Wave Motion

Wave Motion. A wave is a disturbance that carries energy through matter or space. What Is a Wave?. What Is a Wave?. Most waves travel through a medium. medium: a physical environment in which phenomena occur Air – Water - Etc

hlarkin
Télécharger la présentation

Wave Motion

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Wave Motion

  2. A wave is a disturbance that carries energy through matter or space. What Is a Wave?

  3. What Is a Wave?

  4. Most waves travel through a medium. • medium:a physical environment in which phenomena occur • Air – Water - Etc • mechanical wave:a wave that requires a medium through which to travel • examples: sound waves, water waves What Is a Wave?

  5. Electromagnetic waves do not require a medium. • electromagnetic wave: a wave that consists of oscillating electric and magnetic fields, which radiate outward at the speed of light • examples: visible light waves, radio waves What Is a Wave?

  6. Electromagnetic Waves

  7. Waves transfer energy. • Small or Large amounts Depending on Type and Size • Tsunamis carry enough energy to cause damage to coastal towns. • The energy of normal ocean waves breaks up rocks into pieces to form sandy beaches. What Is a Wave?, continued

  8. Tsunami

  9. Energy may spread out as a wave travels. • When sound waves travel in air, the waves spread out in spheres. • As the waves travel outward, the spherical wave fronts get bigger, so the energy spreads out over a larger volume. What Is a Wave?

  10. How are waves generated? • Most waves are caused by vibrating objects. • The sound waves produced by a singer are caused by vibrating vocal cords. • Electromagnetic waves may be caused by vibrating charged particles. • For mechanical waves, the particles in the medium through which the wave passes vibrate, too. Vibrations and Waves

  11. The mechanical energy of a vibrating mass-spring system changes form. • This type of vibration is called simple harmonic motion. Vibrations and Waves

  12. A wave can pass through a series of vibrating objects. • The disturbance travels down the row as energy is transferred from one mass to another. • Wave particles move like masses on springs. Vibrations and Waves

  13. A transverse wave is a wave in which the wave motion is perpendicular to the particle motion. A longitudinal wave is a wave in which the wave motion is parallel to the particle motion. Transverse and Longitudinal Waves

  14. Transverse waves have perpendicular motion. • transverse wave: a wave in which the particles of the medium move perpendicularly to the direction the wave is traveling

  15. Transverse Wave

  16. Longitudinal waves have parallel motion. • longitudinal wave: a wave in which the particles of the medium vibrate parallel to the direction of wave motion

  17. Longitudinal Wave

  18. Waves have crests and troughs or compressions and rarefactions. crest:the highest point of a wave trough: the lowest point of a wave compressions:the crowded areas of a longitudinal wave rarefactions: the stretched-out areas of a longitudinal wave

  19. The particles in a surface wave move both perpendicularly and parallel to the direction in which the wave travels. • surface waves:waves that occur at the boundary between two different mediums, such as water and air Surface Waves

  20. Formation and Movement of Ocean Waves
