  1. Not to scale Use hazard lights when parked in road. Bucknell Road Tanks are interconnected to give these combined capacities Drive straight in to use depot pumps - A Reverse to use vehicle pump - B Tank No. Product Capacity (ltrs) 1 Derv 105, 011 CCTV/Alarm control Pad and light 1 Derv 2 Gas Oil 157, 484 Tanker discharge area 2 Gas Oil 2 Gas Oil 3 Kero 296, 947 3 Kero Loading gantry shed Offices 3 Kero Barrier Fuelmaster ullage/alarm control panel 4 Kero Kerb Store Depot stripper pump start/stop switches A Tank 4 Storage area Discharge header arrangement: B Tank 3 Tank 1 Tank 2 Tank 2 Tank 3 Tank 2 Tank 3 Tank 1 A - Kero 3/4 Gas Oil 2 Derv 1 B - Gas Oil 2 Derv 1 Kero 3/4 x NOLAN OILS MIDDLETON STONEY DEPOT BASE PLAN (for absentee delivery purposes only) Issue date: June 2005 Oil interceptor Emergency shut-off valve Stream DRIVERS ARE ONLY PERMITTED TO BE WITHIN THE KERBED AREA OF THE YARD IN THE VICINITY OF THEIR VEHICLE, THE DISCHARGE HEADERS OR GATES WHILST ON SITE. ALL OTHER AREAS ARE OUT- OF-BOUNDS EXCEPT IN AN EMERGENCY. EMERGENCY NUMBERS ARE:- 01869 342116 or 07860 427893
