  1. 2009 Computex Taipei recap Open Platform BG Motherboard Product Dept. ASUSTeK Computer Inc.June 2009

  2. Xtreme Phase / P7P55 PROProduct Overview ofASUS P7P55 Series ~ P7P55 PRO ~ • SPEC • Socket LGA1156 • Intel P55 • Dual DDR3 • Features • Xtreme Phase • TurboV & Turbo Key • EPU • Q-Slot… • Schedule • July/E MP • Sept Launch

  3. Xtreme Phase / P7P55 PROXtreme Phase, Xtra Power! More Phases, More Power!! • Xtreme Phase - Xtra Performance - Xtra Stability - Xtra Cool

  4. HTPC / M4A785G HTPC Create Your Own Home Theater PC • Crystal-clear Audio with Reduced Electronic Noise • The Gateway to Home Entertainment! • Super Silent for Multimedia Enjoyment

  5. HTPC / M4A785G HTPCM4A785G HTPC—Home Theater Gate Your Gateway to Home Entertainment! Integrated media center Large icons and intuitive software—easy to remote control up to 10 feet away With one touch on the remote controller, you can… Launch Home Theater Gate Switch to super silent Tranquil Mode, start music or radio, enable surround mode… Launch DTS Music player Internet Radio Controlling your PC has never been so simple!

  6. HTPC / M4A785G HTPC M4A785G HTPC—Absolute Pitch Hi-Fi Independent Audio Power Connector Leverage the independent power supply concept of professional AV equipments Effectively reduces electronic noises Built-in gold-plated RCA output connectors Compatible with amplifiers Easy and simple to link your PC to the home theater equipment Crystal-clear Audio with Reduced Electronic Noise!

  7. Express Gate / P5Q Turbo0 to Internet in Seconds • ASUS exclusive instant-on solution • Personalized environment and localized Internet services

  8. Express Gate / P5Q TurboExpress Gate Introduction • Instant search on desktop • Regionalized themes (US, UK, Russia, China, & Taiwan) US Russia China Taiwan UK

  9. P6X58 PremiumNext generation storage technology - SATA 6Gb/s & USB3.0 Hyper Speed Enjoyment! Except Extreme Over-Clocking Capability & Rich Features, P6X58 Premium gives you MORE! • SATA 6Gb/s • Up to 2X faster than SATA 3.0Gb/s! • USB3.0 • Up to 10X faster than USB2.0!

  10. P6X58 PremiumSATA 6Gb/s Support! Next Generation Storage Technology • Up to 2Xtransfer rate • Ready for future SPEC: far earlier than Intel’s plan in 2010 or 2011 • Backward compatible with SATA 3Gb/s and SATA 1.5Gb/s standard Check Video!!

  11. P6X58 PremiumSATA 6Gb/s Support! SATA II & SATA III Cable Comparison SATA III onboard chip SATA II SATA III 1 7 SATA III HDD 1 2 2 8 3 6 4 5 3 4 7 5 6 SATA II & SATA III cables share the same looks but different design, SATA III cable has one more pin inside (8 pins). The look is same as SATA II HDD More about SATA III:

  12. Up to 600MB/s, 10X faster transfer rate Backward compatible with USB 2.0 Technology P6X58 PremiumUSB3.0 Support! Tenfold your connectivity & lead your link to the next generation *Source: The presentation materials of 2008 Intel Development Forum

  13. P6X58 PremiumUSB3.0 Support! • More about USB 3.0: USB 3.0 USB 3.0 USB 2.0 USB 2.0 USB 3.0 connector: Same interface as USB 2.0, but with added pins for USB 3.0 signals

  14. Tough Concept Motherboard

  15. Sometimes… Sometimes, your system is too hot… Sometimes, there are more reasons to render your system unstable… Sometimes, your system shuts down due to unexpected blackouts … Sometimes, your system encounters boot up failure due to memory problems…

  16. Hybrid Thermal Solution Hybrid Power Solution Hybrid Memory Solution Hybrid EvolutionConcept Innovations

  17. Which ROG are you?

  18. MemOK! Any memory is A-OK!

  19. GENE Video
