Organic Chemistry

king avatar
king
20 diapositives · 871 Views · Jul 18, 2014

Organic Chemistry. Alkenes / Dienes Alkynes. Alkenes. The Alkenes form another homologous hydrocarbon series Each member contains one double covalent bond between two C atoms. So alkenes are said to be unsaturated . Only 3 atoms joined to each C, not 4 General formula = C n H 2n

#organic chemistry #organic chemistry ppt #powerpoint #presentation
Organic Chemistry - slide 1
01 / 20Organic Chemistry
1 / 17

Télécharger la présentation

Organic Chemistry
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. Organic Chemistry • Alkenes / Dienes • Alkynes

  2. Alkenes • The Alkenes form another homologous hydrocarbon series • Each member contains one double covalent bond between two C atoms. • So alkenes are said to be unsaturated. • Only 3 atoms joined to each C, not 4 • General formula = CnH2n • What was the general formula for the Alkanes?

  3. Saturated vs Unsaturated

  4. Saturation vs. Unsaturation • Simply put, a saturated hydrocarbon has no double bonds between the Carbon atoms (ex. alkanes) • Unsaturated has one or more double or triple bonds between carbons (alkenes, alkynes)

  5. Physical properties of the Alkenes • Very similar to the alkanes • Insoluble in water • very soluble in organic solvents • Less dense than water • B.P. and M.P increase with increasing carbon • As with alkanes B.P rises about 20-30 C per carbon • Hexane b.p. 69 C; 1-Hexene b.p. 63.5 C • Heptane b.p. 98 C; 1-Heptene b.p. 93 C

  6. Naming Alkenes • Names are derived from the name of the alkane chain with the same number of C atoms. • Replace the –ane ending of the alkane name with –ene. 1st member is C2H4, ethene. H H C=C H H

  7. Ethene Propene 1-Butene 1-Pentene 1-Hexene 1-Heptene 1-Octene 1-Nonene 1-Decene C=C C-C=C C-C-C=C C-C-C-C=C C-C-C-C-C=C C-C-C-C-C-C=C C-C-C-C-C-C-C=C C-C-C-C-C-C-C-C=C C-C-C-C-C-C-C-C-C=C Alkene Homologous Series(C1-C2 double bond)

  8. Naming Alkenes • Location of double bond is specified by numbering C atoms in backbone. Give bond the lowest possible number. 1-butene (not 4) 2-butene H H H C=C–C–C–H H H H H H H H H H–C–C=C–C–H H H Structural Formula Chemical formula Condensed Structural formula C4H8 CH2CHCH2CH3 C4H8 CH3CHCHCH3

  9. Naming Alkenes • Once double bond is numbered specify substituents alphabetically by number • Use di, tri and tetra for multiple substituents of the same group 2,3-dimethyl-1-butene C=C–C–C C C Structural Formula (w/o the H) Chemical formula Condensed Structural formula C6H12 CH2C(CH3)CH(CH3)CH3

  10. Draw the following alkenes: 2-Butene 2–methylpropene 4–Methyl–2-pentene 3,3-Dimethyl-1-butene Problems:

  11. Name this Compound: 4-ethyl-5-methyl-4-octene

  12. Alkenes = 1 double bond Dienes have 2 double bonds End in -diene Location still denoted by numbers Determine which way to number the C backbone by assigning the lowest possible number to one of the double bonds Example: 1,3 – pentadiene c=c-c=c-c Not 2,4-pentadiene Substituents are named first [Numbers are separated by commas and the #’s are Separated from the name by a dash Dienes Double bonds must all be in the backbone.

  13. C=C-C=C-C-C-C C Name this compound: C=C-C-C-C=C-C C 5-methyl-1,5-heptadiene Draw 2-methyl-1,3-heptadiene:

  14. Alkynes • Homologous series of unsaturated hydrocarbons that contain one triple bond. • Each member contains one triple carbon-carbon bond. • Alkynes are unsaturated. • General formula = CnH2n-2

  15. Ethyne Propyne 1-Butyne 1-Pentyne 1-Hexyne 1-Heptyne 1-Octyne 1-Nonyne 1-Decyne C C C-C C C-C-C C C-C-C-C C C-C-C-C-C C C-C-C-C-C-C C C-C-C-C-C-C-C C C-C-C-C-C-C-C-C C C-C-C-C-C-C-C-C-C C Alkyne Homologous Series(C1-C2 triple bond)

  16. Ethene (Common name) A common use of one of the alkynes: The Acetylene torch

  17. Hydrocarbon Table Notice that each Of the hydrocarbon Families differs From the next By 2 hydrogen Alkanes share 1pr e- Alkenes share 2pr e- Alkynes share 3pr e- Can you explain how The above comments Are related?

  18. Naming Alkynes • Use the corresponding name from the alkane series and change the –ane to –yne. • If necessary, number the carbon atom at which the triple bond occurs with the lowest number. • Use the same naming process you used for naming Alkenes

  19. Structural Chemical Name Condensed Formula Formula Structural formula H–CC–H C2H2 ethyne CHCH H H–CC–C–H C3H4 propyne CHCCH3 H H H H–CC–C–C–H C4H6 1-butyne CHCCH2CH3 H H H H H–C–CC–C–H C4H6 2-butyne CH3CCCH3 H H

  20. Can you name this compound? 3-ethyl-1-pentyne
