2. Enterprise VoIP Security Threats • Agenda: • Introduction • Why worry? • What do we need to look at? • What have I seen in the past? • What can I do to be prepared? • Questions & Discussion

3. Introduction • VoIP = Voice + IP • Simple Equation for VoIP Security: VoIP Risks = Current Risks + VoIP Risks • Too many companies haven’t cleaned up their current infrastructure

4. Challenges Along The Way • Relatively new technology (at least adaptation is new) • Often implemented by the voice team, not the data team • “man” pages often exceed 500 pages per component. And each implementation can have ten or more systems. • Implementations usually slide from trial to production without any security review

5. Traditional Risk Assessment • Identify assets • Classify and prioritize assets • Identify vulnerabilities, controls, threats (including likelihood and impact) • Measure risk • Mitigate risk • Monitor • Do it again

6. VoIP Security Assessments • Same process. • Completed with a different group of assets, threats, vulnerabilities, and controls. • Readiness review? • Review the current infrastructure prior to VoIP deployment • Allows mitigation of identified risks concurrent with VoIP planning, design, and pilot program. • Must hold full-scale deployment until all identified risks are mitigated

7. When To Add Security? • Do we add security at: • Planning/Design/Pilot/Roll-Out/Regular Risk Assessment? • The RFI/RFQ stage (and keeping them around): • Make security part of your requirements to ensure that the solution can meet your requirements before you buy the equipment. • Security can support the planning and design phase and make recommendations before decisions are finalized. • Security can perform a risk assessment of the design, infrastructure, and configuration prior to pilot program. • Security can monitor and continually assess the pilot infrastructure and configuration. • Security can mitigate the risks before the deployment.

8. What Do We Need To Review? • IP Infrastructure: • VLAN Configuration • Firewall configurations • Existing policies, procedures, standards, and practices • IDS/IPS • Incident Response • Configuration Management, Change Management, Business Continuity Planning, Commissioning and Decommissioning, and other programs

9. What Else Do We Need To Review? • VoIP Infrastructure: • Are the Security features enabled? • Are they tested in all scenarios? • IPSec enabled? • QoS measured? • Latency and Jitter consistent in production environment • Firewalls: • Where: PSTN Interfaces, Data and IP Segment Intersects • What Types? What Traffic? Reviews? Pinholing? • NAT effects and capacity

10. Experiences from the Trenches • Poor management (storage and transmission) of the encryption keys • Random responses to invalidly formatted or excessive packet transmissions • Security mechanisms susceptible to “bidding-down” attacks • Firewalls that require just a bit of “tuning” to disable that service that isn’t required or the ports that can be closed

11. Experiences from the Trenches • Default administration accounts • Ineffective encryption (It may be AES, but not in use at key points) • Web-Server interfaces (It may be easier for the admin as well as the bad-guys!) • DHCP and TFTP Server Spoofing and Insertion Attacks

12. What’s In YourToolbox? • In order to perform a technical based review, you’ll need some tools: • Sniffers • Injectors • Vulnerability Scanners • Some important documents from the ITU, NIST, ETSI, and most importantly, equipment vendors!

13. VoIP Tools • Sniffers & Analyzers • VoIP Specific or Generic • Injectors • Vendor Tools • Assessment • Proprietary Tools

14. SiVus

15. Additional Resources • National Institute of Standards and Technology: Security Considerations for Voice Over IP Systems: http://csrc.nist.gov/publications/nistpubs/ • SiVus at VoP Security: http://www.vopsecurity.org/ • IETF/ITU Documents • ETSI Tiphon Documents • Miscellaneous Vendor Documentation and White Papers

16. Lucent Technologies Bell Labs Innovations George G. McBride Managing Principle Lucent Worldwide Services Lucent Technologies Inc. Room 2N-611G 101 Crawfords Corner Road Holmdel, NJ 07733 Phone: +1.732.949.3408 E-mail: gmcbride@lucent.com Anything Else? • Please contact me with any questions, comments, complaints, or new developments.
