Sequencing algorithms for multiple machines. Operations scheduling , Nahmias. Sequencing Algorithms for multiple machines. Assume that n jobs are to be processed through m machines . The number of possible schedule is staggering, even for moderate values of both n and m .

#sequencing algorithms for multiple machines #sequencing algorithms for multiple machines ppt #powerpoint #presentation
Sequencing algorithms for multiple machines - slide 1
01 / 9Sequencing algorithms for multiple machines
1 / 17

Télécharger la présentation

Sequencing algorithms for multiple machines
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. Sequencingalgorithmsformultiplemachines Operationsscheduling, Nahmias

  2. Sequencing Algorithms for multiple machines • Assume that njobs are to be processed through mmachines. • The number of possible schedule is staggering, even for moderate values of both n and m. • For each machine there are n! different ordering of the jobs. • If the jobs may be processed on the machines in any order, it follows that there are (n!)mpossible schedules. • For example, for n=5 and m=5, there are 24,833x1010 , possible schedules.

  3. 2 jobs-2 machines Example Mean Idle Time Mean Flow Time Total Flow Time (or Makespan) Machine 1 I J Machine 2 I J 9 (5+9)/2= 7 (4+4)/2= 4 4 5 9 Machine 1 J I J I Machine 2 6 (5+6)/2=5.5 (1+1)/2=1 1 5 6 Machine 1 I J Machine 2 I J 1 5 6 10 10 (6+10)/2=8 (5+5)/2=5 Machine 1 I J Machine 2 J I 10 (10+9)/2=9.5 (5+5)/2=5 4 5 9 10

  4. Example 8.5 What is the optimal job sequence ? 2 4 3 5 1

  5. Extension to three machines • The problem of scheduling jobs on three machines is considerably more complex. • The three machine problem can be reduced to a two machine problem if the following condition is satisfied: • Label the machines A, B and C • Ai = Processing time of job i on machine A. (Bi ,Ci are defined as similar) • minAi≥ max Bior min Ci≥ max Bi • Define Ai‘ = Ai+ Biand define Bi‘ = Bi+ Ci

  6. Example 8.5 minAi= 4 max Bi = 6 min Ci= 6 Check the conditions minAi≥ max Bior min Ci≥ max Bi Required condition is satisfied. What is the optimal job sequence ? 1 4 5 2 3

  7. The two-shop Flow shop problem • Assume that two jobs are to be processed through m machines. • Each job must be processed by the machines in a particular order, but sequences for the two jobs need not to be the same. • A graphical procedure for solving this problem is developed by Aker (1954)

  8. Aker’s Algorithm • Draw a Cartesian coordinate system. • Processing times for first job on the horizontal axis • Processing times for second job on the vertical axis • On each axis, mark off the operation times in the order in which the operations must be performed for that job. • Block out areas corresponding to each machine at the intersection of the intervals marked for that machine on the two axis. • Determine a path from origin to the end of final block that does not intersect any of the blocks and that minimizes the vertical movement.

  9. Example 8.7 Job 1 Job 2 10 C 9 8 7 B 6 5 Job 2 4 3 2 A 1 1 2 3 4 5 6 7 8 9 10 11 12 Job 1 A1 A2 A B1 B2 B C C1 C2 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
