1. Device Interface Board for Wireless LAN Testing Team May 06-15 Client ECpE Department Faculty Advisor Dr. Weber Team Members Matthew Dahms – EE Justine Skibbe – EE Joseph Chongo – EE April 26, 2006

2. Presentation Outline • Project Overview • Introduction • Problem Statement • Operating Environment • Intended Users & Uses • Assumptions and Limitations • End-Product Description • Project Activities • Previous Accomplishments • Technology Considerations • Present Accomplishments • Planned Activities • Resources & Schedule • Estimated Resources • Schedules • Closure Materials • Additional Work • Lessons Learned • Risk & Management • Closing Summary Figure 1: Teradyne Lab Entrance

3. 1 0 1 0 D3 D2 D1 D0 voltage time Header Data Packet Definitions • ASK modulation – Amplitude shift keying. In this modulation scheme the amplitude is varied to indicate logic 0’s and 1’s • DUT – Device under test (positive edge D flip-flop) • ESD – Electrostatic discharge • FPGA – Field programmable gate array. Used to test the DUT after receiving signals from the Teradyne tester • Header – Preamble bits sent prior to the sending of information in a data packet Figure 2: Data Packet and Header

4. Definitions (cont.) • NRZ – Non-return to zero. Using NRZ, a logic 1 bit is sent as a high value and a logic 0 bit is sent as a low value. • PLL – Phase-locked loop • RZ – Return to zero. This is the opposite of NRZ data. The signal state is determined by the voltage during the first half of each data binary digit.  The signal returns to a resting state (called zero) during the second half of each bit. • S/R Network – Send/Receive network. A combination of transmitters and receivers. • Teradyne Integra J750 – Tester donated to Iowa State University by Teradyne.  It is used in the testing of printed circuit boards and integrated circuits.

5. Project Overview

6. Acknowledgement • Dr. Weber • Nathaniel Gibbs • Jason Boyd • Rob Stolpman

7. Project Overview • Problem Statement • In Fall 2004, ISU’s ECE Department introduced a senior design project with the goal of developing a wireless interface capable of receiving test signals and transmitting results to the department’s Teradyne Integra J750 tester. • For this project, the goal is to modify the current setup so that the wireless interface shall be capable of recovering a clock signal transmitted by the Teradyne system.  Figure 3: Teradyne Integra J750

8. Project Overview • Operating Environment • Operates in a controlled laboratory where the temperature range is 27°C to 33°C • Should be protected from ESD

9. Project Overview • Intended Users • The user has knowledge in electrical and/or computer engineering. • The user has previous experience testing circuits with the Teradyne J750. • The user is familiar with Verilog programming language. • Intended Uses • Functional test of a digital device via wireless interface • (Future) Wireless chipset test

10. Project Overview • Assumptions • A sufficient clock-training signal can be sent by the Teradyne J750 over the S/R network to initialize the clock recovering circuitry. • The clock recovering circuit will be able to interact with the existing FPGA. • The current wireless communication network can transmit up to five feet.  This assumption is based on the May05 team’s documentation. • The phase difference between the system clock of the Teradyne J750 and the recovered clock at the wireless interface will not be greater than the overall system clock frequency.

11. Project Overview • Limitations • The Teradyne J750 is sensitive to temperature fluctuations and must operate within the calibrated temperature range. • To avoid the loss of data, the maximum rate at which user can send data is at 115.2 Kbps. • The existing transmitter and receiver communicate at 916.5 MHz.  Therefore, nearby wireless signals at similar frequencies may disrupt the setup. • The communication link shall be limited to one frequency. • Limited to using only one FPGA.  Using two FPGA’s, it would be possible to encode/decode the clock and test data into a single data stream. Figure 4: Temperature Requirements

12. Project Overview • End-Product and Other Deliverables • Wireless interface with clock recovering circuit • Demonstration of wireless test • Update the manual for wireless test operation Figure 5: Cover page of wireless manual

13. Project Activities

14. Project Activities – Previous • Parallel-Serial Conversion • Needed to convert parallel data into serial data for transmission over the S/R network • Chose to use a shift register Figure 6: Shift Register attached to daughterboard

15. Project Activities – Previous • Transmitters and Receivers TRM1 RCV1 RCV2 TRM2 Figure 7: Tx/Rx PCBs

16. Project Activities – Previous • FPGA • Used to recognize header signal • Identifies test data • Presents test data to DUT • Presents reply to S/R network Figure 8: FPGA

17. Figure 9: Final System Setup

18. Project Activities – Present • Present Accomplishments • Hardware • Previous team’s project setup and tested • PLL tested • NRZ/RZ converter tested • PCB milled & soldered • Software • Prototype control software for FPGA written • IG-XL test template written

19. Project Activities – Definition • Definition Activities • Initially wanted to test wireless chipset • May 05-29: Redefined project as “proof-of-concept” that J750 can wirelessly test a device • May 06-15: Incorporate clock recovering circuit and the DUT onto a PCB

20. Project Activities – Research • Research Activities • Clock recovery • What is it? • How to implement it? • Teradyne • How do IG-XL templates work? • How to send data?

21. Project Activities – Approach • Approach Considered & Used • Technology Considerations • Clock recovery • Manchester encoding • PLL & NRZ/RZ converter combination • Software • VHDL • Verilog

22. Project Activities – Approach Manchester Encoding The waveform for a Manchester encoded bit stream carrying the sequence of bits 110100 Figure 11: Graphical representation of Manchester encoding

23. Project Activities – Approach • Manchester Encoding • Advantages • Very easy to implement • Clock phase and frequency are both present • Disadvantages • Too fast for current transmitters and receivers!

24. Project Activities – Approach • PLL & NRZ/RZ converter combination • Advantages • Don’t have to build new transmitters and receivers • Disadvantages • PLL Must be “trained” • Test data must follow a training signal • NRZ/RZ converter needed

25. Project Activities – Approach Figure 10: Phase locked loop transient response a) Output of PLL when locked onto input of PLL b) PLL losing lock when no input is present

26. Project Activities – Approach • Software • VHDL • Advantages • Able to handle abstract levels of logic • More powerful than Verilog • Disadvantages • This team has no experience using VHDL • Verilog • Advantages • More intuitive • Previous team’s code was based on Verilog • Disadvantages • No libraries for use in high-level constructs

27. Project Activities – Approach • Hardware chosen - PLL & NRZ/RZ converter combination • Language chosen - Verilog

28. Project Activities – Design Figure 12: Internal Components of a PLL

29. Project Activities – Design • Phase Detector • Type I – XOR • *Type II – Generates lead or lag pulses • Voltage Controlled Oscillator (VCO) • Centered at 115.2 KHz • Frequencies too far off of center frequency will not lock

30. Project Activities – Design • NRZ/RZ Converter: Monostable Multivibrators • Chosen to convert NRZ data to RZ data • Must use an external RC combination to specify pulse widths

31. Project Activities – Design Figure 14: NRZ to RZ converter circuit with I/O waveforms

32. Project Activities – Design System Block Diagram Figure 10: Proposed final setup block diagram

33. Project Activities – Implementation • Implementation Activities • Created clock recovering circuit on breadboard • Created PCB layout for final end-product • Created IG-XL test template Breadboard implementation of NRZ/RZ converter, PLL, & DUT Completed PCB

34. Project Activities – Implementation • Problems encountered • Pin mapping • FPGA grounding problem • Errors uploading program to FPGA • Parasitics using breadboard setup • Leads on capacitors • Crosstalking

35. Project Activities – Testing • Plan of attack • Test components individually w/ function generator & oscilloscope • Simulate code • Test components individually on breadboard w/ J750 • Test PCB components • Test code w/ J750 • Test integrated system

36. Project Activities - Testing FPGA Code • Works well in simulation: • Able to recognize header • Able to isolate PLL • Able to send data to DUT • Able to reset for additional sets of test data • In practice: Some features of Verilog cannot be implemented by an FPGA. In addition to this, the same register may not be used in multiple “always” block statements.

37. Resources & Schedule

38. Actual • Original • Revised Schedule

39. Schedule (cont.) • Actual • Original • Revised

40. Personnel Effort (as of April 26) Personnel Time Commitment *Completed hours ** Left on Co-op

41. Previous Team Resources

42. Financial Resources (w/ labor)

43. Closure Materials

44. Closure Materials – Project Evaluation

45. Closure Materials - Commercialization • Unlikely • Low Speed • Immobile • Inflexible • Cost Inefficient

46. Closure Materials - Additional Work • Consider building faster TX/RX • Consider using Manchester encoder/decoder • Allow for more advanced DUTs

47. Closure Materials - Lessons Learned • Circuit debugging techniques • FPGA implementation • Verilog • Timing considerations • Clock recovery • Circuit board layout

48. Closure Materials - Lessons Learned • What went well? • Teamwork • Record keeping • PCB • What did not go well? • Damaging parts • Inefficient trouble shooting • FPGA implementations

49. Closure Materials – Risk Management • Risk: Losing Team Member • Management: All members keep detailed & organized notes • Risk: Loss of Data • Management: All data will be backed up using team gmail account • Risk: Parts Malfunction • Management: Meticulous care in ESD procedures (using ESD bands)

50. Closing Materials • Closing Summary • Problem – Integrate clock recovery circuitry into current system • Solution • Use PLL for clock recovery • Modify FPGA program to incorporate new components
