  1. Lowest Storage Cost Per Desktop Without Tradeoffs Abhinav Joshi Sr. Product Manager Desktop Virtualization #NetAppSynergy

  2. Citrix-NetApp Architecture #NetAppSynergy

  3. NetApp-Citrix Architecture Profile & Folder Redirection to CIFS VM XenDesktop Desktop Director Corporate Apps User Installed Apps Profile/ Folders User Data Win 7/ 2K8 OS Write Cache Virtualized Apps Base image/ vDisk Personal vDisk (s) CIFS Home Dir. Hypervisor VSC NetApp Clustered ONTAP FlashCache Write IO Coalescing VMDK/ VHD VMDK/ VHD OnCommand Balance Dedupe/Thin Prov. CIFS/Blocks NFS/Blocks NFS/Blocks CIFS CIFS DR Site Multi-protocol Non-Disruptive Ops Citrix CloudBridge Dedupe aware NetApp snapshots NetApp SnapMirror #NetAppSynergy

  4. Non Persistent Desktops • Call center • Training labs • Kiosks Task Workers App compatibility issues w/ multi-user session on the same Win OS? Locked down environment? Yes Yes No No Locked down environment? Yes No 4 2 3 1 Pooled Streamed Desktops (1 VM per user) • Profile Management • Redirected Folders Hosted Shared Desktops (XenApp) • Mandatory Profiles • Redirected Folders Hosted Shared Desktops (XenApp) • Profile Management • Redirected Folders Pooled Streamed Desktops (1 VM per user) • Mandatory Profiles • Redirected Folders Storage required for Citrix PVS write cache file and CIFS shares #NetAppSynergy More popular

  5. Persistent Desktops Knowledge Workers • Developers • Contractors Users roam between desktops? Yes No 6 5 Personal Streamed Desktops(1 VM/user) • Local Profiles & Folders (PvDisk) • User installed apps persistent across sessions Personal Streamed Desktops (1 VM/user) • Profile Management • Redirected Folders • User installed apps persistent across sessions Storage required for Citrix PVS write cache file & Personal vDisk Storage required for CIFS Share #NetAppSynergy More popular

  6. Storage Cost per Desktop Analysis #NetAppSynergy

  7. Sizing Assumptions • Extrapolation based on NetApp performance testing for Citrix PVS & our VDI Sizing Tool • LoginVSI heavy workload (10 IOPS/desktop to storage; majority of read IOPS served by PVS read cache) • Apps latency within acceptable limits (VSIMaxnumber below 1500) • All VMs boot within 10 minutes • Capacity: 6GB-17GB per user (use case dependent) • 35% dedupe savings for Citrix Personal vDisk and CIFS share • IO Acceleration: • Writes: NetApp IO coalescing • Read IOPS: • FlashCache for CIFS read traffic • Citrix PVS caches majority of VM reads • NetApp controller utilization <50% during steady state #NetAppSynergy

  8. Non Persistent Desktops Hosted Shared Desktops (XenApp) • Mandatory Profiles • Redirected Folders 1 $33-$75/user* Hosted Shared Desktops (XenApp) • Profile Management • Redirected Folders 2 Pooled Streamed Desktops (1 VM/user) • Local Profiles • Redirected Folders 3 Pooled Streamed Desktops (1 VM/user) • Profile Management • Redirected Folders 4 * Assumes standard discounts Price includes 3 yr support/services w/ 4 hr parts replacement DS4243 shelves with 600GB 15K RPM disks FAS3250 config includes two 512GB FlashCache cards CIFS shares included #NetAppSynergy

  9. Persistent Desktops Personal Streamed Desktops (1 VM/user) • Local Profiles & Folders • User installed apps persistent across sessions $37-$90/user* 5 Personal Streamed Desktops (1 VM/user) • Profile Management • User installed apps persistent across sessions 6 * Assumes standard discounts Price includes 3 yr support/services w/ 4 hr parts replacement DS4243 shelves with 600GB 15K RPM disks FAS3250 config includes total two 512GB FlashCache CIFS shares included #NetAppSynergy

  10. VDI in a Box with FAS2240-2 < $50/user* FAS2240-2 w/ internal SAS drives • 2U • Internal SAS disks • 600GB; 10K RPM * Assumes standard discounts Price includes 3 yr support/services w/ 4 hr parts replacement CIFS shares included #NetAppSynergy

  11. VDI in a Box with FAS2240-2 <$30/user Up to 1000 VMsin 2U FAS2240-2 w/ 24 internal SAS disks (600GB; 10K RPM) Non-persistent desktops (pooled streamed with PVS) • 5GB for PVS write cache file (0% dedupe) • 2GB for VM memory (0% dedupe) • 10-12 IOPS (95% writes) to write cache file • No Profile Management • No Folder Redirection • No CIFS share * Assumes standard discount Price includes 3 yrsupport/services; 4 hr parts rep #NetAppSynergy

  12. Summary • Achieve lowest storage cost per desktop with NetApp • No performance tradeoffs • Complete solution for desktop OS, Apps, Profiles, and Data • Simple to deploy and scale #NetAppSynergy

  13. #NetAppSynergy
