  1. Table of Contents Chapter: Measurement Section 1: Description andMeasurement Section 2: SI Units Section 3: Drawings, Tables, and Graphs

  2. Description and Measurement 1 Measurement • Measurementis a way to describe the world with numbers. • It answers questions such as how much, how long, or how far. • Measurement can describe the amount of milk in a carton, the cost of a new compact disc, or the distance between your home and your school.

  3. Description and Measurement 1 Measurement • In scientific endeavors, it is important that scientists rely on measurements instead of the opinions of individuals. • You would not know how safe the automobile is if this researcher turned in a report that said, “Vehicle did fairly well in head-on collision when traveling at a moderate speed.”

  4. Description and Measurement • In the 1956 summer Olympics, sprinter Betty Cuthbert of Australia came in first in the women’s 200-m dash. 1 Describing Events • Measurement also can describe events.

  5. Description and Measurement • Measurements convey information about the year of the race, its length, the finishing order, and the time. 1 Describing Events • She ran the race in 23.4 s.

  6. Description and Measurement 1 Estimation • Estimation can help you make a rough measurement of an object. • Estimation is a skill based on previous experience and is useful when you are in a hurry and exact numbers are not required.

  7. Description and Measurement 1 Estimation • In many instances, estimation is used on a daily basis. • For example, a caterer prepares for each night’s crowd based on an estimation of how many will order each entrée.

  8. Description and Measurement 1 Using Estimation • You can use comparisons to estimate measurements. • When you estimate, you often use the word about. • For example, doorknobs are about 1 m above the floor, a sack of flour has a mass of about 2 kg, and you can walk about 5 km in an hour.

  9. Description and Measurement 1 Using Estimation • Estimation also is used to check that an answer is reasonable. Suppose you calculate your friend’s running speed as 47 m/s. • Can your friend really run a 50-m dash in 1 s? Estimation tells you that 47 m/s is unrealistically fast and you need to check your work.

  10. Description and Measurement 1 Precision and Accuracy • Precisionis a description of how close measurements are to each other. • Suppose you measure the distance between your home and your school five times and determine the distance to be 2.7 km.

  11. Description and Measurement 1 Precision and Accuracy • Suppose a friend measured 2.7 km on two days, 2.8 km on two days, and 2.6 km on the fifth day. • Because your measurements were closer to each other than your friend’s measurements, yours were more precise.

  12. Description and Measurement 1 Precision and Accuracy • The term precision also is used when discussing the number of decimal places a measuring device can measure. • A clock with a second hand is considered more precise than one with only an hour hand.

  13. Description and Measurement 1 Degrees of Precision • The timing for events has become more precise over the years. • Events that were measured in tenths of a second 100 years ago are measured to the hundredth of a second today.

  14. Description and Measurement • A watch with a second hand is more precise than one with only an hour hand, but if it is not properly set, the readings could be off by an hour or more. Therefore, the watch is not accurate. 1 Accuracy • When you compare a measurement to the real, actual, or accepted value, you are describing accuracy.

  15. Description and Measurement 1 Rounding a Measurement • Suppose you need to measure the length of the sidewalk outside your school. • If you found that the length was 135.841 m, you could round off that number to the nearest tenth of meter and still be considered accurate.

  16. Description and Measurement 1 Rounding a Measurement • To round a given value, follow these steps: • 1. Look at the digit to the right of the place • being rounded to. • If the digit to the right is 0, 1, 2, 3, or 4, the digit being rounded to remains the same. • If the digit to the right is 5, 6, 7, 8, or 9, the digit being rounded to increases by one.

  17. Description and Measurement 1 Rounding a Measurement • 2. The digits to the right of the digit being • rounded to are deleted if they are also to • the right of a decimal. If they are to the • left of a decimal, they are changed to • zeros.

  18. Description and Measurement 1 Precision and Number of Digits • Suppose you want to divide a 2-L bottle of soft drink equally among seven people. • Will you measure exactly 0.285 714 285 L for each person? • No. All you need to know is that each person gets about 0.3 L of soft drink.

  19. Description and Measurement 1 Using Precision and Significant Digits • The number of digits that truly reflect the precision of a number are called the significant digits or significant figures. • Digits other than zero are always significant. • Final zeros after a decimal point (6.545 600 g) are significant. • Zeros between any other digits (507.0301 g) are significant. • Initial zeros (0.000 2030 g) are NOT significant.

  20. Description and Measurement 1 Using Precision and Significant Digits • Zeros in a whole number (1650) may or may not be significant. • A number obtained by counting instead of measuring, such as the number of people in a room or the number of meters in a kilometer, has infinite significant figures.

  21. Description and Measurement 1 Following the Rules • For multiplication and division, you determine the number of significant digits in each number in your problem. The significant digits of your answer are determined by the number with fewer digits.

  22. Description and Measurement 1 Following the Rules • For addition and subtraction, you determine the place value of each number in your problem. The significant digits of the answer are determined by the number that is least precise.

  23. Section Check 1 Question 1 How many oranges can fit inside a given crate? How much rain fell on your town during the last thunderstorm? These are questions of _______.

  24. Section Check 1 Answer The answer is measurement. Measurement is used to answer questions such as: How long? How many? How far?

  25. Section Check 1 Question 2 It isn’t always necessary to know exactly how much or exactly how fast. As a rough way of looking at your data, you can use _______. A. assignation B. estimation C. pagination D. salination

  26. Section Check 1 Answer The answer is B. You can use estimation to get a rough measurement of an object.

  27. Section Check 1 Question 3 Round 1.77 g to the nearest tenth of a gram. Answer The answer is 1.8 grams. The digit in the hundreds column is above 5, so you round up the digit in the tens column.

  28. SI Units 2 The International System • To avoid confusion, scientists established the International System of Units, or SI, in 1960 as the accepted system for measurement.

  29. SI Units 2 The International System • The SI units are related by multiples of ten. • Any SI unit can be converted to a smaller or larger SI unit by multiplying by a power of 10. • The new unit is renamed by changing the prefix.

  30. SI Units 2 The International System

  31. SI Units 2 Length • Length is defined as the distance between two points. • The meter (m) is the SI unit of length. One meter is about the length of a baseball bat.

  32. SI Units • Smaller objects can be measured in centimeters (cm) or millimeters (mm). The length of your textbook or pencil would be measured in centimeters. 2 Length

  33. SI Units 2 A Long Way • To measure long distances, you use kilometers. • Kilometers might be most familiar to you as the distance traveled in a car or the measure of a long-distance race. • The course of a marathon is measured carefully so that the competitors run 42.2 km. • When you drive from New York to Los Angeles, you cover 4,501 km.

  34. SI Units 2 Volume • The amount of space an object occupies is its volume. The cubic meter (m3) is the SI unit of volume.

  35. SI Units 2 Volume • To find the volume of a square or rectangular object, such as a brick or your textbook, measure its length, width, and height and multiply them together.

  36. SI Units 2 Volume by Immersion • Not all objects have an even, regular shape. • When you measure the volume of an irregular object, you start with a known volume of water and drop in, or immerse, the object. • The increase in the volume of water is equal to the volume of the object.

  37. SI Units 2 Mass • The mass of an object measures the amount of matter in the object. • The kilogram (kg) is the SI unit for mass. • You can determine mass with a triple-beam balance. • The balance compares an object to a known mass. Weight and mass are not the same. Mass depends only on the amount of matter in an object.

  38. SI Units 2 Weight • Weight is a measurement of force. • The SI unit for weight is the Newton (N). • Weight depends on gravity, which can change depending on where the object is located.

  39. SI Units 2 Weight • If you were to travel to other planets, your weight would change, even though you would still be the same size and have the same mass. • This is because gravitational force is different on each planet.

  40. SI Units 2 Temperature • The physical property of temperature is related to how hot or cold an object is. • Temperature is a measure of the kinetic energy, or energy of motion, of the particles that make up matter. • Temperature is measured in SI with the Kelvin (K) scale.

  41. SI Units 2 Temperature • The Fahrenheit and Celsius temperature scales are the two most common scales used on thermometers and in classroom laboratories. • The Kelvin scale starts at 0 K. In theory, 0 K is the coldest temperature possible in nature.

  42. SI Units 2 Time and Rates • Time is the interval between two events. • The SI unit of time is the second (s). • Time also is measured in hours (h). • A rate is the amount of change of one measurement in a given amount of time. • One rate you are familiar with is speed, which is the distance traveled in a given time.

  43. Section Check 2 Question 1 If everyone used a different standard of measurement, there would be no way to know how one scientist’s data compared with another scientist’s data. Instead, scientists all use an agreed-upon standard of measurement known as _______.

  44. Section Check 2 A. English standard of measurement B. European standard of measurement C. International system of units D. North American system of units

  45. Section Check 2 Answer The correct answer is C. “SI” is the International System of Units.

  46. Section Check 2 Question 2 If you were measuring a particular mass, for example, a big lump of cookie dough, you would measure it in terms of _______. A. kilograms B. liters C. newtons D. watts

  47. Section Check 2 Answer The answer is A. A kilogram is a unit of mass.

  48. Section Check 2 Question 3 A spring scale can show you how much a baseball mitt weighs, but why might this figure change if you were to weigh the same object on Mars?

  49. Section Check 2 Answer Gravitational pull is different on different planets. The mass of the mitt stays the same no matter where it is, but its weight can change.
