  1. Company Origin • Jingjiang Nanyang Shipbuilding Co., Ltd is a Sino-Foreign joint venture shipbuilding enterprise, invested and grouped by Nantong Tiannan Shipyard and Singapore Pacific Ocean Engineering & Trading Pte Ltd • The company (phase 1 and phase 2) covers 700,000 square meters, including 1090 meters of the Yangtze river bank line, and phase 3 is being built which is over 260000 square meters. • At present the capacity of plate treatment is120,000 tons, and it will increase to 200,000 tons after the phase 3 is finished and put into operation. 25 different types of vessels can be built each year. 关于我们 About us

  2. Production Ability • The company is professional with the construction of all kinds of vessels facing the domestic and international shipping market. • We own & operate the high-level producing ability and professional technology of any type of vessel, and has been cooperated with many ship-owners from Singapore, Japan, Korea etc., which attracted and trained many professional technicians on hull，engine & eclectic works; and thousands of technical workers classified by CCS, LR, ABS, BV, DNV and so on. 关于我们 About us

  3. 组织结构图 董事长 总经理 副总经理 副总经理 副总经理 生产管理部 技 术 部 经营供应部 行政事务部 财 务 部 计划科 考核结算科 工程科 安全科 质量管理科 轮机科 船体科 电气科 经营科 国内采购组 国外采购组 市场采购组 人事处 办公室 成本核算科 财会中心 起运车间 设备车间 钢加车间 分段车间 管装车间 轮机车间 大合拢车间 舾装车间 电装车间 涂装车间 结构组 外舾装组 内舾装组 涂装组 原材料仓库 设备仓库 五金劳保库 关于我们 About us

  4. Human resource • The staff of our company is over 2000, including： • Management staff :165persons Technicians in different subjects: 98 persons； • 51 persons having degree of college or engineer. 关于我们 About us

  5. Quality system • Quality systems we have: • ABSISO9001:2000quality management system • ISO14001enviromental management system • 2004/OHSA18001occupational health and safety management system. 质量体系 Quality

  6. Corporate Culture • Sincerity, Pragmatic, Innovation & Service • Guided by Sincerity • Based on Pragmatic • By means of Innovation • Ensured by Service 质量体系 Quality

  7. Workshops • One standard shipbuilding workshop of 150M×300M equipped with 2 set of electromagnetic gantry crane, 1 set of 20T traveling crane, 1 set of 10T traveling crane • Plate Pretreatment Workshop; • Material Marking Workshop; • Block Fabrication Workshop; • Outfitting Workshop; • Piping Workshop; • Equipments and MaterialStoreroom; • Living Quarters; • Office Building; • Shot-blasting and Painting Workshop 生产设备 Facility

  8. 生产设备 Facility

  9. Facilities • Steel plate pretreatment line • Cold frame bender • 630TOil compressor &1000TOil compressor • 3 sets of Plasma cutting machine • 4 sets of NC hydraulic pipe bender • 1 set of 300Thydraulic three core roll • 25 automatic arc welding machine • One 150tbulk carrier and one 320tbulk carrier • One 50T truck crane and one 20Ttruck crane • 600 CO2welding machines and other types of welding machines； • 9 sets of 40m3and 20m3air compressor； • Six 5t, 10tand 20tforklifts • 2 set of X-RAY detector； • 2 set of UT machine； • 1 set of magnetic powder detector； • 3 laser distance measuring machines； • 6 multipoint temperature indicators。 生产设备 Facility

  10. Block fabrication and outfitting area • 300M*32M，equipped with 80T & 20T cranes，10 forklifts of 5T，and truck crane of 50T&20T 生产设备 Facility

  11. Slipway • NO.1 & NO.2: 138M*32M，equipped with 50T&20T cranes • NO.3: 210M*52M, equipped with 3 set of 100Tframe crane and gantry cranes • NO.4: 180M*43M， equipped with150Tframe crane and 32T frame crane. 生产设备 Facility

  12. Slipway NO.1 150M×32M NO.2120M×32M NO.3210M×52M NO.4 148M×43M 生产设备 Facility

  13. Dry Dock • 220M*52M，with 300Tframe crane and 2 set of 45 cranes. 生产设备 Facility

  14. Outfitting Jetty • Jetty No.1： 90M*15M，with one 20Ttraveling gantry; • Jetty No.2： 120M, with one 45 T traveling gantry； 生产设备 Facility

  15. Outfitting Jetty • Jetty No.3： 300M*25M, with one 55T traveling gantry. 生产设备 Facility

  16. Main Products • 2000/3000TPipe lay Vessel • 3000TPipe lay and Accommodation Vessel • 4400TPipe lay Vessel • Wind Power Farm Installation & Piling Catamaran • 76M×8000 hp Tugboat • 122M SubmersibleBarge • Wenqiang 1600TFloating Crane • Pipelay Accommodation Vessel Capacity of 300 产品介绍 产品介绍 Products

  17. 长120米×宽36米×型深7米 76M×8000HP 168M×46M×13.5M 108M×43.2M×7.8M Main Products 168M×46M×13.5M 196.9M×48M×19.9M 长90米×宽50米×型深6.8米 120M×36M×7M 产品介绍 产品介绍 Products

  18. Project at the moment • ZPMC 4200TDerrick Pipe Lay Vessel • Wind Power Farm Installation & Piling Catamaran • The 2000T full rotary lifting vessel • Ukraine Dry Cargo Vessel 产品介绍 Products

  19. Our Prospect • With 10 years developing and effort, we are keep on making a good, efficient and modern shipbuilding management system. • Gain more experience by different projects, to build a excellent and stable professional team. • By means of our well-deserved reputation, good quality and service, to attract clients in the world, and to build a long-term cooperation. 公司展望 Prospect

  20. Jingjiang Nanyang Shipbuilding Co., Ltd Add. Xingang, Developing Zone of Jingjiang, Jiangsu Province Tel. 0523-84958000 Fax. 0523-84223621 http: www.nyship.cn Thanks!
