  1. Unit One Quiz Solutions and Unit Two Goals Mechanical Engineering 370 Thermodynamics Larry Caretto February 11, 2003

  2. Outline • Solution to quiz • Look at individual problems • Solutions available on line • Unit two – work and paths • Unit goals available on line • Group exercise on Thursday • Quiz on Tuesday, February 18

  3. Problem One Solution • Given: P = 2 MPa, T = 200 K, V = 2 m3 • Find the mass, m, using tables • First, find the specific volume from superheat tables v(2 MPa,200 K) = 0.04164 m3/kg • m = 48.03 kg

  4. T, K P,MPa 200 v 2 h s 0.0416 269.92 4.2172 Searching the Table

  5. Problem Two Solution • Given: P = 2 MPa, T = 200 K, V = 2 m3 • Find the mass, m, using ideal gas equation • Still have m = V/v with v = RT/P • m = 48.55 kg, a 1.3% error

  6. Problem Three Solution • Given: Neon at 200 K and 2 MPa cooled at constant volume to 30 K • Find: Final state • For constant volume process initial specific volume = final specific volume = 0. 04164 m3/kg from problem one • Final state is v = 0. 04164 m3/kg and T = 30 K

  7. Problem Three Continued • Check vf and vg at T = 30 K • Find vf = 0.000869 m3/kg < v = 0.4164 m3/kg < vg = 0.05016 m3/kg • Mixed, so P = Psat(30 K) = 0.2238 MPa

  8. Unit Two Goals • As a result of studying this unit you should be able to • find properties more easily than you were able to do after completing unit one • describe the path for a process • find the work as the integral of PdV • find the work as the area under the path on a P-V diagram

  9. Unit Two Goals Continued • understand the difference between the applied force (or pressure) and the system force (or pressure). • recognize that work is always the integral of the applied force (or pressure) over distance (or volume) • recognize when the applied pressure and the system pressure are the same

  10. More Unit Two Goals • use the description of the path as an equation • recognize the difference between the path equation and the equation of state • use the path equation and the equation of state in a trial-and-error procedure to find the final state • use the path equation and the equation of state in a trial-and-error procedure to find the final state when the "equation of state" is a set of tables

  11. Analysis of Work • Start with dW = Fdx • dW = (PA)d(V/A) = PdV • Note that dimensions are (F/L2) times L3 • E. g., pascal-m3 gives N-m or joules • psia-ft3 times 144 in2/ft2 gives ft-lbf • W = PdV over path • Work depends on path

  12. Simple Path • Here we have an initial point (1), a final point (2) • Work = area under path = trapezoid area = (V2 – V1) (P1 + P2)/2 • Work is positive 1 P 2 V

  13. Integrating a Line • Work = area under path = trapezoid area = (V2 – V1) (P1 + P2)/2 • Work is positive because if V2 > V1 (and pressure is always positive) • Work is positive when system expands (system does work on surroundings) 1

  14. Reverse Path • Here the initial point (1) and final point (2) are reversed • Work = area under path = trapezoid area = (V2 – V1) (P1 + P2)/2 • Work is negative 2 P 1 V

  15. Integrating a Reverse Line • In the previous chart the initial point (1) and final point (2) are reversed • Work = area under path = trapezoid area = (V2 – V1) (P1 + P2)/2 • Work is negative because V2 < V1 • Work is negative when system is compressed (work done on system) 1

  16. More Complex Path • Here we have an initial point (1), a final point (4) and two intermediate points (2 and 3) • Work = area under path = trapezoid area plus rectangle area 2 3 P 4 1 V

  17. How Do We Specify State • To integrate PdV, we need path equation, P(V) • Path equation is integrated along path in terms of P and V • Can specify states in terms of T • Need to use equation-of-state or tables to get v from (P,T) and V = m v

  18. Example Calculation • Given: 10 kg of H2O at 200oC and 50% quality is expanded to 400oC at constant pressure • Find: Work • Equation: W = PdV = P(V2 – V1) for constant pressure • How do we find P, V1 and V2 from data given?

  19. Example Continued • Use tables for H2O to find P and v • Get total volume as V = m v • Initial state is in mixed region so the constant pressure, P = Psat(200oC) = 1.5538 MPa and v = vf + x (vg – vf) • At 200oC, vf and vg, respectively, = 0.001157 and 0.12736 m3/kg • For x1 = 0.5, v1 = 0.06426 m3/kg

  20. Example Concluded • V1 = m v1 = 0.6426 m3 for m = 10 kg • Point 2 has T = 400oC and P = initial P = 1.5538 MPa • From superheat table interpolation this final state has v = 0.19646 m3/kg • Since m = 10 kg, V2 = 1.9646 m3 • W = (1.5538 MPa)(1.9646 – 0.6426) m3

  21. Units for Work • Basic idea is that Pa•m3 gives J, kPa•m3 gives kJ, MPa•m3 gives MJ, • For other pressure units need to convert into kJ; here W = 2,054 kJ • Without unit conversion we could get the work as 2.054 MJ
