  1. The Principle of Linear Superposition and Interference Phenomena 17.1 The Principle of Linear Superposition and 17.2 Constructive and Destructive Interference of Sound Waves

  2. 17.1 The Principle of Linear Superposition • Often two or more wave pulses move through the same space at once • When two or more waves are present simultaneously at the same place, the resultant disturbance is the sum of the disturbances from individual waves

  3. Two Examples

  4. Example • After 2 seconds, what is the height of the resultant pulse at x = 2, 4, and 6 cm? • 0, -2, 2

  5. 17.2 Constructive and Destructive Interference of Sound Waves • Imagine that there are 2 speakers facing each other. Both speakers produce the same sound at the same time.  = 1 m

  6. Destructive interference • One of the speakers is moved back half a wavelength

  7. Noise-canceling ear phones

  8. Problem Solving Strategy • For two wave sources vibrating in phase, a difference in path lengths that is zero or an integer number of wavelengths leads to constructive interference • A difference in path lengths that is a half-integer number of wavelengths leads to destructive interference.

  9. Overlap of Sound

  10. Example – What does the listener hear? • A listener hears two speakers. The distance between the speakers and the listener are 3.00 m and 5.25 m. The sound is at 229 Hz and the speed of sound is 343 m/s. Does the listener hear a loud or soft sound? • Soft sound

  11. Practice Problems • Try sounding out these exercises • 506 CQ 1, P 1 – 3, 6 – 7 • Total of 6 Problems
