  1. Quadcopter Presentation by Chomp Chomp Microelectronics Ltd. 1

  2. Quadcopter Structure Quadcopter Advantages Quadcopter Chips Quadcopter PCB BOM Quadcopter Materials Quadcopter Demo 2

  3. Quadcopter Structure

  4. Quadcopter Advantages • Uniquely Shaped • Handy Structure and Light Weight • Stable Flying Experience and Easy Operated • Flexible Operation and 6DOF Control • Extensible Space

  5. 6DOF Control

  6. MEMS ( Micro Electro Mechanical System ) + 3-axle GSensor 3-axle Gyroscope 6-axle MEMS

  7. Quadcopter Chips Quadcopter Chips Basic Requirements : • RF SPI 5~6pin • MEMS I2C 2pin • Motor PWM 4 Routine • LVDChecking AD 1Routine • Overcurrent Protection AD 4Routineor 4 IO • LED IO 1 pin

  8. Quadcopter Chips Quadcopter Chips Materials Requirements : • RF SPI 5~6 pin • AD 4 Channel • Other Function

  9. Sonix 4-axle Periphery Materials • MEMSSensor • 6-axle Sensor • Invense 6050/Invense 3050 + Koinix J9 • 2.4G Communication • Rolling codesetting RF ID，which can realize multi-persons for Air Races • BK2423 • LT8900 • Nordic24L01

  10. PCB BOM List • Quadcopter BOMList:

  11. PCB BOM List • Quadcopter BOMList:

  12. Material • Quadcopter Size：20 cm * 20 cm • Coreless Motor ：Starting Currency 1000mA，Speed Racing 50000RPM • Li Battery：about 500mAh

  13. Functions Extension • Entertainment: • 3DRolling • Colorful Lights/Breathing Lights • Aerial photography • Flightpath Setting • Height Setting/ Obstacle Avoiding

  14. Quadcopter Demo • Stable Lifting • Flexible Control • Sensible: 3D Rolling with one Key Follow zckidology on YouTube for the Quadcopter Demo !
