  1. ISDN Integrated Service Digital Network

  2. DEFINISI ISDN Pengembangandarijaringantelepon IDN (Integrated Digital Network ) secara digital untukprosestransformasiinformasidalambentuk : • Suara • Data • Gambar Integrated Service Digital Network

  3. PRINSIP ISDN PrinsipISDN : • Mendukung aplikasi suara dan non-suara • Mendukung aplikasi switched dan nonswitched • Ketergantungan terhadap koneksi 64-kbps • Kecerdasan dalam jaringan • Arsitektur protokol berlapis • Macam-macam Konfigurasi Integrated Service Digital Network

  4. KONSEP DASAR ISDN Integrated Service Digital Network

  5. KEUNTUNGAN ISDN • High Speed & Quality > 10 kali lebihcepatdari PSTN ( > 9,6 Kbps ) • Efficiency Satusaluranuntukberbagaijenislayanan (voice, data dan video) • Flexibility Single interface untuk terminal bervariasi • Cost Effective Teminaltunggaluntuk audio dan video Integrated Service Digital Network

  6. MODEL REFERENSI ISDN Integrated Service Digital Network

  7. USER INTERFACE ISDN • TE1 Contoh : Telepon ISDN; Video phone. • TE2 Contoh : Teleponkonvensional ( terminal a/b ) Terminal X-25. • NT1 Contoh : titikterminasifisik 2 kawatke 4 kawat • NT2Contoh : PABX; LAN • LT LTdapatmembentukfungsi-fungsiseperti NT, test loop, pembangkitansinyaldankonversikode. • ET :Titikterminasijaringanakses dg sentral ISDN dimanasinyalkontroldiproses. Integrated Service Digital Network

  8. USER INTERFACE Integrated Service Digital Network

  9. USER INTERFACE • Network Termination (NT) NT bisaberupa Modem atauperangkatPBX • Terminal Equipment 1 (TE1) Contoh: Telepon digital, Fax G4, Videophone • Terminal Equipment 2 (TE2) Contoh: PC, FAX analog (G3), Teleponanalog • Terminal Adapter (TA) Perangkat interface terminal non-ISDNU-Interface 2-W subscriber line • S/T-Interface 4-wire physical interface, untukkoneksiantara NT dengan TE1 atau NT dengan TA. • R-Interface Physical interface antara TA dengan TE2 Integrated Service Digital Network

  10. STRUKTUR AKSES Integrated Service Digital Network

  11. PERANGKAT CPE ISDN Integrated Service Digital Network

  12. TIPE KANAL AKSES ISDN Integrated Service Digital Network

  13. TIPE KANAL BASIC RATE ACCESS • Model KonfigurasiEropa Model Konfigurasi Amerika Integrated Service Digital Network

  14. TIPE KANAL PRIMARY RATE ACCESS Integrated Service Digital Network

  15. KANAL ISDN • Kanal B • Kanal D • Kanal H Integrated Service Digital Network

  16. DUA KANAL KOMUNIKASI Integrated Service Digital Network

  17. PROTOKOL ISDN Lapis 1 Lapis 2 Lapis 3 Integrated Service Digital Network

  18. KONSEP SERVICE ISDN • Bearer Services • Teleservice • Supplementary Service Integrated Service Digital Network

  19. BEARER SERVICE Integrated Service Digital Network

  20. BEARER SERVICE Paket mode bearer service Integrated Service Digital Network

  21. TELESERVICE Integrated Service Digital Network

  22. TELESERVICE • Aplikasi : • ISDN PC Card • ISDN Router • VCS (Video Conference System) • Home Shopping • Home Banking • Home Medical System (Teledoctor) • Remote Security Control • Internet Access Integrated Service Digital Network

  23. SUPPLEMENTARY SERVICE • Number Identification Supplementary Service • - Direct Dialing In (DDI) • - Multiple Subscriber Number (MSN) • - Calling Line Identification Presentation (CLIP) • - Calling Line Identification Restriction (CLIR) • Call offering Supplementary Service • - Call Transfer (CT) • - Call Forwarding Busy (CFB) • - Call Forwarding No Reply (CFNR) • - Call Forwarding Unconditional (CFU) • - Multiple Access Line Hunting (MA/LH) Integrated Service Digital Network

  24. SUPPLEMENTARY SERVICE • Call completion Supplementary Service • - Call Waiting (CW) • - Call Hold (CH) • Charging Supplementary Service • - Advice of Charge Setup (AoC-S) • - Advice of Charge During (AoC-D) • - Advice of Charge End (AoC-E) • - User to User Signaling (UUS) Integrated Service Digital Network

  25. APLIKASI ISDN Integrated Service Digital Network

  26. APLIKASI ISDN Camera TV Monitor Codec Video Conference System ISDN Switch Video Conference System Integrated Service Digital Network
