  1. Advanced OOP MCS-3 OOP BSCS-3Lecture # 9

  2. TOPICS TO COVER Ways of Arranging Components in GUI • Uses Container class setLayout() method from java.awt package • Visual Programming in an IDE • Provides GUI design tool. • Supports drag and drop. • Absolute Positioning • Provides greatest level of control by setting setLayoutmethod to null. But it can be tedious to set absolute positioning. • Methods like setSize, setLocation, andsetBoundsare used. • Layout Managers • FlowLayout • BorderLayout • GridLayout

  3. TOPICS TO COVER FlowLayout class (java.awt.FlowLayout) • Default for javax.swing.JPanel • Components are placed from left to right in order they are added. • Automatically places components onto next row, if row is full. • FlowLayout() • FlowLayout(int) // alignment Row positioning options • FlowLayout.LEFT • FlowLayout.RIGHT • FlowLayout.CENTER (default) • void setAlignment(int) // alignment • intgetAlignment()

  4. TOPICS TO COVER BorderLayout class (java.awt.BorderLayout) • Default for javax.swing.JFrame • Arranges components in five regions • Places upto five components in a container one in each region. • Automatically displaces previous component, if component is already occupied in the position. • BorderLayout() • BorderLayout(int, int) // horizontal gap, vertical gap Regions • BorderLayout.NORTH • BorderLayout.SOUTH • BorderLayout.EAST • BorderLayout.WEST • BorderLayout.CENTER

  5. TOPICS TO COVER GridLayout class (java.awt.GridLayout) • Divides container into a grid so that components can be placed in rows and columns. • Each component has same width and height. • GridLayout() • GridLayout(int, int) // rows, columns • GridLayout(int, int, int, int) // rows, columns, horizontal gap, vertical gap • intgetColumns() • intgetHgap() • intgetRows() • intgetVgap() • void setColumns(intcols) • void setHgap(inthgap) • void setRows(introws) • void setVgap(intvgap)

  6. Color java.awt.Color • Color.BLACK • Color.BLUE • Color.CYAN • Color.DARK_GRAY • Color.GRAY • Color.GREEN • Color.LIGHT_GRAY • Color.MAGENTA • Color.ORANGE • Color.PINK • Color.RED • Color.WHITE • Color.YELLOW

  7. Color Color • Color(int, int, int) // red, green, blue ranging from 0 to 255 • Color brighter() • Color darker() • intgetRed() • intgetGreen() • intgetBlue() JColorChooser class in javax.swing.JColorChooser • Color showDialog(Component, String, Color) //component, title of dialogbox, initial color

  8. Good Luck ! ☻. . .
