  1. Building RESTful Services using WCF Jon Flanders http://www.rest-ful.net/ INT303

  2. About Me • Jon Flanders – http://www.rest-ful.net/ • Independent consultant/trainer • BizTalk MVP

  3. Storytime: Once upon time…

  4. REST • Representational State Transfer • introduced by Roy Fielding • Architectural style • A set of constraints distilled from the architecture of the Web • URIs represent resources • Clients interact via with resources via a uniform interface (GET, POST, PUT, DELETE) • Services are stateless

  5. Why should you care? Microsoft Live Services .NET Services More to come from Microsoft and others – but why let them have all the fun (and rewards)? ADO.NET Data Services EVERYBODY that isn’t Microsoft (Twitter,Google, Yahoo, Facebook, MySpace)

  6. REST Advantages • GET responses can be cached • Using URIs build on experience using the Web • Uniform interface simplifies building and using services • Statelessness constraint eases scalability • GET is safe, can be called N times without causing change • PUT and DELETE are idempotent (same effect no matter how many times called)

  7. Building a RESTful service • Design your resource(s) • Determine the URI for each resource • Determine what part of the uniform interface each resource should implement

  8. Uniform Interface

  9. Windows Communication Foundation (WCF) • Framework for building applications that communicate • Client-Server • Message oriented • Service oriented • WCF abstracts away network complexities, developer concentrates on code • Most of WCF is highly geared toward SOAP • REST support added in 3.5 and improved in 3.5 sp1

  10. WCF Messages to Methods • In WCF developers write methods in classes that respond to network messages • SOAP support in 3.0/3.5 routes messages to methods based on SOAP Action • URI always the same • Always uses POST • Done by the default dispatcher

  11. WCF 3.5 Web Programming • Messages are routed to methods based on: • URI • HTTP Verb • Same programming model as “SOAP” • ServiceContract, OperationContract, DataContract • New dispatcher that maps URIs/Verbs to methods

  12. WCF 3.5 REST infrastructure • UriTemplate & UriTemplateTable • URI parsing • WebGet & WebInvoke attributes • UriTemplate defines URI • WebGet + UriTemplate maps GET requests to methods • WebInvoke + UriTemplate maps remainder of uniform interface to methods , Method property determines verb (POST is default) • WebHttpBinding/WebServiceHost/WebServiceHostFactory • Eases use and configuration

  13. WCF Dispatching Network Transport Channel Transport Channel (HTTP) Message Message Encoder Message Encoder (Text + No SOAP) Protocol Channel (1-N) Dispatcher (URI + VERB) Dispatcher (Action) Your Code

  14. AJAX Support • Many RESTful clients are JavaScript based AJAX clients • JavaScript Object Notation (JSON) is the preferred resource representation • Smaller footprint than XML • No parsing necessary • WCF has support for AJAX applications at two levels • JSONDataContractSerializer for JSON parsing and generation • JavaScript “proxy” build on ASP.NET AJAX

  15. Web Feeds • Web Feeds are endpoints that expose machine consumable resource representations • Commonly used for web logs (blogs), news etc. • Expansion into enterprise data is happening

  16. WCF support for Feeds • Built on top of WCF REST support (WebGet/UriTemplate) • Feed specific feature is feed-format neutral object model • Transform your data into the WCF OM • OM serialized to either RSS or Atom (or other future formats – extensible formatting capabilities) • OM is closer to Atom model (Atom is richer than RSS)

  17. Know the rules, bend when necessary • “…REST isn’t an all or nothing proposition.  One can get significant value from partial adoption. “ Sam Ruby - Author RESTFul Web Services Don’t underestimate the power of GET!

  18. Summary • REST is an architectural style that encourages interoperable, scalable web services • Builds on the existing architecture of the web • WCF 3.5 adds support for this architecture

  19. Complete an evaluation on CommNet and enter to win an Xbox 360 Elite!
