Guidelines for Signal Degrade Detection in MPLS-TP Networks

haile avatar
haile
9 diapositives · 221 Views · Oct 04, 2014

This draft outlines necessary guidelines for detecting signal degradation in MPLS-TP networks for effective protection triggering. It highlights the importance of a carrier view, proposing an SD detection strategy originating from the server MEP sub-layer. Key elements include ensuring detection methods do not disrupt services, are insensitive to various traffic characteristics, and can identify low Bit Error Rate (BER) conditions. The document further suggests a new "Link Condition Indication" message for communicating degradation events and discusses its implications for protection switching.

#guidelines for signal degrade detection in mpls-tp networks #guidelines for signal degrade detection in mpls-tp networks ppt #powerpoint #presentation
Guidelines for Signal Degrade Detection in MPLS-TP Networks - slide 1
01 / 9Guidelines for Signal Degrade Detection in MPLS-TP Networks
1 / 17

Télécharger la présentation

Guidelines for Signal Degrade Detection in MPLS-TP Networks
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. draft-rkhd-mpls-tp-sd-00 IETF 78 July 2010 Rafi Ram (rafir@orckit.com) Masahiro Daikoku (ms-daikoku@kddi.com)

  2. Problem Statement • Provide carrier view guide lines for signal degrade detection for protection triggering • Suggest SD detection approach originating from server MEP sub-layer • Provide end-to-end view on architecture of : • Signal degrade detection • Signal degrade condition notification • Signal degrade consideration in protection switching

  3. Guide Lines for SD Detection (1) • Method MUST not disrupt the forwarded services • e.g. add delay or jitter to real time traffic • Criterion for determining signal degrade MUST be agnostic to : • Length and rate of frames transmitted • Traffic class and drop precedence marking of frames • Link congestion level

  4. Guide Lines for SD Detection (2) • Method SHOULD be able to detect low BER condition • Method SHOULD have low miss-detection and false alarm probabilities • Method SHOULD be agnostic to number of LSPs or PWs forwarded over the link • Method for determining signal degrade is RECOMMENDED not to require transmission of traffic exclusively dedicated for this purpose

  5. Examples for SD Detection Methods • 1GE PCS : Measurement of rate of 10bit code violations and dispersion errors • 10GE PCS : Measurement of rate of errored 66bit block headers • Note : These examples work as long as the layer carrying the information used for SD detection is not terminated in between two MPLS-TP transport entities

  6. SD Condition Notification • A server MEP identifying SD condition should advertise this condition to the MPLS entity handling the protection • Propose addition of a new fault message type “Link Condition Indication” (LCI) • The LCI message can have the following impairment flags : (1) Link performance is reduced (i.e. signal degraded) (2) Link is congested (3) Link rate is reduced Note : Using the existing LDI for conveying SD may have the following drawbacks : 1. It does not allow the flexibility to report of various impairment conditions 2. Need to differentiate between “link down” condition (equivalent to SF) and “link reduced” (equivalent to SD), since for APS state machine SF has higher priority than SD

  7. SD Consideration for Protection Switching • SD has a lower protection priority than SF-W, but higher than MS • SD-P and SD-W have similar protection priority : • If SD-P occurs firstand then SD-W, there is no change of state • If SD-W occurs firstand then SD-P, there is no change of state

  8. Next Steps • Add section of SD BER for various transport technologies and applications • Address any comments • Republish

  9. Questions ? Comments ?
