  1. Product Icons

  2. * * Denotes Product Name in Canada, France

  3. * Denotes Product Name in Canada, France

  4. * * * Denotes Product Name in Canada, France

  5. Security

  6. 1RU 2RU

  7. GENView or other 2RU servers

  8. Other Logos • Professional Services • GENiUS platform

  9. Other Logos

  10. GENApps Icons Unified Multimedia Mobile Life Personal Agent Web Unified Conferencing Voicemail Answer Anywhere MS Office Personal Agent Mobile Unified Fax Visual Messaging Call Grabber IBM Sametime Mobile Office Unified Auto Attendant Conferencing

  11. GENBAND Logotypes – No tagline at this time **Note this logo has thicker rings at the bottom to scale better.

  12. GENBAND Generic Icons September 2010

  13. Usage • Icons should normally reflect supporting elements, GENBAND products should always be the focus and should be shown as a photography always • If you need an icon that is not in this collection, see if it relates to any of the existing icons and rename it • If you still believe a new icon needs to be created, please contact contactgb@genband.com with your requirements • These icons should only be used for non-GENBAND products, use GENBAND product rendering for GENBAND products.

  14. Usage (ii) • Objects can be reflected if necessary, just use the Horizontal Flip tool in PowerPoint • Just remember to keep the elements GROUPED when you do the flip or the figure will not be correct BTS BTS BTS BTS Ungrouped Flip (Each element is flipped independently over its axis) Grouped Flip (the group is treated as a single picture)

  15. Data Icons

  16. Access Aggregation • AN-DLC • DLC • DSLAM • IP DSLAM • RIM • CMUX AN-DLC DLC DSLAM IP DSLAM RIM CMUX

  17. FTTx • FTTx • FTTP • GPON • IPDSLAM FTTx FTTP GPON IPDSLAM

  18. Data Nodes ATM • ATM • PDG • GGSN • SGSN • PDSN • PDG • Media Server • PDIF • SEG Media Server PDF GGSN PDIF SGSN SEG PDSN ATM

  19. CMS • CMS CMS

  20. Database • Database • HLR • HSS • AAA • SDM Database HLR HSS AAA SDM

  21. Traffic and Policy Management • The Magnifying Glass is a separate object in the group, it can be reused to show TPM capabilities in other nodes by ungrouping/copying/pasting TPM

  22. Carrier Routers and Media • Generic Carrier Router • MRFP • BRAS Router MRFP BRAS

  23. Generic CPE • CPE • LAN Switch • Small Router CPE Ethernet Switch Router

  24. Wireless Icons

  25. Antenna • Cell Tower Cell Tower

  26. Wireless Radio Access Network (RAN) • BTS • Node-B • Wireless Base Station BTS Node-B Wireless Base Station

  27. Radio Network Controllers • RNC • BSC RNC BSC

  28. Customer Premises Equipment

  29. Femtocell • Femtocell Femtocell

  30. IAD • IAD • ATA IAD ATA

  31. PBX • PBX • IP-PBX PBX IP PBX

  32. Switches, Gateways, Lines

  33. Switch C5 • C5 Switch • PSTN • Tandem • Local Exchange • C4 Switch PSTN Tandem Local Exchange C4

  34. Softswitch or Application Server • Softswitch • CSCF • I-CSCF • S-CSCF • BCF Softswitch CSCF CSCF I-CSCF S-CSCF BCF

  35. Small Softswitch or Application Server • Softswitch • MGCF • AGCF • MRFC • Controller • Application Server Softswitch MGCF AGCF MRFC Controller Application Server

  36. Gateway • Gateway Gateway

  37. Line Frame Line Frame • Line Frame • Remote • Large OLT Remote Large OLT

  38. Small OLT • OLT • CMTS OLT CMTS

  39. Optical Network Terminal • ONT ONT

  40. Optical Network Unit • ONU ONU

  41. Signaling • SS7 • STP • Signaling Point SS7 STP STP SignalingPoint

  42. Data Line Unit • DLU • LLS DLU LLS

  43. OAM

  44. GenView • GenView GenView EMS

  45. Other Icons

  46. Other Icons 1 Server • Server • Internet • IP • Generic Box • Firewall • Home • Residential User • Laptop • Outdoor Cabinet Outdoor Cabinet Internet IP Firewall Home Residential User
