    1. Everything Copper Wing Eng WE2583@att.com Principal Product Development Engineer AT&T Common Systems 2600 Camino Ramon San Ramon, CA 94593 (925)823-4616

    2. Product Responsibilities DSX-1, DSX-3 Panels and Bays DS1 & DS3 Patch Cords and Cross Connect Cords DS1 & DS3 Connectors DS1 & DS3 Tools DSL Frame wires Ethernet (CAT5 and CAT6) Cables and Connectorized Assemblies BITS Timing Cables and Connectorized Assemblies 2

    3. Todays Presentation Ethernet Cable Color and Ethernet Distribution Frame Exceptions ATT-NOTICE-000-003-989 Migration from ADCs DSX-1 (D1M series) to ADCs DSX-1 (DSXi series) Products ATT-TELCO-NOTICE-000-004-312 ATT-TELCO-PAN-COMMONSYSTEMS-2010-0011 Upcoming BNC Coaxial Connector RFQ 3

    4. Ethernet Cable Color and Ethernet Distribution Frame Exceptions ATT-NOTICE-000-003-989, Issue 1, 10-15-10 Ethernet cables will normally be manufactured and deployed with gray-colored outer jackets and Ethernet circuits will normally be cabled to an intermediate Ethernet Distribution Frame. This document details exceptions to the use of gray-colored outer jackets and Ethernet Distribution Frames. The following exceptions to deployment of Gray-Only-Outer Jackets of Ethernet Cable Deployment of Ethernet Circuits involving an Ethernet Distribution Frame are: 4

    5. Ethernet Cable Color and Ethernet Distribution Frame Exceptions ATT-NOTICE-000-003-989, Issue 1, 10-15-10 Gray-Only-Outer Jackets of Ethernet Cable Mobility Outer cable jackets of Ethernet cables will be Green for Console/Network Elements, Red for OAM Management and Blue for Traffic IPTV (VHO) Outer cable jackets of Ethernet cables will be Blue for Video and Gray for Out of Band/Network Management Deployment of Ethernet Circuits involving an Ethernet Distribution Frame VOIP No Ethernet Distribution Frame required / Circuits direct cabled between Network Elements 5

    6. Migration from ADCs DSX-1 (D1M Series) to ADCs DSX-1 (DSXi Series) Products ATT-TELCO-NOTICE-000-004-312 (Issue 4, 02/15/11) ATT-TELCO-PAN-COMMONSYSTEMS-2010-0011 (Issue 5, 04/08/11) 6

    7. Upcoming BNC Coaxial Connector RFQ This upcoming BNC Coaxial Connector RFQ will consider brand-name connectors as well as clones of brand-name connectors. We do not anticipate any changes in tooling used by OTVs to crimp their regional connectors. 7
