  1. NCCS Network Roadmap Josh Lothian High Performance Computing OperationsNational Center for Computational Sciences

  2. NCCS network roadmap Summary: Hybrid Ethernet/Infiniband (IB) network to provide both high-speed wide-area connectivity and uber-speed local-area data movement • 2007 • Scaled Ethernet to meet wide-area needs and current day local-area data movement • Developed wire-speed, low-latency perimeter security to fully utilize 10Gb production and research WAN connections • Began IB LAN deployment • 2008 • Continue building out IB LAN infrastructure to satisfy the file system needs of the Baker system • Test Lustre on IB/WAN for possible deployment • Increase security on 10Gb WAN connections

  3. NCCS network roadmap summary Ethernet core scaled to match wide-area connectivity and archive Infiniband core scaled to match central file system and data transfer Lustre Baker Gateway Ethernet [O(10Gb/s)] Infiniband [O(100 Gb/s)] Jaguar High-Performance Storage System (HPSS)‏ Viz

  4. NCCS WAN overview Ciena CoreStream Ciena CoreDirector TeraGrid Juniper T320 DOE UltraScience/ NSF CHEETAH Force10 E600 Juniper T640 CCS Cisco 6509 NSTG CCS OC-192 to Internet 2 OC-192 to Esnet Internal 10Gb Link Internal 1Gb Link OC-192 to TeraGrid 2 x OC-192 to USN OC-192 to CHEETAH

  5. Jaguar NCCS Network 2007 Infiniband Ethernet Voltaire ISR2012 32 DDR 32 Spider30 20 DDR 48 48 Spider10 48 6-12 DDR 64 DDR 48 Cisco 7024D 48 Force10 E1200 Viz 48 32 DDR 32 4 HPSS 6-12 DDR 4 48 24 SDR Voltaire ISR9288 4 Devel 48 87 SDR 48 E2E 48 24-48 SDR 20

  6. NCCS IB network 2008 24 SDR Voltaire ISR9288 Devel 87 SDR Jaguar E2E 48-96 SDR (16-32 SDR/link)‏ 64 DDR 20 DDR 20 DDR Viz Spider10 32 DDR Voltaire ISR2012 50 DDR HPSS Spider30 50 DDR Cisco 7024D 32 DDR 300 DDR (50 DDR/link)‏ Baker Spider240

  7. 2007 milestones April 2007—Completed 10 G WAN upgrade June 2007—Completed VL/QOS testing November 2007—Complete fiber IB cable testing December 2007—IBoIP/SDP decision point

  8. 2008 milestones January—4x QDR testing February—Deploy flow-based perimeter security February—Complete 4X QDR testing March—Enable routing of XT3 HSN to production network June—Deploy redundant links between IB switches

  9. 4x Infiniband SDR OC-192 SONET Lustre End-to-End IB over WAN testing Ciena CD-CI (SNV)‏ • Placed 2 x Obsidiam Longbow devices between Voltaire 9024 and Voltaire 9288 • Provisioned loopback circuits of various lengths on the DOE UltraScience Network and ran test • RDMA Test Results: Local: 7.5 Gbps (Longbow to Longbow) ORNL ↔ ORNL (0.2 mile): 7.5 Gbps ORNL ↔ Chicago (1400 miles): 7.46 Gbps ORNL ↔ Seattle (6600 miles): 7.23 Gbps ORNL ↔ Sunnyvale (8600 miles): 7.2 Gbps DOE UltraScience Network Obsidian Longbow Obsidian Longbow Ciena CD-CI (ORNL)‏ Voltaire 9288 Voltaire 9024 20 81

  10. Contact Josh Lothian High Performance Computing Operations National Center for Computational Sciences (865) 241-5563 lothian@ornl.gov 10 Lothian_Networking_SC07
