  1. Fall 2008

  2. G e l E l e c t r o p h o r e s i s

  3. Electrophoresis is a molecular technique that separates nucleic acids and proteins based on Size and +-+Charge+-+ Shape

  4. DNA is anegativelycharged molecule and therefore is attracted topositive charges.

  5. Agarose provides a matrix through which DNA molecules migrate.• Size – larger molecules move through the matrix slower than small molecules • Concentration – the higher the concentration of agarose, the better the separation of small fragments

  6. How to make an agarose gel…. • Weigh out a specified amount of agarose powder. • Add the correct amount of buffer. • Dissolve the agarose by boiling the solution. • Pour the gel in a casting tray. • Wait for the gel to polymerize.

  7. Plasmid Lambda phage • Vector – DNA source which can replicate and is used to carry foreign genes or DNA fragments. Recombinant DNA – A vector that has taken up a foreign piece of DNA.

  8. Restriction enzyme – an enzyme which binds to DNA at a specific base sequence and then cuts the DNA.

  9. Restriction enzymes are named after the bacteria from which they were isolated. • Bacteria use restriction enzymes to “chop up” foreign viral DNA.

  10. Recognition site – specific base sequence on DNA where a restriction enzyme binds. • All recognition sites are palindromes, which means they read the same way forward and backward. (example: RACECAR or GAATTC CTTAAG • Each restriction enzyme has its own unique recognition site.

  11. After cutting up a long piece of DNA, you can run the samples on an agarose gel. • The smaller fragments migrate further than the longer fragments. • The bands are compared to standard DNA of known sizes. This is often called a DNA marker, or a DNA ladder.

  12. http://207.207.4.198/pub/flash/4/4.html

  13. After analyzing your results, you draw a restriction map of the cut sites. • A restriction map is a diagram of DNA showing the cut sites of a series of restriction enzymes.

  14. Restriction enzymes cut in the middle of the recognition site. • When restriction enzymes cut down the middle of the sequence, blunt ends are generated. Example: GATC GA+TC CTAG CT AG • When restriction enzymes cut in a zig zag pattern, sticky ends are generated. Example: GAATTC G+ AATTC CTTAAG CTTAAG G

  15. Sticky ends are very useful because if two different pieces of DNA are cut with the same restriction enzyme, the overhanging sticky ends will complementarily base pair, creating a recombinant DNA molecule. • DNA ligase will seal the nick in the phosphodiester backbone.

  16. Bacterial Transformation – bacteria take up and express foreign DNA, usually a plasmid. • Plasmid – circular piece of DNA

  17. Steps of Bacterial Transformation • Choose a bacterial host. • E.coli is a model organism. • Well studied • No nuclear membranes • Has enzymes necessary for replication DNA/ Chrom.

  18. Steps of Bacterial Transformation • 2. Choose a plasmid to transform. • Characteristics of a useful plasmid. • Single recognition site • Plasmid only cuts in one place, so this ensures that the plasmid is reformed in the correct order. • Origin of replication • Allows plasmid to replicate and make copies for new cells. • Marker genes • Identifies cells that have been transformed.  gene for antibiotic resistance – bacteria is plated on media with an antibiotic, and only bacteria that have taken up a plasmid will grow  gene that expresses color – bacteria that have taken up a recombinant plasmid are a different color than bacteria that have taken up a NONrecombinat vector.

  19. Steps of Bacterial Transformation • 3. Prepare bacterial cells for transformation of plasmid. • Treat with calcium chloride, which allows plasmid to pass through bacterial cell walls. This is the most common method. • Electroporation - brief electric pulse • Directly inject plasmid into bacterial cell.

  20. Steps of Bacterial Transformation • 4. Plate transformation solution on appropriate media. • Contains nutrients for bacteria. • Contains antibiotic to distinguish transformed bacteria from NONtransformed bacteria. • 5. Incubate plates overnight. • E.coli grows in the human body, • and is therefore incubated at • body temperature (37°C) • 6. Analyze plates. http://www.sumanasinc.com/webcontent/animations/content/plasmidcloning.html

  21. http://www.sumanasinc.com/webcontent/animations/content/dnalibrary.htmlhttp://www.sumanasinc.com/webcontent/animations/content/dnalibrary.html

  22. Chromosome Walking

  23. POLYMERASE CHAIN REACTION "PCR has transformed molecular biology through vastly extending the capacity to identify, manipulate and reproduce DNA. It makes abundant what was once scarce -- the genetic material required for experimentations."

  24. The purpose of PCR is to amplify small amounts of DNA to produce enough for analysis.

  25. Reaction Requirements • Template – starting amount of DNA • Target– segment of DNA you wish to amplify

  26. Reaction Requirements • Primers – short pieces of single stranded DNA that binds to the template DNA. Allows DNA polymerase to to attach and begin replication. 3’-TACGACCCGGTGTCAAAGTTAGCTTAGTCA-5’ 5’-ATGCT-3’ 3’-AGTCA-5’ 5’-ATGCTGGGCCACAGTTTCAATCGAATCAGT-3’

  27. Reaction Requirements • Polymerase – attaches nucleotides to the template. • Taq polymerase is extracted from bacteria that live in hot springs, so they remain active at temperatures up to 90°C. 3’-TACGACCCGGTGTCAAAGTTAGCTTAGTCA-5’ 5’-ATGCTGGGCCACAGTTT-3’ 3’- AAGTTAGCTTAGTCA-5’ 5’-ATGCTGGGCCACAGTTTCAATCGAATCAGT-3’

  28. Reaction Requirements • Magnesium – required for DNA polymerase to work • Nucleotides – needed to make new DNA segments • Buffer – maintain constant pH • Thermocycler – machine that cycles through required temperatures

  29. STEPS: • Heat samples to 90°C for a minute or so to separate double stranded template DNA.

  30. STEPS: 2. Drop temperature to around 50 or 60°C to allow primers to anneal.

  31. STEPS: 3. Maintain temperature at 70°C for a minute or two to allow the polymerase to elongate the new DNA strands.

  32. 4. Repeat denaturation, annealing, and synthesis steps over and over and over. http://www.sumanasinc.com/webcontent/animations/content/pcr.html

  33. PCR amplification is logarithmic, meaning the number of copies is doubled with every cycle. 2n
