1. CSCE 715:Network Systems Security Chin-Tser Huang huangct@cse.sc.edu University of South Carolina

2. Insufficiencies with Symmetric Encryption • Symmetric encryption is not enough to address two key issues • key distribution – how to have secure communications in general without having to trust a KDC with your key? • digital signatures – how to verify that a received message really comes from the claimed sender?

3. Thoughts about KDC What good would it do after all to develop impenetrable cryptosystems, if their users were forced to share their keys with a KDC that could be compromised by either burglary or subpoena? - Whitfield Diffie

4. Advent of Asymmetric Encryption • Probably most significant advance in the 3000 year history of cryptography • Use two keys: a public key and a private key • Asymmetric since parties are not equal • Clever application of number theory concepts instead of merely substitution and permutation

5. How Asymmetric Encryption Works • Asymmetric encryption uses two keys that are related to each other • a public key, which may be known to anybody, is used to encrypt messages, and verify signatures • a private key, known only to the owner, is used to decrypt messages encrypted by the matching public key, and create signatures • the key used to encrypt messages or verify signatures cannot decrypt messages or create signatures

6. Asymmetric Encryptionfor Confidentiality

7. Asymmetric Encryptionfor Authentication

8. Public-Key Cryptosystems

9. Public-Key Characteristics • Public-Key algorithms rely on two keys where: • it is computationally infeasible to find decryption key knowing only algorithm & encryption key • it is computationally easy to en/decrypt messages when the relevant (en/decrypt) key is known • either of the two related keys can be used for encryption, with the other used for decryption (for some algorithms)

10. Applications for Asymmetric Encryption • Three categories • Encryption/decryption: sender encrypts a message with receiver’s public key • Digital signature: sender “signs” a message with its private key • Key exchange: two sides exchange a session key

11. Security of Asymmetric Encryption • Like symmetric schemes brute-force exhaustive search attack is always theoretically possible, but keys used are too large (>512bits) • Not more secure than symmetric encryption, dependent on size of key • Security relies on a large enough difference in difficulty between easy (en/decrypt) and hard (cryptanalyse) problems • Generally the hard problem is known, just that it is made too hard to do in practice • Require using very large numbers, so is slow compared to symmetric schemes

12. RSA • Invented by Rivest, Shamir & Adleman of MIT in 1977 • Best known and widely used public-key scheme • Based on exponentiation in a finite (Galois) field over integers modulo a prime • exponentiation takes O((log n)3) operations (easy) • Use large integers (e.g. 1024 bits) • Security due to cost of factoring large numbers • factorization takes O(e log n log log n) operations (hard)

13. RSA Key Setup • Each user generates a public/private key pair by • select two large primes at random: p, q • compute their system modulus n=p·q • note ø(n)=(p-1)(q-1) • select at random the encryption key e • where 1<e<ø(n), gcd(e,ø(n))=1 • solve following equation to find decryption key d • e·d=1 mod ø(n) and 0≤d≤n • publish their public encryption key: KU= {e,n} • keep secret private decryption key: KR= {d,n}

14. RSA Usage • To encrypt a message M: • sender obtains public key of receiver KU={e,n} • computes: C=Me mod n, where 0≤M<n • To decrypt the ciphertext C: • receiver uses its private key KR={d,n} • computes: M=Cd mod n • Message M must be smaller than the modulus n (cut into blocks if needed)

15. Why RSA Works • Euler's Theorem: aø(n) mod n = 1 where gcd(a,n)=1 • In RSA, we have • n=p·q • ø(n)=(p-1)(q-1) • carefully chosen e and d to be inverses mod ø(n) • hence e·d=1+k·ø(n) for some k • Hence :Cd = (Me)d = M1+k·ø(n) = M1 = M mod n

16. RSA Example: Computing Keys • Select primes: p=17, q=11 • Compute n=pq=17×11=187 • Compute ø(n)=(p–1)(q-1)=16×10=160 • Select e:gcd(e,160)=1 and e<160 • choose e=7 • Determine d:de=1 mod 160 and d<160 • d=23 since 23×7=161=1×160+1 • Publish public key KU={7,187} • Keep secret private key KR={23,187}

17. RSA Example: Encryption and Decryption • Given message M = 88 (88<187) • Encryption: C = 887 mod 187 = 11 • Decryption: M = 1123 mod 187 = 88

18. RSA Example:Processing of Multiple Blocks

19. Exponentiation • Use a property of modular arithmetic [(a mod n)(b mod n)]mod n = (ab)mod n • Use the Square and Multiply Algorithm to multiply the ones that are needed to compute the result • Look at binary representation of exponent • Only take O(log2 n) multiples for number n • e.g. 75 = 74·71 = 3·7 = 10 (mod 11) • e.g. 3129 = 3128·31 = 5·3 = 4 (mod 11)

20. RSA Key Generation • Users of RSA must: • determine two primes at random - p,q • select either e or d and compute the other • Primes p,qmust not be easily derived from modulus n=p·q • means p,qmust be sufficiently large • typically guess and use probabilistic test • Exponents e, d are multiplicative inverses, so use Inverse algorithm to compute the other

21. Security of RSA • Four approaches to attacking RSA • brute force key search (infeasible given size of numbers) • mathematical attacks (based on difficulty of computing ø(n), by factoring modulus n) • timing attacks (on running of decryption) • chosen ciphertext attacks (given properties of RSA)

22. Factoring Problem • Mathematical approach takes 3 forms: • factor n=p·q, hence find ø(n) and then d • determine ø(n) directly and find d • find d directly • Currently believe all equivalent to factoring • have seen slow improvements over the years • as of May-05 best is 200 decimal digits (663 bits) with LS • biggest improvement comes from improved algorithm • cf “Quadratic Sieve” to “Generalized Number Field Sieve” to “Lattice Sieve” • 1024+ bit RSA is secure barring dramatic breakthrough • ensure p, q of similar size and matching other constraints

23. Timing Attacks • Developed in mid-1990’s • Exploit timing variations in operations • e.g. multiplying by small vs large number • Infer operand size based on time taken • RSA exploits time taken in exponentiation • Countermeasures • use constant exponentiation time • add random delays • blind values used in calculations

24. Chosen Ciphertext Attacks • RSA is vulnerable to a Chosen Ciphertext Attack (CCA) • attackers chooses ciphertexts and gets decrypted plaintext back • choose ciphertext to exploit properties of RSA to provide info to help cryptanalysis • can counter with random pad of plaintext • or use Optimal Asymmetric Encryption Padding (OAEP)

25. Next Class • Key management • Key exchange • Diffie-Hellman key exchange protocol • Elliptic curve cryptography • Read Chapters 11 and 12
