  1. Introduction toBayesian Belief Nets Russ Greiner Dep’t of Computing Science Alberta Ingenuity Centre for Machine Learning University of Alberta http://www.cs.ualberta.ca/~greiner/bn.html

  2. Motivation • Gates says [LATimes, 28/Oct/96]: Microsoft’s competitive advantages is its expertise in “Bayesian networks” • Current Products • Microsoft Pregnancy and Child Care (MSN) • Answer Wizard (Office 95, Office 2000) • Print Troubleshooter Excel Workbook Troubleshooter Office 95 Setup Media Troubleshooter Windows NT 4.0 Video Troubleshooter Word Mail Merge Troubleshooter

  3. Motivation (II) • US Army:SAIP(Battalion Detection from SAR, IR… GulfWar) • NASA: Vista(DSS for Space Shuttle) • GE: Gems(real-time monitor for utility generators) • Intel: (infer possible processing problems from end-of-line tests on semiconductor chips) • KIC: • medical: sleep disorders, pathology, trauma care, hand and wrist evaluations, dermatology, home-based health evaluations • DSS for capital equipment: locomotives, gas-turbine engines, office equipment

  4. Motivation (III) • Lymph-node pathology diagnosis • Manufacturing control • Software diagnosis • Information retrieval • Types of tasks • Classification/Regression • Sensor Fusion • Prediction/Forecasting

  5. Outline • Existing uses of Belief Nets (BNs) • How to reason with BNs • Specific Examples of BNs • Contrast with Rules, Neural Nets, … • Possible applications of BNs • Challenges • How to reason efficiently • How to learn BNs

  6. Symptoms Blah blah ouch yak ouch blah ouch blah blah ouch blah Chief complaint History, … Signs Physical Exam Test results, … Plan Diagnosis Treatment, …

  7. Objectives: Decision Support System • Determine • which tests to perform • which repairto suggest based on costs, sensitivity/specificity, … • Use all sources of information • symbolic (discrete observations, history, …) • signal(from sensors) • Handle partial information • Adapt to track fault distribution

  8. Underlying Task • Approach1: Use set of obs1 & … & obsm  Dxirules but… Need rule for each situation • for each diagnosis Dxr • for each set of possible values vj for Oj • for each subset of obs. {Ox1, Ox2, … }  {Oj} • Can’t use if only know Temp and BP If Temp>100 & BP = High & Cough = Yes  DiseaseX • Situation: Given observations {O1=v1, … Ok=vk} (symptoms, history, test results, …) what is best DIAGNOSIS Dxi for patient? • Seldom Completely Certain

  9. Underlying Task, II • Approach 2: Compute Probabilities of Dxi given observations { obsj } P( Dx = u | O1= v1, …, Ok= vk ) • Situation: Given observations {O1=v1, … Ok=vk} (symptoms, history, test results, …) what is best DIAGNOSIS Dxi for patient? • Challenge: How to express Probabilities?

  10. How to deal with Probabilities P( Dx=T, O1=T, O2=T, …, ON=T ) = 0.03 P( Dx=T, O1=T, O2=T, …, ON=F ) = 0.4 … P( Dx=T, O1=F, O2=F, … , ON=T ) = 0 … P( Dx=F, O1=F, O2=F, …, ON=F ) = 0.01  • Then:Marginalize: P( Dx = u, O1= v1,…,Ok= vk ) = ΣP( Dx = u , O1= v1 , …, Ok= vk, …, ON= vN ) Conditionalize: P( Dx = u | O1 = v1,…, Ok = vk) P( Dx = u, O1 = v1,…,Ok = vk ) P( O1 = v1,…,Ok = vk) P( Dx = u, O1=v1,..., Ok= vk,…, ON=vN ) • Sufficient: “atomic events”: for all 21+N values u {T, F}, vj{T, F} • But… even if binary Dx, 20 binary obs.’s.  >2,097,000 numbers!

  11. Problems with “Atomic Events” Belief Nets  • Representation is not intuitive  Should make “connections” explicit use “local information” P(Jaundice | Hepatitis), P(LightDim | BadBattery),… • Too many numbers – O(2N) • Hard to store • Hard to use • [Must add 2r values to marginalize r variables] • Hard to learn • [Takes O(2N) samples to learn 2N parameters]  Include only necessary “connections”

  12. ? Hepatitis? ? Hepatitis, not Jaunticed but +BloodTest ? Jaunticed BloodTest

  13. Hepatitis Example • J B H P(J, B, H) • 0 0 0 0.03395 • 0 0 1 0.0095 • 0 1 0 0.0003 • 0 1 1 0.1805 • 1 0 0 0.01455 • 0 1 0.038 • 1 0 0.00045 • 1 1 1 0.722 Option 1: …Marginalize/Conditionalize, to get P( H=1 | J=0, B=1 ) … H Hepatitis J Jaundice B (positive) Blood test • (Boolean) Variables: • Want P( H=1 | J=0, B=1 ) • …, P(H=1 | B=1, J=1), P(H=1| B=0,J=0), … • Alternatively…

  14. Encoding Causal Links P(H=1) P(H=0) H 0.05 0.95 h P(B=1 | H=h) P(B=0 | H=h) B 1 0.95 0.05 0 0.03 0.97 h b P(J=1|h,b) P(J=0|h,b) J 1 1 0.8 0.2 1 0 0.8 0.2 0 1 0.3 0.7 0 0 0.3 0.7 • Simple Belief Net: • Node ~ Variable Link ~ “Causal dependency” • “CPTable” ~ P(child | parents)

  15. Encoding Causal Links H B J • P(J | H, B=0) = P(J | H, B=1)  J, H !P( J | H, B) = P(J | H) • J is INDEPENDENT of B, once we know H • Don’t need B J arc!

  16. Encoding Causal Links H B J • P(J | H, B=0) = P(J | H, B=1)  J, H !P( J | H, B) = P(J | H) • J is INDEPENDENT of B, once we know H • Don’t need B J arc!

  17. Encoding Causal Links H B J • P(J | H, B=0) = P(J | H, B=1)  J, H !P( J | H, B) = P(J | H) • J is INDEPENDENT of B, once we know H • Don’t need B J arc!

  18. Sufficient Belief Net H B J P(B=1 | H=1) Hence: P(H=1 | J=0, B=1) = P(H=1) P(J=0 | H=1) P(B=1 | J=0,H=1) • Requires: P(H=1) known • P(J=1 | H=1) known • P(B=1 | H=1) known • (Only 5 parameters, not 7)

  19. “Factoring” H • but… ONLY THROUGH H: • If know H=1, then likely that B=1 • … doesn’t matter whether J=1 or J=0 ! •  B J P(B=1 | J=0, H=1) = P(B=1 | H=1) • Bdoes depend on J: • If J=1, then likely that H=1 B =1 N.b., BandJ ARE correlated a priori P(B | J )  P(B) GIVEN H, they become uncorrelatedP(B | J, H) = P(B | H)

  20. Factored Distribution H Hepatitis J Jaundice B (positive) Blood test P( B | J ) P ( B ) but P( B | J,H ) = P ( B | H ) Age ShoeSize Reading • Symptoms independent, given Disease • ReadingAbility and ShoeSize are dependent, P(ReadAbility | ShoeSize ) P(ReadAbility ) • but become independent, given Age • P(ReadAbility | ShoeSize, Age ) = P(ReadAbility | Age)

  21. “Naïve Bayes” P(H = hi ) P(Oj = vj | H = hi) Independent: P(Oj | H, Ok,…) = P(Oj | H) H • Given ... O1 O2 On • Classification Task: Given {O1 = v1, …, On = vn } Findhi that maximizes (H = hi | O1 = v1, …, On = vn) • Find argmax {hi}

  22. Naïve Bayes (con’t) • If kDx’s and nOis, • requires only k priors, n * k pairwise-conditionals • (Not 2n+k… relatively easy to learn) n 1+2n 2n+1 – 1 10 21 2,047 H 30 61 2,147,438,647 ... O1 O2 On • Normalizing term (No need to compute, assame for allhi) • Easy to use for Classification • Can use even if some vjs not specified

  23. Bigger Networks GeneticPH LiverTrauma Hepatitis Jaundice Bloodtest • If GeneticPH, then expect Jaundice: GeneticPH Hepatitis Jaundice • But only via Hepatitis: GeneticPH and not Hepatitis Jaundice • P( J | D ) P( J ) but • P( J | D,H ) = P( J | H) • Intuition: Show CAUSAL connections: GeneticPH CAUSES Hepatitis; Hepatitis CAUSES Jaundice

  24. Belief Nets D I • Given H = 1, • - D has no influence on J • - J has no influence on B • - etc. H J B • DAG structure • Each node  Variable v • v depends (only) on its parents + conditional prob: P(vi | parenti = 0,1,… ) • vis INDEPENDENT of non-descendants, given assignments to its parents

  25. Less Trivial Situations P(FHD=1) FHD 0.001 f P(MS=1 | FHD=f) 1 0.10 MS f m P(D=1 | FHD=f, MS=m) 0 0.03 1 1 0.97 1 0 0.90 D 0 1 0.08 0 0 0.04 • N.b., obs1 is not always independent of obs2 given H • Eg, FamilyHistoryDepression ‘causes’ MotherSuicide and Depression MotherSuicide causes Depression (w/ or w/o F.H.Depression) • Here, P( D | MS, FHD ) P( D | FHD ) ! • Can be done using Belief Network, • but need to specify: • P( FHD ) 1 • P( MS | FHD ) 2 • P( D | MS, FHD ) 4

  26. Example: Car Diagnosis

  27. MammoNet

  28. ALARM • A Logical Alarm Reduction Mechanism • 8 diagnoses, 16 findings, …

  29. Troup Detection

  30. ARCO1: Forecasting Oil Prices

  31. ARCO1: Forecasting Oil Prices

  32. Forecasting Potato Production

  33. Warning System

  34. Extensions • Find best values (posterior distr.) for SEVERAL (> 1) “output” variables • Partial specification of “input” values • onlysubset of variables • only “distribution” of each input variable • General Variables • Discrete, but domain > 2 • Continuous (Gaussian: x = i bi yifor parents {Y} ) • Decision TheoryDecision Nets(Influence Diagrams) Making Decisions, not just assigning prob’s • Storing P( v | p1, p2,…,pk)General “CP Tables” 0(2k) Noisy-Or, Noisy-And, Noisy-Max “Decision Trees”

  35. Outline • Existing uses of Belief Nets (BNs) • How to reason with BNs • Specific Examples of BNs • Contrastwith Rules, Neural Nets, … • Possible applications of BNs • Challenges • How to reason efficiently • How to learn BNs

  36. Belief Nets vs Rules • Oftensame nodes(rep’ning Propositions) but BN: Cause  Effect “Hep  Jaundice” P(J | H ) Rule: Effect  Cause “Jaundice  Hep” • Both have “Locality” Specific clusters (rules / connected nodes) WHY?: Easier for people to reason CAUSALLY even if use is DIAGNOSTIC • BN provide OPTIMAL way to deal with • + Uncertainty • + Vagueness (var not given, or only dist) • + Error • …Signals meeting Symbols … • BN permits different “direction”s of inference

  37. Belief Nets vs Neural Nets • Both have “graph structure” but BN: Nodes have SEMANTICs Combination Rules: Sound Probability NN: Nodes: arbitrary Combination Rules: Arbitrary • So harder to • Initialize NN • Explain NN (But perhaps easier to learn NN from examples only?) • BNs can deal with • Partial Information • Different “direction”s of inference

  38. Belief Nets vs Markov Nets • Technical: BNs use DIRECTRED arcs •  allow “induced dependencies” • I (A, {}, B) “A independent of B, given {}” • ¬ I (A, C, B) “A dependent on B, given C” A B C A • MNs use UNDIRECTED arcs •  allow other independencies • I(A, BC, D) A independent of D, given B, C • I(B, AD, C) B independent of C, given A, D B C D • Each uses “graph structure” to FACTOR a distribution … explicitly specify dependencies, implicitly independencies… • but subtle differences… • BNs capture “causality”, “hierarchies” • MNs capture “temporality”

  39. Uses of Belief Nets #1 • Medical Diagnosis: “Assist/Critique” MD • identify diseases not ruled-out • specify additional tests to perform • suggest treatments appropriate/cost-effective • react to MD’s proposed treatment • Decision Support: Find/repair faults in complex machines [Device, or Manufacturing Plant, or …] … based on sensors, recorded info, history,… • Preventative Maintenance: Anticipate problems in complex machines [Device, or Manufacturing Plant, or …] …based on sensors, statistics, recorded info, device history,…

  40. Uses (con’t) • Logistics Support: Stock warehouses appropriately…based on (estimated) freq. of needs, costs, • Diagnose Software:Find most probable bugs, given program behavior, core dump, source code, … • Part Inspection/Classification:… based on multiple sensors, background, model of production,… • Information Retrieval: Combine information from various sources, based on info from various “agents”,… General: Partial Info, Sensor fusion -Classification -Interpretation -Prediction -…

  41. Challenge #1Computational Efficiency • For given BN: • General problem is • Given • Compute • + If BN is “poly tree”,  efficient alg. • - If BN is gen’l DAG (>1 path from X to Y) • - NP-hard in theory • - slow in practice • Tricks: Get approximate answer (quickly) • + Use abstraction of BN • + Use “abstraction” of query (range) O1 = v1, …, On = vn D I P(H | O1 = v1, …, On = vn) H J B

  42. # 2a:Obtaining Accurate BN • BN encodes distribution over n variables • Not O(2n) values, but “only” i 2k_i • (Node ni binary, with kiparents) • Still lots of values! …structure .. • Qualitative Information • Structure: “What depends on what?” • Easy for people (background knowledge) • But NP-hard to learn from samples… • Quantitative Information • Actual CP-tables • Easy to learn, given lots of examples. • But people have hard time… Knowledge acquisition: from human experts Simple learning algorithm

  43. Notes on Learning structure values • Just Learning Algorithm: algorithms that • learn from sample • Mixed Sources: Person provides structure; Algorithm fills-in numbers. • Just Human Expert: People produce CP-table, as well as structure • Relatively few values really required • Esp. if NoisyOr, NoisyAnd, NaiveBayes, … • Actual values not that important • …Sensitivity studies

  44. My Current Work • Learning Belief Nets • Model selection: Challenging myth that MDL is appropriate criteria • Learning “performance system”, not model • Validating Belief Nets “Error bars” around answers • Adaptive User Interfaces • Efficient Vision Systems • Foundations of Learnability • Learning Active Classifiers • Sequential learners • Condition Based maintenance, Bio-signal interpretation, …

  45. # 2b: Maintaining Accurate BN • The world changes. Information in BN*may be • perfect at time t • sub-optimal at time t + 20 • worthless at time t + 200 • Need to MAINTAIN a BN over time using on-going human consultant • Adaptive BN • Dirichlet distribution (variables) • Priors over BNs

  46. Conclusions • Belief Nets are PROVEN TECHNOLOGY • Medical Diagnosis • DSS for complex machines • Forecasting, Modeling, InfoRetrieval… • Provide effective way to • Represent complicated, inter-related events • Reason about such situations • Diagnosis, Explanation, ValueOfInfo • Explain conclusions • Mix Symbolic and Numeric observations • Challenges • Efficient ways to use BNs • Ways to create BNs • Ways to maintain BNs • Reason about time

  47. Extra Slides • AI Seminar • Friday, noon, CSC3-33 • Free PIZZA! • http://www.cs.ualberta.ca/~ai/ai-seminar.html • References http://www.cs.ualberta.ca/~greiner/bn.html • Crusher Controller • Formal Framework • Decision Nets • Developing the Model • Why Reasoning is Hard • Learning Accurate Belief Nets

  48. References • http://www.cs.ualberta.ca/~greiner/bn.html • Overview textbooks: • Judea Pearl, Probabilistic Reasoning in Intelligent Systems: Networks of Plausible Inference, Morgan Kaufmann, 1988. • Stuart Russell and Peter Norvig, Artificial Intelligence: A Modern Approach, Prentice Hall, 1995. (See esp Ch 14, 15, 19.) • General info re BayesNets • http://www.afit.af.mil:80/Schools/EN/ENG/LABS/AI/BayesianNetworks • Proceedings: http://www.sis.pitt.edu/~dsl/uai.html • Assoc for Uncertainty in AI http://www.auai.org/ • Learning: • David Heckerman, A tutorial on learning with Bayesian networks, 1995, • http://www.research.microsoft.com/research/dtg/heckerma/TR-95-06.htm • Software: • General: http://bayes.stat.washington.edu/almond/belief.html • JavaBayes http://www.cs.cmu.edu/~fgcozman/Research/JavaBaye • Norsys http://www.norsys.com/

  49. Decision Net: Test/Buy a Car
