1. Clustering High Dimensional Data Using SVM Tsau Young Lin and Tam Ngo Department of Computer Science San José State University

2. Overview • Introduction • Support Vector Machine (SVM) • What is SVM • How SVM Works • Data Preparation Using SVD • Singular Value Decomposition (SVD) • Analysis of SVD • The Project • Conceptual Exploration • Result Analysis • Conclusion • Future Work

3. Introduction • World Wide Web • No. 1 place for information • contains billions of documents • impossible to classify by humans • Project’s Goals • Cluster documents • Reduce documents size • Get reasonable results when compared to humans classification

4. Support Vector Machine (SVM) • a supervised learning machine • outperforms many popular methods for text classification • used for bioinformatics, signature/hand writing recognition, image and text classification, pattern recognition, and e-mail spam categorization

5. Motivation for SVM • How do we separate these points? • with a hyperplane Source: Author’s Research

6. SVM Process Flow Feature Space Input Space Input Space Source: DTREG

7. Convex Hulls Source: Bennett, K. P., & Campbell, C., 2000

8. Simple SVM Example • How would SVM separates these points? • use the kernel trick •  Φ(X1) = (X1, X12) • It becomes 2-deminsional Source: Author’s Research

9. Simple Points in Feature Space • All points here are support vectors. Source: Author’s Research

10. SVM Calculation • Positive: w  x + b = +1 • Negative: w  x + b = -1 • Hyperplane: w  x + b = 0 • find the unknowns, w and b • Expending the equations: • w1x1 + w2x2 + b = +1 • w1x1 + w2x2 + b = -1 • w1x1 + w2x2 + b = 0

11. Use Linear Algebra to Solve w and b • w1x1 + w2x2 + b = +1 •  w10 + w20 + b = +1 •  w13 + w29 + b = +1 • w1x1 + w2x2 + b = -1 •  w11 + w21 + b = -1 •  w12 + w24 + b = -1 • Solution is w1 = -3, w2 = 1, b = 1 • SVM algorithm can find the solution that returns a hyperplane with the largest margin

12. Use Solutions to Draw the Planes Positive Plane: w  x + b = +1 w1x1 + w2x2 + b = +1  -3x1 + 1x2 + 1 = +1  x2 = 3x1 Negative Plane: w  x + b = -1 w1x1 + w2x2 + b = -1  -3x1 + 1x2 + 1 = -1 x2 = -2 + 3x1 Hyperplane: w  x + b = 0 w1x1 + w2x2 + b = 0  -3x1 + 1x2 + 1 = 0 x2 = -1 + 3x1 Source: Author’s Research

13. Simple Data Separated by a Hyperplane Source: Author’s Research

14. LIBSVM and Parameter C • LIBSVM: A Java Library for SVM • C is very small: SVM only considers about maximizing the margin and the points can be on the wrong side of the plane. • C value is very large: SVM will want very small slack penalties to make sure that all data points in each group are separated correctly.

15. Choosing Parameter C Source: LIBSVM

16. 4 Basic Kernel Types • LIBSVM has implemented 4 basic kernel types: linear, polynomial, radial basis function, and sigmoid • 0 -- linear: u'*v • 1 -- polynomial: (gamma*u'*v + coef0)^degree • 2 -- radial basis function: exp(-gamma*|u-v|^2) • 3 -- sigmoid: tanh(gamma*u'*v + coef0) • We use radial basis function with large parameter C for this project.

17. Data Preparation Using SVD • SVM is excellent for text classification, but requires labeled documents to use for training • Singular Value Decomposition (SVD) • separates a matrix into three parts; left eigenvectors, singular values, and right eigenvectors • decompose data such as images and text. • reduce data size • We will use SVD to cluster

18. SVD Example of 4 Documents • D1: Shipment of gold damaged in a fire • D2: Delivery of silver arrived in a silver truck • D3: Shipment of gold arrived in a truck • D4: Gold Silver Truck Source: Garcia, E., 2006

19. Matrix A = U*S*VT Given a matrix A, we can factor it into three parts: U, S,and VT. Source: Garcia, E., 2006

20. U = 0.3966 -0.1282 -0.2349 0.0941 0.2860 0.1507 -0.0700 0.5212 0.1106 -0.2790 -0.1649 -0.4271 0.1523 0.2650 -0.2984 -0.0565 0.1106 -0.2790 -0.1649 -0.4271 0.3012 -0.2918 0.6468 -0.2252 0.3966 -0.1282 -0.2349 0.0941 0.3966 -0.1282 -0.2349 0.0941 0.2443 -0.3932 0.0635 0.1507 0.3615 0.6315 -0.0134 -0.4890 0.3428 0.2522 0.5134 0.1453 S = 4.2055 0.0000 0.0000 0.0000 0.0000 2.4155 0.0000 0.0000 0.0000 0.0000 1.4021 0.0000 0.0000 0.0000 0.0000 1.2302 Using JAMA to Decompose Matrix A Source: JAMA (MathWorks and the National Institute of Standards and Technology (NIST))

21. V = 0.4652 -0.6738 -0.2312 -0.5254 0.6406 0.6401 -0.4184 -0.0696 0.5622 -0.2760 0.3202 0.7108 0.2391 0.2450 0.8179 -0.4624 VT = 0.4652 0.6406 0.5622 0.2391 -0.6738 0.6401 -0.2760 0.2450 -0.2312 -0.4184 0.3202 0.8179 -0.5254 -0.0696 0.7108 -0.4624 Using JAMA to Decompose Matrix A • Matrix A can be reconstructed by multiplying matrices: U*S*VT Source: JAMA

22. U’ = 0.3966 -0.1282 0.2860 0.1507 0.1106 -0.2790 0.1523 0.2650 0.1106 -0.2790 0.3012 -0.2918 0.3966 -0.1282 0.3966 -0.1282 0.2443 -0.3932 0.3615 0.6315 0.3428 0.2522 S’ = 4.2055 0.0000 0.0000 2.4155 Rank 2 Approximation (Reduced U, S, and V Matrices) • V’ = 0.4652 -0.6738 0.6406 0.6401 0.5622 -0.2760 0.2391 0.2450

23. Use Matrix V to Calculate Cosine Similarities • calculate cosine similarities for each document. • sim(D’, D’)=(D’• D’) /(|D’| |D’|) • example, Calculate for D1’: • sim(D1’, D2’) = (D1’• D2’) / (|D1’| |D2’|) • sim(D1’, D3’)=(D1’• D3’) / (|D1’| |D3’|) • sim(D1’, D4’) = (D1’• D4’) / (|D1’| |D4’|)

24. Result for Cosine Similarities • Example result for D1’: sim(D1’, D2’)= ((0.4652 * 0.6406) + (-0.6738 * 0.6401)) = -0.1797 ( (0.4652)2 + (-0.6738)2 ) * ( (0.6406)2 + (0.6401) 2 ) sim(D1’, D3’)= ((0.4652 * 0.5622) + (-0.6738 * -0.2760)) = 0.8727 ( (0.4652)2 + (-0.6738)2 ) * ( (0.5622)2 + (-0.2760)2 ) sim(D1’, D4’)= ((0.4652 * 0.2391) + (-0.6738 * 0.2450)) = -0.1921 ( (0.4652)2 + (-0.6738)2 ) * ( (0.2391)2 + (0.2450)2 ) • D3 returns the highest value, pair D1 with D3 • Do the same for D2, D3, and D4.

25. D1: 3 D2: 4 D3: 1 D4: 2 label 1: 1 3 label 2: 2 4 Result of Simple Data Set • label 1: • D1: Shipment of gold damaged in a fire • D3: Shipment of gold arrived in a truck • label 2: • D2: Delivery of silver arrived in a silver truck • D4: Gold Silver Truck

26. Check Cluster Using SVM • Now we have the label, we can use it to train with SVM • SVM input format on original data: 1 1:1.00 2:0.00 3:1.00 4:0.00 5:1.00 6:1.00 7:1.00 8:1.00 9:1.00 10:0.00 11:0.00 2 1:1.00 2:1.00 3:0.00 4:1.00 5:0.00 6:0.00 7:1.00 8:1.00 9:0.00 10:2.00 11:1.00 1 1:1.00 2:1.00 3:0.00 4:0.00 5:0.00 6:1.00 7:1.00 8:1.00 9:1.00 10:0.00 11:1.00 2 1:0.00 2:0.00 3:0.00 4:0.00 5:0.00 6:1.00 7:0.00 8:0.00 9:0.00 10:1.00 11:1.00

27. Results from SVM’s Prediction Results from SVM’s Prediction on Original Data Source: Author’s Research

28. Using Truncated V Matrix • We want to reduce data size, more practical to use truncated V matrix • SVM input format (truncated V matrix): 1 1:0.4652 2:-0.6738 2 1:0.6406 2:0.6401 1 1:0.5622 2:-0.2760 2 1:0.2391 2:0.2450

29. SVM Result From Truncated V Matrix Results from SVM’s Prediction on Reduced Data Using truncated V matrix gives better results. Source: Author’s Research

30. Vector Documents on a Graph D2 D4 D3 D1 Source: Author’s Research

31. Analysis of the Rank Approximation Cluster Results from Different Ranking Approximation Source: Author’s Research

32. use the previous methods on larger data sets compare the results with that of humans classification Program Process Flow Program Process Flow

33. Conceptual Exploration • Reuters-21578 • a collection of newswire articles that have been human-classified by Carnegie Group, Inc. and Reuters, Ltd • most widely used data set for text categorization

34. Result Analysis Clustering with SVD vs. Humans Classification First Data Set Source: Author’s Research

35. Result Analysis Clustering with SVD vs. Humans Classification Second Data Set Source: Author’s Research

36. Result Analysis • highest percentage accuracy for SVD clustering is 81.5% • lower rank value seems to give better results • SVM predicts about the same accuracy as SVD cluster

37. Result Analysis: Why results may not be higher? • humans classification is more subjective than a program • reducing many small clusters to only 2 clusters by computing the average may decrease the accuracy

38. Conclusion • Showed how SVM works • Explore the strength of SVM • Showed how SVD can be used for clustering • Analyzed simple and complex data • the method seems to cluster data reasonably • Our method is able to: • reduce data size (by using truncated V matrix) • cluster data reasonably • classify new data efficiently (based on SVM) • By combining known methods, we created a form of unsupervised SVM

39. Future Work • extend SVD to very large data set that can only be stored in secondary storage • looking for more efficient kernels of SVM

40. Thank You!

41. References Bennett, K. P., & Campbell, C. (2000). Support Vector Machines: Hype or Hellelujah?. ACM SIGKDD Explorations. VOl. 2, No. 2, 1-13 Chang, C & Lin, C. (2006). LIBSVM: a library for support vector machines, Retrived November 29, 2006, from http://www.csie.ntu.edu.tw/~cjlin/libsvm Cristianini, N. (2001). Support Vector and Kernel Machines. Retrieved November 29, 2005, from http://www.support-vector.net/icml-tutorial.pdf Cristianini, N., & Shawe-Taylor, J. (2000). An Introduction to Support Vector Machines. Cambridge UK: Cambridge University Press Garcia, E. (2006). SVD and LSI Tutorial 4: Latent Semantic Indexing (LSI) How-to Calculations. Retrieved November 28, 2006, from http://www.miislita.com/information-retrieval-tutorial/svd-lsi-tutorial-4-lsi-how-to-calculations.html Guestrin, C. (2006). Machine Learning. Retrived November 8, 2006, from http://www.cs.cmu.edu/~guestrin/Class/10701/ Hicklin, J., Moler, C., & Webb, P. (2005). JAMA : A Java Matrix Package. Retrieved November 28, 2006, from http://math.nist.gov/javanumerics/jama/

42. References Joachims, T. (1998). Text Categorization with Support Vector Machines: Learning with Many Relevant Features. http://www.cs.cornell.edu/People/tj/publications/joachims_98a.pdf Joachims, T. (2004). Support Vector Machines. Retrived November 28, 2006, from http://svmlight.joachims.org/ Reuters-21578 Text Categorization Test Collection. Retrived November 28, 2006, from http://www.daviddlewis.com/resources/testcollections/reuters21578/ SVM - Support Vector Machines. DTREG. Retrived November 28, 2006, from http://www.dtreg.com/svm.htm Vapnik, V. N. (2000, 1995). The Nature of Statistical Learning Theory. Springer-Verlag New York, Inc.
