  1. ETSI ERM

  2. ETSI ERM • Task Group activities ERM has a number of task groups which are set up on a short-term basis to deal with particular issues, and which disband on the resolution of the task.  • Aeronautical radio (TG25) • Maritime radio (TG26) • Standardisation of land-mobile radio, including • Wideband data systems (TG11) • Generic short-range devices (TG28) • Ultra Wide Band (UWB) for telecommunications and radiolocations activities (TG31A) • Now TG UWB • RF Identification Devices (TG34) • Harmonised Standards for IMT-2000 equipment (TFES) • Automotive, including UWB radar (TG31B) and UWB Sensors (TG31C) • Now TG SRR • Wireless medical devices (TG30) • Broadcast and ancillary equipment (TG17) • Radio Site Engineering (TG27) • Measurement Uncertainty (TG33) • Intelligent Transport Systems (TG37)

  3. ETSI TC ERM Legend Aeronautical mobile service Maritime mobile service Land mobile service Broadcasting service Short Range Devices Horizontal topic f.k.a. – TG 31

  4. ERM ETSI TR 102 649-1 (v1.1.1 – 2007-04) • Electromagnetic compatibility and Radio spectrum Matters (ERM); Technical characteristics of RFID in the UHF Band; System Reference Document for Radio Frequency Identification (RFID) equipment; Part 1: RFID equipment operating in the range from 865 MHz to 868 MHz ETSI TR 102 649-2 (v1.1.1 – 2008-09) • Electromagnetic compatibility and Radio spectrum Matters (ERM); Technical characteristics of Short Range Devices (SRD) and RFID in the UHF Band; System Reference Document for Radio Frequency Identification (RFID) and SRD equipment; Part 2: Additional spectrum requirements for UHF RFID, non-specific SRDs and specific SRDs

  5. ETSI ERM • ETSI ERM is a "horizontal" technical committee that is responsible for the standardization of electromagnetic compatibility (EMC) and radio spectrum matters on behalf of all other technical bodies of ETSI. • ETSI TC ERM is responsible for 75% of standards being developed under the Radio and Telecommunications Terminal Equipment (R&TTE) Directive (1999/5/EC). • The work of ETSI ERM can be considered in three main areas • Electromagnetic Compatibility • The Electromagnetic Compatibility (EMC) working group is responsible for all ETSI Harmonised Standards related to the EMC Directive (89/336/EEC) and article 3.1b of the R&TTE Directive (1999/5/EC). This group is also responsible for liaison on behalf of ETSI with CENELEC on EMC issues and with CISPR. • Radio Spectrum Matters • The Radio Matters (RM) working group is responsible for co-operation with the European Radiocommunications Committee (ERC) to secure appropriate spectrum allocations in the CEPT countries for standardised systems, in order to ensure co-existence between different communications systems standardised by ETSI.

  6. ERM TG11 (Wideband Data Systems) EN 300 328 (2.4 GHz ISM Band) (Revision) • Title Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband transmission systems; Data transmission equipment operating in the 2,4 GHz ISM band and using wide band modulation techniques; Harmonized EN covering essential requirements under article 3.2 of the R&TTE Directive, Wideband transmission systems in 2,4 GHz • Scope and Field of Application • Amend the scope of the standard as instructed by TCAM26 • Include detailed requirements and test methods for the MAC as instructed by TCAM26 • Exclude UWB from the scope of standard • Improve test methods for MIMO • Clarify antenna types • Define channel separation for FH systems in function of the number of Hopping Position, • Next meeting 22-24 June 2009

  7. ERM TG28 (Generic SRDs) EN 300 220-1 (25 MHz – 1 000 MHz) (v2.3.1 – 2009-04) • Electromagnetic compatibility and Radio spectrum Matters (ERM); Short Range Devices (SRD); Radio equipment to be used in the 25 MHz to 1 000 MHz frequency range with power levels ranging up to 500 mW; Part 1: Technical characteristics and test methods EN 300 220-2 (25 MHz – 1 000 MHz) (v2.3.1 – 2009-04) • Electromagnetic compatibility and Radio spectrum Matters (ERM); Short Range Devices (SRD); Radio equipment to be used in the 25 MHz to 1 000 MHz frequency range with power levels ranging up to 500 mW; Part 2: Harmonized EN covering essential requirements under article 3.2 of the R&TTE Directive EN 300 330-1 (25 MHz – 1 000 MHz) (v1.6.2 – 2009-03) • Electromagnetic compatibility and Radio spectrum Matters (ERM); Short Range Devices (SRD); Radio equipment in the frequency range 9 kHz to 25 MHz and inductive loop systems in the frequency range 9 kHz to 30 MHz; Part 1: Technical characteristics and test methods EN 300 330-2 (25 MHz – 1 000 MHz) (v1.4.1 – 2009-03) • Electromagnetic compatibility and Radio spectrum Matters (ERM); Short Range Devices (SRD); Radio equipment in the frequency range 9 kHz to 25 MHz and inductive loop systems in the frequency range 9 kHz to 30 MHz; Part 2: Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directives

  8. ERM TG28 (Generic SRDs) EN 300 440-1 (25 MHz – 1 000 MHz) (v1.5.1 – 2009-03) • Electromagnetic compatibility and Radio spectrum Matters (ERM); Short range devices; Radio equipment to be used in the 1 GHz to 40 GHz frequency range; Part 1: Technical characteristics and test methods EN 300 440-2 (25 MHz – 1 000 MHz) (v1.3.1 – 2009-03) • Electromagnetic compatibility and Radio spectrum Matters (ERM); Short range devices; Radio equipment to be used in the 1 GHz to 40 GHz frequency range; Part 2: Harmonized EN covering essential requirements of article 3.2 of the R&TTE Directives

  9. ERM TG34 (RFID Devices) EN 302 208-1 (865 – 868 MHz) (v1.2.1 – 2007-07) • Electromagnetic compatibility and Radio spectrum Matters (ERM); Radio Frequency Identification Equipment operating in the band 865 MHz to 868 MHz with power levels up to 2 W; Part 1: Technical requirements and methods of measurement EN 302 208-1 (865 – 868 MHz) (Revision) • §8.3.3 - The beamwidth(s) of the antenna(s) in the horizontal orientation shall comply with the following limits: • For transmissions 500 mW e.r.p. there shall be no restriction on beamwidth. • For transmissions of >500 mW e.r.p. to  1000 mW e.r.p. beamwidths shall be  180º. • For transmissions of >1000 mW e.r.p. to 2 000 mW e.r.p. beamwidths shall be  90º. • §10 – Rewritten for compliance to ERC Recommendation 74-01 and by the request of WGSE • CEPT/ERC/RECOMMENDATION 74-01E Unwanted Emissions in the Spurious Domain

  10. International Coalescence (900 – 930 MHz)

  11. ERM TG UWB (Ultra Wideband) EN 302-500-1 (v1.2.1 – 2008-06) • A Electromagnetic compatibility and Radio spectrum Matters (ERM); Short Range Devices (SRD) using Ultra WideBand (UWB) technology; Location Tracking equipment operating in the frequency range from 6 GHz to 8,5 GHz; Part 1: Technical characteristics and test methods EN 302-500-2 (v1.2.1 – 2008-06) • Electromagnetic compatibility and Radio spectrum Matters (ERM); Short Range Devices (SRD) using Ultra WideBand (UWB) technology; Location Tracking equipment operating in the frequency range from 6 GHz to 8,5 GHz; Part 2: Harmonized EN covering essential requirements of article 3.2 of the R&TTE Directive

  12. ERM TG UWB (Ultra Wideband) ETSI TR 102 495-3 (v1.3.1 – 2008-02) • Electromagnetic compatibility and Radio spectrum Matters (ERM); System Reference Document; Short Range Devices (SRD); Technical characteristics for SRD equipment using Ultra Wide Band Sensor technology (UWB); Part 3: Location tracking applications type 1 operating in the frequency band from 6 GHz to 8,5 GHz for indoor, portable and mobile outdoor applications ETSI TR 102 495-5 (v1.1.1 – 2009-01) • Electromagnetic compatibility and Radio spectrum Matters (ERM); System Reference Document; Short Range Devices (SRD); Technical characteristics for SRD equipment using Ultra Wide Band Sensor technology (UWB); Part 5: Location tracking applications type 2 operating in the frequency bands from 3,4 GHz to 4,8 GHz and from 6 GHz to 8,5 GHz for person and object tracking and industrial applications

  13. ERM TG SRR (Automotive and Surveillance Radar) ETSI TR 102 495-4 (v1.3.1 – 2008-02) • System Reference Document; Short Range Devices (SRD); Technical characteristics for SRD equipment using Ultra Wide Band Sensor technology (UWB); Part 4: Object identification for surveillance applications operating in the frequency band from 2,2 GHz to 8 GHz

  14. ETSI UWB Sensor Applications Location Tracking Building Material Analysis and Classification (BMA) Object Discrimination and Characterizat. (ODC) Object Identificat. for Surveillance (OIS) Object Detection for mobile, construction, agriculture and off-road applications GPR / WPR EN 302 066 Published 10 / 2005 TR 102 495 - 1 EN 302 435 Published 05 / 2008 TR 102 495 - 2 EN 302 498 under work TR 102 495 - 4 EN 302 499 under work TR 102 495 - 6 EN 302 XXX under work Type 1 Type 2 Outdoor / fixed LAES Ad hoc emergency tracking networks LTT (for traffic applications) TR 102 495 - 3 EN 302 500 Published 02 / 2007 Rev: 06 / 2008 TR 102 496 EN 302 XXX under work TR 102 495 - 5 EN 302 501 under work TR 102 495 - 7 EN 302 XXX under work

  15. ???

  16. Thank you!!! Craig K. Harmon, President & CEO Q.E.D. Systems 3963 Highlands Lane, SE Cedar Rapids, IA 52403-2140 USA (V): +1 319/364-0212 (M): +1 319/533-8092 (E): craig.harmon@qed.org (U): http://www.autoid.org
