  1. EX Models • EX5 – 2 door controller • EX7 – 4 door controller • EX5P – 2 door controller with integrated proximity

  2. COMMON FEATURES • Power input 12/24V AC/DC • Indoor/outdoor installation • Blue illuminated keypad • Metal/plastic keys • 99 User codes (1 to 8 digits) • 30 sec lockout after 8 invalid codes • 2 Free tension LEDs (Red & Green) • 2 Push buttons • Pulse (01 to 99 sec) or latch (00) relay mode • 3-wire CODIX bus

  3. EX5M52B EX552B EX5M52C EX552C EX5M52G EX552G PRODUCT PREFERENCES • EX552 • EX5M52 options • Strong aluminum case • Surface mount • Metal keys • 2 outputs - Relay1 (10A) - Relay2 (2A) • Plastic keys

  4. INSIDE PRODUCT EX7 4 Relays (4x2A) EX5 2 Relays (1x10A, 1x2A) EX5P 2 Relays (1x10A, 1x2A)

  5. Cable distance • Cable type: AWG24 • Bi-directional 3-wire CODIX bus HOST INOX b). a). Codix peripheral Codix peripherals Max: 100m Max: 200m MINIm INOX EX5M43B

  6. Start Enter ‘Master Code’ OR ‘000’ (if first time use) EX5/EX7 programming Block diagram Validate by pressing (B) Validation OK? NO Multiple small beeps + Yellow LED blinks rapidly YES 1 small beep + 1 long beep + Yellow LED is ‘On’ Assign a user code Press (0) + Memory position from 01 to 99 Change Master code Press (0) + Memory Position (00) Assign Output Press (3) + Memory position from (01 to 99) + Press (1) for relay OR Press (2) for transistor OR Press (12) for both Set output timer Pulsed Mode (01 to 99 sec) Relay (2A): Press (1) + (from 01 to 99) Transistor: Press (2) + (from 01 to 99) OR Latch Mode (ON/OFF) Press (1) or (2) and (00) Delete Single Code Press (9) + Memory position from (01 to 99) Delete All Codes Press (8) + (99) Proximity reader Keypad reader Enter new code (1 to 8 digits) Press A to validate Present Card/Tag before the Reader Validation OK? NO YES Quit programming NO YES Press B ( yellow LED is ‘OFF’ ) End

  7. EX5M102A EX5102A EX5M102B EX5102C EX5M102G EX5102G FLUSH MOUNT

  8. EX5P SPECIAL FEATURES • Standalone keypad & proximity reader • 99 PIN Codes or badges or Badge + Code • Reads EM4100 cards/tags • Read range 6 cm • Single security with code or tag • Double security with code and tag • Input voltage 12V AC/DC • Comes with 5 badges • 2 Free tension LEDs • IP65 EX5P-73C EX5P-43B
