  1. Graphs

  2. Types of Records One link – For stack and queue. Two links – For double ended queue. Many links:

  3. Order is important

  4. Searching in a Graph A Generic algorithm: Let G=(V,E) be the graph. Let D be a data structure (we’ll later see which one). For unmarked vertex v: VISIT(v) end

  5. VISIT(v) D INSERT(v) While D≠Ø do x REMOVE(D) visit and mark x for all unmarked w adjacent to x do D INSERT(w) end end

  6. Depth-First Search D is LIFO: D PUSH(v) While D≠Ø do x POP(D) visit and mark x for all unmarked w adjacent to x do D PUSH(w) end end A B C E F D

  7. Breadth-First Search D is FIFO: D ENQUEUE(v) While D≠Ø do x DEQUEUE(D) visit and mark x for all unmarked w adjacent to x do D ENQUEUE(w) end end A B C E F D

  8. אינפי 1 לינארית 1 מבוא לחישוב מבני נתונים לינארית 2 אינפי 2 מיון טופולוגי • כידוע יש באוניברסיטה לכל קורס דרישות קדם • נניח שאני מעוניין לקחת קורס אחד לסמסטר • תן אלגוריתם שיגיד איזה קורס לקחת באיזה סמסטר. אינפי 1 לינארית 1 אינפי 2 לינארית 2 מבני נתונים מבוא לחישוב

  9. Algorithm • Topological-Sort() • { • Call DFS to compute finish time for each vertex • Insert vertex finished into the beginning of linked list • Return the linked list of vertices • } • הזמן זהה לחיפוש לעומק והוא O(V+E).

  10. Socks Undershorts Watch Shoes Pants Shirt Belt Tie Jacket Example

  11. Socks Undershorts Watch Shoes Pants Shirt Belt Tie Socks Undershorts Shoes Pants watch Shirt Tie Jacket Belt Jacket Example
