circle

circle. Jeff Bivin -- LZHS. Circle. The set of all points equidistant from a fixed point (center). radius. Jeff Bivin -- LZHS. Circle. Equation: x 2 + y 2 = r 2 ( x – h ) 2 + (y – k ) 2 = r 2. r. (h, k). Jeff Bivin -- LZHS.

holmes-hull
Télécharger la présentation

circle

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. circle Jeff Bivin -- LZHS

  2. Circle The set of all points equidistant from a fixed point (center). radius Jeff Bivin -- LZHS

  3. Circle Equation: x 2 + y2 = r2 (x – h)2 + (y – k)2 = r2 r (h, k) Jeff Bivin -- LZHS

  4. Derive equation of circle • https://www.khanacademy.org/math/geometry/cc-geometry-circles/equation-of-a-circle/v/equation-for-a-circle-using-the-pythagorean-theorem

  5. Circle x 2+ y 2= 16 center r = (0, 0) 16 r = 4 4 (0, 0) Jeff Bivin -- LZHS

  6. Circle (x – 3)2 + (y – 5)2 = 121 x – 3 = 0 r = 121 x = 3 r = 11 11 y – 5 = 0 (3, 5) y = 5 center (3, 5) Jeff Bivin -- LZHS

  7. Circle (x + 5)2 + (y – 2)2 = 81 center r = 81 r = 9 ( -5 , 2 ) 9 (-5, 2) Jeff Bivin -- LZHS

  8. Graph the following circle: x2+ 4x + y2- 2y - 10 = 1 x2+ 4x + y2- 2y = 1+ 10 x2+ 4x + y2- 2y = 11 (x2 + 4x + 22 ) + (y2 - 2y + (-1)2 ) = 11 + 4 + 1 (x + 2)2 + (y - 1)2 = 16 Jeff Bivin -- LZHS

  9. Circle (x + 2)2 + (y – 1)2 = 16 r = center 16 r = 4 4 (-2, 1) (-2, 1) Jeff Bivin -- LZHS

  10. Circle r = center 16 r = 4 (-2, 1) 4 (x + 2)2 + (y – 1)2 = 16 (-2, 1) Intercepts: x-int: (Plug 0 in for y) y-int: (Plug 0 in for x) (x + 2)2 + (y – 1)2 = 16 (x + 2)2 + (y – 1)2 = 16 (0 + 2)2 + (y – 1)2 = 16 (x + 2)2 + (0 – 1)2 = 16 4 + (y – 1)2 = 16 (x + 2)2 + 1 = 16 (y – 1)2 = 12 (x + 2)2 = 15 y – 1 = ±√12 x + 2 = ±√15 y = 1 ±2√3 x = -2 ± √15 y = 4.46 or -2.46 x = -5.87 or 1.87

  11. Graph the following circle 4x2 + 24x + 4y2 + 32y + 13 = 157 4x2 + 24x + 4y2 + 32y = 157 - 13 4x2 + 24x + 4y2 + 32y = 144 4 (x2 + 6x + 32 ) + (y2 + 4y + 22 ) = 36 + 9 + 4 (x + 3)2 + (y + 2)2 = 49 Jeff Bivin -- LZHS

  12. Circle r = (x + 3)2 + (y + 2)2 = 49 center 49 r = 7 (-3, -2) x-int: (Plug 0 in for y) y-int: (Plug 0 in for x) 7 (x + 3)2 + (y + 2)2 = 49 (0 + 3)2 + (y + 2)2 = 49 (x + 3)2 + (0 + 2)2 = 49 9 + (y + 2)2 = 49 (x + 3)2 + 4 = 49 (y + 2)2 = 40 (x + 3)2 = 45 (-3, -2) y + 2 = 40 ±√ x + 3 = ±√ 45 y = -2 ±2√10 x = -3 ±3√5 x = 3.71 or -9.71 y = 4.32 or -8.32 Jeff Bivin -- LZHS

  13. Graph the following circle: 5x2 - 80x + 5y2 + 20y - 34 = 106 5x2 - 80x + 5y2 + 20y = 106 + 34 5x2 - 80x + 5y2 + 20y = 140 5 (x2 - 16x + 42 ) + (y2 + 4y + 22 ) = 28 + 16 + 4 (x - 4)2 + (y + 2)2 = 48 Jeff Bivin -- LZHS

  14. Circle (x - 4)2 + (y + 2)2 = 48 center r = 48 r = 4 3 4 3 (4, -2) (4, -2) Jeff Bivin -- LZHS
