  1. Wheel Alignment Fundamentals Chapter 67

  2. Objectives • Describe each wheel alignment angle • Tell which alignment angles cause wear or pull

  3. Introduction • Correct wheel alignment • Allows vehicle to run straight on the highway • Little steering effort • Minimal tire wear • This chapter deals with principles of different wheel alignment angles

  4. Wheel Alignment Angles • Five wheel alignment angles • Toe • Camber • Caster • Steering axis inclination (SAI) • Turning radius

  5. Toe • Comparison of distances between fronts and rears of a pair of tires • Alignment angle most responsible for tire wear • Toe-in: tires closer together at the front • Every 1/16" of toe-in results in 11 feet per mile scuff • Tires move sideways for 11 feet out of every mile • Toe-out: tires further apart at the front

  6. Toe (cont'd.) • Causes of incorrect toe • Improper adjustment • Bent steering linkage • Change in caster or camber adjustment • Looseness in steering linkage due to wear • Change in toe on one side of the vehicle • Will be split through steering linkage with the wheel on the other side • Front toe: adjustable on all vehicles • Rear toe adjustable on some

  7. Camber • Camber: inward or outward tilt of tire at top • Adjustable on most vehicles • Positive camber: tire tilts out • Negative camber: tire tilts in • Inside and outside edges of tread on cambered tire have different radii • Rotate at different speeds • Camber angle • Controlled by position of control arms or struts • Camber roll: tire tends to roll in a circle

  8. Caster • Caster: forward or rearward tilt of the spindle support arm • Positive caster: top tilted to the rear • Lead point in front of true vertical • Negative caster: steering axis tilts forward • Moving the point of load behind the wheel • Sometimes adjustable on front wheels • Front wheels have different caster settings • Vehicle will pull toward the side with the most negative caster

  9. Steering Axis Inclination • Amount the spindle support arm leans in at top • Not a tire wearing angle • Three functions • After a turn, SAI helps vehicle return to straight • SAI keeps vehicle going straight down the road • Allows car to have less positive caster • Included angle • Combination of SAI and camber • Some cars with large SAI wear outsides of tires

  10. Scrub Radius • Factor of steering axis inclination • Pivot point for front tire’s footprint • Distance at the road surface between centerline of true vertical and steering axis pivot centerline • More scrub radius makes it harder to steer • Positive camber reduces scrub radius

  11. Scrub Radius (cont'd.) • Causes of incorrect scrub radius • Lower profile tires and offset wheel rims • Tires and wheels too tall installed on RWD vehicle • Bent front suspension member • Damage to frame at crossmember

  12. Turning Radius • When turning: outside wheel must travel in wider arc than inside wheel • Turning radius: alignment angle that controls arc traveled • Also called Ackermann angle • Tires toe out during turn • Steering arms are angled inward or outward

  13. Tracking • Wheel base: distance between front and rear tires • Track: side-to-side distance between axle’s tires • All four wheels should form an exact rectangle • Tracking is off: car tries to steer to the side • Front wheels try to follow direction of rear wheels • Dog tracking: rear axle out of line to the right • Causes steering to be aimed to the right

  14. Set-Back • Amount that one front wheel is behind front wheel on other side • Measured in degrees • Negative angle • Wheel on left side is set back • Cause vehicle to steer to left • Cause brake pull

  15. Special Handling Characteristics • Slip angle: during a turn for a tire to continue turning in the same direction • Amount of slip angle depends on: • Weight exerted vertically on the tire • Tire pressure and wheel alignment setting • Positive camber • Understeer: vehicle does not respond to movement of steering wheel during hard turn • Oversteer: vehicle turns too far in response to steering wheel movement
