  1. Embedded IPMI

  2. Agenda • Introduction • Features • KVM and Virtual Media • Software Interface

  3. Introduction • Supermicro’s new Embedded IPMI solution helps save cost and improves reliability • IPMI helps reduce TTM and development cost for cross-platform management • IPMI provides solid foundation for platform management implementations • The IPMI protocol leverages an out-of-band network, which provides a flawless and secure path for mission-critical applications • Provides redundant access to the system for management

  4. Features • Monitors onboard instrumentation (Temperature sensors, Power Status, Voltages, Fan speed, Chassis intrusion • Remote power control (Reset, Shutdown and Power up) • Remote system control through KVM and SOL over LAN • Failover access for redundancy • Configurable Alert destination (Email or SNMP traps) • Virtual Media redirection (Floppy, CD/DVD Drive/image, USB stick) • Soft keyboard

  5. Continued.. • VLAN support • Active directory and Open LDAP Authentication support • SMASH 2.0 and CLP support • WSMAN support • DCMI support • Option to enable secure link through HTTPS • Option to flash FW through Web interface, Windows, Linux and DOS

  6. KVM KVM-over-LAN • Keyboard-video-mouse switches (KVM), connect several computers so that a user can manipulate all of them using just one keyboard, one mouse and one monitor. • As handy as they are, these switches always forced end user to work in a close distances to the servers because of the mouse or keyboard cable length. • Supermicro embedded IPMI support KVM-over-Lan. Authorized users can manage all networked systems with it, no matter how far away.

  7. KVM Virtual Media: • Remote installation of OS • BIOS update, firmware flashing etc from remote location • Data transfer

  8. SOFTWARE • (GUI) IPMIView • (CLI) SMCIPMITool • Web Engine

  9. IPMIview Log-in Event Log Sensors Power control

  10. IPMIview (Contd.) BMC Setting User Settings SOL KVM Console

  11. IPMIview (Contd.) Device Discovering Group Voltage Group Power Control Group General Info

  12. SMCIPMITool Usage: shell Example: D:\>SMCIPMITool 192.168.0.1 ADMIN ADMIN shell Press Ctrl+D or "exit" to exit Press "?" or "help" for help Press TAB for command completion Press UP and DOWN key for command history Usage: ipmi ver Example Output: Firmware Revision = 02.02 IPMI Version = 2.0 Manufacturer ID = C5 28 00 product ID = 04 00 00 OEM Version = 2.2.64 build 5420 OEM Tag = Dec-15-2010-17-15-CMM

  13. Web Engine Log-in Page

  14. Web Engine Home Page Server Health

  15. Web Engine Configuration Remote Control

  16. Web Engine Remote Console
