This study, conducted by Cunningham, Hodgson, Parson, and Masson, presents a semi-quantitative summary of active along-slope and down-slope processes affecting the NW European continental margin. With a focus on risk assessment for submarine cables, the research aims to compile datasets related to slope processes and stability, utilizing GIS for model assessments. The findings reveal significant insights into sediment transport dynamics, including active turbidity currents and sediment slides, providing essential data to support the UK telecommunications industry in managing submarine cable risks.

#evaluation of active slope processes on the nw european continental margin #evaluation of active slope processes on the nw european continental margin ppt #powerpoint #presentation
Evaluation of Active Slope Processes on the NW European Continental Margin - slide 1
01 / 44Evaluation of Active Slope Processes on the NW European Continental Margin
1 / 17

Télécharger la présentation

Evaluation of Active Slope Processes on the NW European Continental Margin
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. An evaluation of regional active along-slope and down-slope processes of the NW European continental margin Michael Cunningham, Sophie Hodgson, Lindsay Parson and Doug Masson In conjunction with: BT Marine Flag Telecom Gemini Global Crossing / Global Marine Tyco

  2. Aims To develop a semi-quantitative summary of active slope processes Risk assessment for submarine cables To reduce time and costs to UK telecommunications industry

  3. Objectives Compilation of all available datasets relating to slope processes and stability Evaluation of datasets Model ‘Risk Assessment’ in Geographical Information Systems (GIS)

  4. Datasets Swathe bathymetry Swathe Backscatter Side-Scan Sonar 3.5kHz Pinger Profiles Gravity / Box Cores

  5. Data Modelling and Interpretation GIS Layers: 3.5kHz Echo-facies (grid/image/line/point/polygon) Aspect (grid) Backscatter (grid/polygon) Bathymetric Shaded Relief (grid) Cables (line) Contours (line) Morphology (grid/polygon) Relief (grid) Sediment samples (point) Side-scan sonar (geoTiff) Slope (grid) Metadata (line/point/polygon/xml)

  6. Conclusions (Goban Spur) Asymmetrical sediment waves infer NW sediment transport Continental shelf break transition dominated by glacial erosive features Along-, down-slope gullies/channels, and sediment slides S margin indented by large U-shaped canyons, with evidence of sediment slides Canyon floors – incised channels following topographic fault bounded escarpments

  7. Conclusions (Celtic Margin (1)) Sand waves on shelf break, mainly orthogonal to the canyon axes, and asymmetry infers sediment transport into the canyon heads Symmetrical sand waves appear to be inactive, now being overprinted Active down-slope sediment transport in the form of turbidity currents dominates upper reaches of canyons Drainage basins on canyon heads, interpreted as retrogressive mass wasting and shelf indention Recent or Active NNW-SSE faulting (?)

  8. Conclusions (Celtic Margin (2)) Sediment deposition mid-slope Canyon over-bank spill – unconfined turbidite deposits Active down-slope sediment transport (turbidity currents) dominate upper reaches of canyons Major asymmetrical levees at foot of continental slope / rise Turbidity currents incised a major channel into the low gradient of the continental rise and the flat abyssal plain. Over-spill deposits form sediment waves and the build up of wide levees
