your largest effort
