Properties of Polygons: Polygons, Parallelograms, and Rhombuses

hortonw avatar
hortonw
65 diapositives · 710 Views · Jan 02, 2020

Learn about polygons, parallelograms, and rhombuses, including their definitions, properties, and theorems. Explore how to identify and prove these shapes using coordinates and angle measures.

#properties of polygons: polygons, parallelograms, and rhombuses #properties of polygons: polygons, parallelograms, and rhombuses ppt #powerpoint #presentation
Properties of Polygons: Polygons, Parallelograms, and Rhombuses - slide 1
01 / 65Properties of Polygons: Polygons, Parallelograms, and Rhombuses
1 / 17

Télécharger la présentation

Properties of Polygons: Polygons, Parallelograms, and Rhombuses
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. Chapter 6 Notes

  2. 6.1 – Polygons

  3. Poly  Many A polygon is a plane figure that meets the following conditions: 1) It is formed by three or more segments called sides such that no two sides with a common endpoint are collinear. 2) Each side intersects exactly two other sides, one at each endpoint.

  4. Names of polygons # of sides Name 3 Triangle 4 Quadrilateral 5 Pentagon 6 Hexagon 8 Octagon 10 decagon 12 dodecagon n n-gon When naming polygons, you list the vertices in order! R P T E L B Hexagon PRTBLE Or Hexagon TBLEPR Or other names

  5. Convex  A polygon such that no line containing a side of a polygon contains a point in the interior of the polygon.

  6. Equilateral  Sides are the same. Equiangular  Angles are the same. Regular  Both

  7. Is it a polygon? If so, name it and say if it is convex or concave. Diagonal – Segment that joins two nonconsecutive vertices

  8. Interior angles of a Quadrilateral The sum of the measures of the interior angles of a quadrilateral is 360o. Solve for x xo xo x+20o x+20o 2xo 2xo 100o 100o

  9. (3x + 2)o (2x – 10 )o (x + 5)o (2x – 7)o

  10. 6.2 – Properties of Parallelograms

  11. Definition of a parallelogram  Both pairs of opposite sides are parallel. A D M C B

  12. Find all information A D M C B

  13. x + 24 z 65 y 4x – 12

  14. zo 7y wo 9q + 4 3y + 28 xo 30o 30o write

  15. Proving Theorem 6.2 A D B C

  16. C B F A D E

  17. X C B 1 E F Y 2 A D Z

  18. 6.3 – Proving Quadrilaterals are Parallelograms

  19. Opposite sides are parallel, then it’s a ||-gram by def. S 3 T 2 1 R 4 Q THRM 6.6 If both pairs of opposite sides of a quad are congruent, then the quadrilateral is a parallelogram. THRM 6.8, If an angle of a quad is supplementary to both its consecutive angles, then the quadrilateral is a ||- gram THRM 6.7 If both pairs of opposite angles of a quadrilateral are congruent, then the quadrilateral is a ||-gram THRM 6.9 If the diagonals of a quad bisect each other, then the quadrilateral is a ||-gram

  20. Let’s discuss how to prove two of these theorems S 3 T 2 1 R 4 Q THRM 6.6 If both pairs of opposite sides of a quad are congruent, then the quadrilateral is a parallelogram. M THRM 6.9 If the diagonals of a quad bisect each other, then the quadrilateral is a ||-gram

  21. THRM 6.10, If one pair of opposite sides are both CONGRUENT and PARALLEL, then the quadrilateral is a ||-gram S 3 T 2 M 1 R 4 Q Yes parallelogram, not a parallelogram, and why?

  22. Prove that the following coordinates make a parallelogram by the given theorems\definitions using slope formula and distance formula. A B (-1, 3) (3, 2) D C (-4, -1) (0, -2) Opposite sides are parallel, then it’s a ||-gram by def. One pair of opposite sides are both CONGRUENT and PARALLEL. The diagonals of a quad bisect each other

  23. Do these points make a parallelogram? (0,2) (-3,1) (-2, 3) (1,4) Do these points make a parallelogram? (-1,-3) (-2, 1) (2, 2) (1, -3)

  24. 6.4 – Rhombuses, Rectangles, and Squares

  25. Rectangle – Quad with 4 rt angles. Rhombus – Quad with 4 congruent sides Square – 4 rt angles AND 4 congruent sides, It’s a rectangle AND a rhombus!! Why are these parallelograms?

  26. World O’ Parallelograms Answer with always, sometimes, or never A Rhombus is a Square Always Sometimes Never A Square is a Parallelogram Always Sometimes Never

  27. Corollaries Rhombus Corollary A quadrilateral is a rhombus iff it has four congruent sides. Rectangle Corollary A quadrilateral is a rectangle iff it has four right angles. Square Corollary  A quadrilateral is a square iff it is a rhombus and a rectangle.

  28. A D M B C A B D C Thrm 6.11  A ||-gram is a rhombus iff its diagonals are perpendicular. Thrm 6.12  A ||-gram is a rhombus iff each diagonal bisects a pair of opposite angles.

  29. Thrm 6.13  A ||-gram is a rectangle iff its diagonals are congruent. A D B C Prove this theorem. Stuwork

  30. Which shape could it be? • What can be true about it?

  31. Solve for x and y. Given the figure is a rectangle, Solve for x and y. 2y + 35 70o xo 2y + 16 (2x + 5)o 4y – 10 5y – 10 Stuwork

  32. Solve for x and y. Given the figure is a square, Solve for x and y. 55o A B xo 10 yo 5 y D C AC = 4x – 10 BD = 2x + 2 Stuwork

  33. A ||-gram is a rectangle iff its diagonals are congruent. We’ll now prove this using coordinate proof A D B C ( , ) ( , ) ( , ) ( , ) Stuwork

  34. Well do some coordinate proof stuff with rhombus, rectangles, and squares added on.

  35. 6.5 – Trapezoids and Kites

  36. A quadrilateral with EXACTLY one pair of parallel sides is called a TRAPEZOID. The parallel sides are called BASES. The other sides are LEGS Trapezoids have two pairs of base angles. ISOSCELES TRAPEZOID – LEGS are CONGRUENT! KITE – A quadrilateral with two pairs of consecutive sides, BUT opposite sides aren’t congruent.

  37. Theorem 6.14  Base angles of an isosceles trapezoid are congruent. B A X Y Z ONLY TRUE FOR ISOS TRAPEZOID, NOT REGULAR TRAPEZOID! Congruent, opp sides ||-gram congruent. Transitive to work all sides congruent. Corresponding, base angles thrm, transitive. Same side interior angles, measure, supp, subtraction.

  38. Theorem 6.15 If a trapezoid has one pair of congruent base angles, then it’s an isosceles trapezoid. A B D C A B D C Theorem 6.16 A trapezoid is isosceles iff its diagonals are congruent.

  39. A B b1 E midsegment F D C b2 Just like in a triangle, the midsegment will go through the midpoint of the legs.

  40. A A B B 10 x E F D D C C 18 12 15 E F y

  41. A B z 11 E F D C A B 14 D C 14 2x+2 7y-10 5y+10

  42. 13 Write in x 19 y z A B R D C AD = 15 AR = 6 BC = _____ BR = __ RC = ____ RD = __

  43. 55 y 22 44 x 45 z

  44. C Theorem 6.18 If a quadrilateral is a kite, then its diagonals are perpendicular B D A Theorem 6.18 If a quadrilateral is a kite, then EXACTLY one pair of opposite angles are congruent. C B D A

  45. C B D A C B D A x 12 5 60o 140o zo yo

  46. C B D A C B D A 25 24 x zo 100o 70o yo

  47. Go Over HW • Verify Quadrilateral while HW checked • Properties of shapes of Parallelogram, Rhombus, Rectangle, Square • Discuss what’s on quiz

  48. 6.6 – Special Quadrilaterals

  49. Quad-Tree-Laterals
