  1. telnet TCP/IP Suit by Behrouz Fourozan 4th Ed

  2. concept • General purpose client server program • Developed when time sharing systems were being used • Time sharing environment • Large computer with multiple users • Interaction with user through terminals • Login • Local login • Remote login Internet Computing (CS-413)

  3. Netork virtual terminal Internet Computing (CS-413)

  4. NVT characterset • Data characters • 8b long • MSB =0 • Control characters • 8b long • MSB=1 • Examples EOF, EOR, SE, NOP, DM, IP, AO, GA, will, do, dont, IAC Internet Computing (CS-413)

  5. embedding • Uses TCP port 23 for server • Client may use any port • Same connection for data and control • Control character is preceded by Interpret as Control (IAC) • Eg cat file1  mistyped to cat filea<backspace> 1 Internet Computing (CS-413)

  6. options • telnet lets client and server negotiate option before or during the use of the service • Options are extra features available to a user with more sophisticated terminal • Examples binary, ECHO, Suppress go ahead, status, timing marks, terminal type, terminal speed, line mode Internet Computing (CS-413)

  7. Option negotiation • To use options, option negotiation is required • Four control characters • WILL • WONT • DO • DONT • Enabling an option • Some can be enabled only by server, some only by client and some by both • Two possibilities • Offer or request Internet Computing (CS-413)

  8. Option negotiation • disabling • Two possibilities • Offer to disable • Request to disable • Symmetry • Client and servers are given equal opportunity • If one party wants an option enabled, it may offer or request Internet Computing (CS-413)

  9. Suboption negotiation • Some options require additional information • Example define type or speed of a terminal • SE – suboption end • SB – suboption begin Internet Computing (CS-413)

  10. Controlling the server • Client may be controlled by ctrl+C or back space etc • Server is controlled through special characters • IP – interrupt process • AO- Abort output • AYT – are you there • EC- erase last character • EL- erase line Internet Computing (CS-413)

  11. Out of band signaling • Control characters are preceeded by IAC and sent out of order • TCP segment is marked with URG bit and Urgent data pointer • Urgent data points to DM (data mark) character. • DM tells where the out of order data is present Internet Computing (CS-413)
