Understanding Line Segments and Their Distances in Geometry

This guide explores line segments, defined as parts of a line consisting of two endpoints and all points in between. We explain how to calculate the distance between two points using their coordinates, exemplified by the formula AB = |x2 - x1|. The segment addition postulate is also detailed, illustrating relationships between points on a line. Examples, including real-life applications like distances between cities, reinforce the concepts taught. Engage in practice exercises to solidify understanding of segments and congruence.

gore
Télécharger la présentation

Understanding Line Segments and Their Distances in Geometry

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Line Segments Section 1.3 Sol:G.4c

  2. Line Segment • Is a part of a line that consists of two points, called endpoints, and all the points between. • Symbolized by: • Distance: The distance between the points A and B written as AB is the absolute value of the difference of the coordinates of x1 and x2. Denoted: AB = |x2 – x1| Name of Points A B x1 x2 Coordinates

  3. Ex: Find the Distance

  4. Segment addition Postulate • If B is between A and C, then AB + BC = AC. • If AB + BC = AC, Then B is between A and C. A B C

  5. Example 99 miles Bismarck Dickenson Fargo 289 miles The cities shown on the map lie approximately in a straight line. Use the given distances to find the distance from Bismarck to Fargo.

  6. Try These:1. 380 miles 360 miles Lubbick Tulsa St. Louis What is the distance from Lubbick to St. Louis?

  7. 36 F G H 2. Use the diagram to Find GH 3. Find y, then find PQ and QR. 21 3y+1 Q P R 2y 21

  8. Try These: Solve for x, then find UT and TS1. 5x - 3 7x U T S 45

  9. Congruent Segments • Line segments that have the same length / measure. • Ex: A B D C AB= CD Equal AB CD Congruent

  10. Example: Find X and ST if S is between R and T • RS = 12, ST = 2x, RT = 34 • RS = 16, ST = 2x, RT = 5x + 10

  11. Assignments Classwork: Workbook Pg 11-12 1-20 even 27,28. Homework: Pg 23-25 1-5, 7,12,14,16,19,20,27,37,38,39
