This project focuses on the design and construction of a Plasma Enhanced Chemical Vapor Deposition (PECVD) machine, upgraded from an existing Reactive Ion Etching (RIE) system. Contracted by the Nanotechnology Research Center, the machine automates the polymer deposition process, eliminating the need for constant human monitoring. Key features include continuous monitoring of vacuum pressure, RF power, and gas flow rate, simplifying future modifications. Constructed with customizable materials, the machine is aimed at advancing research in nanotechnology while significantly minimizing operational costs.

#innovative pecvd machine design for nanotechnology applications #innovative pecvd machine design for nanotechnology applications ppt #powerpoint #presentation
Innovative PECVD Machine Design for Nanotechnology Applications - slide 1
01 / 30Innovative PECVD Machine Design for Nanotechnology Applications
1 / 17

Télécharger la présentation

Innovative PECVD Machine Design for Nanotechnology Applications
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. Digital PECVD Machine Design and Construction Zlatan Ceric William Edwards Timothy Gurtler David Ogden Quan Tran Date:12/10/2010

  2. Project Overview Contracted by Nanotechnology Research Center Converted existing RIE to PECVD machine Automation of process eliminates the need for constant human monitoring Cost of Hardware: $35,000 Built base model for NRC modification

  3. Final Product

  4. Design Objectives Continuously monitor chamber vacuum pressure, RF power, and gas flow rate Automated the polymer deposition process Allows for future process modification through HMI

  5. RIE to PECVD Conversion Removed turbo pump Use one chamber pressure sensor instead of two Removed old chamber heater Remapped wires to integrate new design Edited PLC and HMI code to reflect all changes

  6. System Hierarchy

  7. Mechanical Pump

  8. Mass Flow Controllers

  9. RF Power System

  10. Chassis Construction Gator Jaw is the material used to build the stand It is customizable and easily changed if needed Plates can be mounted to the frame to provided a surface for components to mount

  11. Component Mounting • Din rail provides a simple mounting solution • Standard 35mm width used widely in industrial control systems • PLC was designed to mount onto this type of rail • Power supply and terminal blocks also mount to it

  12. Centralized Signal Testing • Over 70 signals are required for the PLC to manage • Having terminal blocks gives a convenient location to test the signals • Mounting them onto the din rail gives a clean look for the machine • Future manipulations of the machine will also be more convenient

  13. Testing the Machine Wire continuity was first check to ensure each component was properly connected Each Input into the PLC was forced on to ensure each component was working properly Feedback was compared between components and HMI Display

  14. Set Point Feedback • Pressure is required to stay within 10% • Gas Flow Rate is required to stay within 1% • RF Power is required to stay within 5%

  15. PLC Operational Flow Chart

  16. HMI Screen Capture

  17. Recipe Input Capture

  18. Power Input Capture

  19. Coding Challenges • Working with new programs and languages: • RSLogix5000 with Ladder Logic • FactoryTalk View Studio • Interfacing with analog, digital, and serial connections • Inability to test and debug software before machine was fully assembled • Not able to implement “Trending” function due to time constraints

  20. Subsystems Interaction Subsystems need a way to interact with each other and PLC Require customized cables

  21. Problems with Pneumatics Problem: No Documentation Solution: Called Technical Support Problem: Solenoid was not working properly Solution: Craig Fox came out to help solve the problems

  22. Problems with RF Power • Problem: RF Power would not respond • Solution: Called Tech Support to resolve problem • Problem: High Power could not be achieved • Solution: Replaced RF Power Supply

  23. Budget and Cost • Project is exclusively design for Ga Tech NRC and cannot be used for mass production • Parts were donated, salvaged, and funded by: • Ga Tech NRC • Rockwell Automation • A conservative estimate cost of $135,000 including hardware and labor/testing for completed project

  24. Cost Breakdown Labor & Testing Assume average GT ECE graduate earns $65K annually Project includes 5 design and implementation members Estimated labor and testing of $100K Hardware • Major components

  25. Future Work: Intended Machine Use M. Bakir 2008 Options: • Deep UV lithography • Electron Beam Lithography • FEL/ARLP X-Ray Lithography • Nano Imprint Lithography

  26. Future Work: Additional Machine Use Topographic negative of structure will will be constructed with electron beam lithography Organic Gas will deposit non stick polymer on mold Mold will be used as press to relief desired structure Antistick coating will have to be reapplied after several uses (~3)

  27. Future Work: Diagnostic and Expansion • Additional internal real estate available: • MFCs • Turbo • Heating System • Magnetic field module • Plasma Density Test

  28. Video Demonstration

  29. Questions or Comments?
