  1. FlowMap: An Optimal Technology Mapping Algorithm for Delay Optimisation in Lookup-Table Based FPGA Designs Presented by Qiwei Jin 10/09/2014

  2. Overview • The paper and the authors. • Some background information. • The algorithm in detail. • Results and Conclusion. • Questions for discussion.

  3. About the Paper • Originally published in 1992, won IEEE Circuit & Systems Society best paper award in 1994. • 238 citations in total, 33 self. • The firstalgorithm to solve a conventionally NP-hard depth minimisation problem in polynomial time. • The algorithm is a key component in most commercial FPGA compilers. • FlowMap-r and other more sophisticated algorithms published by the authors at the same year or later for both depth and area minimisation.

  4. Jason Cong • Chairman of Computer Science Department, UCLA. • Was Assistant Professor in 1994 when this paper was published. • Got Promoted to Associate Professor in the same year. • His company Aplus was acquired by Magma in 2004 for "$13 million in stock, cash and incentives“. Picture borrowed from Jason Cong’s homepage

  5. Yuzheng Ding • Very low profile person, no picture, no home page, not even on FaceBook. • RA in UCLA for PhD when this paper was published. • May have left university for work (Mentor Graphics) after graduation. • Still working actively with Jason Cong, latest paper published in year 2008.

  6. Background • FPGA (Field-Programmable Gate Array): Programmable hardware. Xilinx Virtex 5 FPGA

  7. Background Cont. For more information, go to Wayne Luk’s Custom Computing Course

  8. Background Cont. • FPGAs are essentially a bunch of wires and LUTs (Look-Up Tables) that can be configured to emulate the behaviour of a digital circuit. • FPGAs can be configured by Hardware Description Language (HDL, such as VHDL). • Based on the HDL, a netlist can be generated automatically by some algorithm (FlowMap!).

  9. Background Cont. = 4-Input 1-Output LUT (16 entries in total)

  10. Background Cont. • Mappings from ASIC to FPGAs are not necessary one to one. • The question is how to achieve the optimal condition? =

  11. Background Cont. • Trade-offs: • Area (number of LUTs used) • Depth (delay of the circuit) • FlowMap focuses on depth optimisation depth

  12. Depth Minimisation Example

  13. The Key Idea of Depth Minimisation • Try to pack as many gates in different levels into a LUT as possible. • Number of LUT used (Area) is not the primary concern. • The problem is equivalent to generating optimal code for expressions containing common subexpressions, hence NP-Hard.* • Conventional method will decompose the Boolean network into a forest of trees before processing. • FlowMap can find an optimal mapping directly from a Boolean network within polynomial time. Let’s see how. * A. Aho, S. C. Johnson, “Optimal Code Generation for Expression Trees”, 23, 3, 488-501 (1976).

  14. Preliminaries • Input(T) • Cut (X, X) • Node Cut Size • Edge Capacity • Edge Cut Size • Whether a cut is K-feasible • Height of a Cut

  15. The FlowMap Algorithm • 2 Phases • Node Labeling: define the optimal depth of the LUT mapping solution for Nt. • LUT Mapping: generate the LUT network based on the labeling in the first phase.

  16. Phase 1: Node Labelling

  17. Phase 1: Node Labelling Cont.

  18. Phase 2: LUT Mapping

  19. Phase 2: LUT Mapping Cont.

  20. The FlowMap Pseudocode

  21. Enhancements • Maximising Cut Volume During Mapping • Postprocessing (flow-pack) Operations to reduce number of K-LUTs

  22. Results

  23. Conclusion • The paper presents the first algorithm to compute a NP-hard problem in polynomial time. • Compared to other algorithms FlowMap is about to reduce up to 7% of the LUT network and reduce up to 50% of the number of LUTs.

  24. Questions • It is claimed that a minimum height K-feasible cut can be found in O(Km) time, where K is the number of input of LUT and m is the number of edges of in the network. • But it is not clear to me how it is derived.

  25. Questions Cont. • It would be interesting to see the time taken to compute the mapping for the testing cases with FlowMap vs. Other Algorithms. • The testing cases are generally small in size, it would be more convincing to see some large size examples.
