  1. Precision Mechanical Springs

  2. Our History • Founded in 1958 • Celebrating 50 Years in 2008 • Original Location in West Allis • Moved to Muskego in 1986 • LuAnn Lanke began working at WCS in 19?? • ISO 9001: 2000 Certified in 2003 • LuAnn Lanke Became President in 2006 New Building Photo Here

  3. Precision Mechanical Springs • Compression Springs • Extension Springs • Torsion Springs • Wire Forms and Flat Forms • Using Music Wire or Any Specialty Wire You Choose • From .004” up to .275” (special applications up to .343”)

  4. The WiCoil Way Wisconsin Coil Spring makes precision mechanical springs to your specifications, delivered anywhere you tell us, anytime you tell us. The WiCoil Way is really Your Way. Step 1 We start by studying your drawing, analyzing the cycle life of the spring, the functional tolerances on loads, rates, and both outside and inside diameters Photo of Larry & Roger at a desk or table

  5. The WiCoil Way Step 2 We meet with you to review the spring design, and we recommend the best material and finish. All at the least possible cost

  6. The WiCoil Way Step 3 Then our engineers and senior springmakers collaborate on creating your perfect spring – within 3 days! Photo of Larry, Derek, Roger, John, Dan looking over a blueprint

  7. The WiCoil Way Step 4 We put your spring through a battery of tests to be sure it’s just right before seeking your final approval

  8. The WiCoil Way Step 5 We order the wire (if we don’t have it in stock) and, as soon as it arrives, start producing your springs on sophisticated computer numerical control (CNC) machines

  9. The WiCoil Way Step 6 Your spring is baked, checked for accuracy, and packaged to your specifications, then shipped to your door in three weeks or less

  10. Equipment • CNC Coilers (Wafios, Fenn Torin, Aim, Itaya, Asahi-Seiki) • Mechanical Coilers (Fenn Torin, Sleeper-Hartley, Mec) • 4-Slides (Wafios, Baird, Multi-Slides) • In-Line Ovens and Batch Ovens (Pyromaitre, JN, Furnase) • Grinding Machines (Dorn, Besley, Moyer) • Air Presses, Punch Presses, Hydraulic Presses

  11. Quality Assurance • Comparators from Optical to Quadra Checks • Electronic Spring Gages on CNC Coilers • Electronic/Laser Position Probes to hold angularity • Electronic Testers from 600 grams to 1,000 lbs. • ISO 9001: 2000 Certified

  12. A Commitment to the Future • Over $2 Million in New Investment • New CNC Coilers (Four) • New Grinders • New Ovens • New Computer Software • New Office Upgrade • New Dedication to Our Customers

  13. WISCONSIN COIL SPRING Where The WiCoil Way is Your Way. We want to be your partner in manufacturing your precision mechanical springs and wire forms

  14. Precision Mechanical Springs Made Your Way, the WiCoil Way
