  1. Computer Networks2002/2003 Network Architecture Johan Lukkien Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking

  2. Network Architecture • Elements • Nodes (hosts) • Interconnect (wires + repeaters/hubs) • Topology • Software • stack Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking

  3. Network architecture design • Generality: do not limit the scope unnecessarily • avoid use-specific designs • Robustness • node & link failure: local impact • limit effect of malfunctioning • e.g. domains • stability: left to itself the system converges to a defined & useful state • e.g. no global reboots • removing malfunctioning component is enough • fault resilience • detection: auto-diagnose • Byzantine behavior Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking

  4. Network architecture design • Scalability • design works for small and large networks • e.g., performance, exploitation of locality • extensions possible • Configurability • automatic (cf. stability), local configuration • tweakable: optimizable for certain conditions • Determinism • Migration & evolution Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking

  5. Architecture and distance home networks wireless networks long-distance wire-less Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking

  6. Local area networks • Typically, based on shared medium • broadcasting at layer 1 or layer 2 • Relatively small distance (few kilometers, at most) • Simple topologies • 10Base2 ethernet • Star: 10(0)BaseT • Token ring • ownership (token) passed around • owner puts packets on an removes them from the ring • owner puts token on the ring again • medium can be shared as well as point-2-point Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking

  7. Local Area Networks • High total bandwidth (the shared medium is fast) • Limited number of nodes • Low delay and error rate • Broadcast facility supported • i.e., part of the layer 2 service • All nodes equal • though some a bit more than others.... Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking

  8. Standardizing LANs: IEEE 802 • Working Groups and Study Groups • 802.1 Higher Layer LAN Protocols Working Group • Try to unify some issues for all LANs: management, addressing, bridges • 802.2Logical Link Control working Group • Issues in connecting to the network layer • 802.3 Ethernet Working Group • 802.4 Token bus Working Group • 802.5 Token ring Working Group • 802.11 Wireless LAN Working Group • 11a, 11b, 11e, 11g • 802.15 Wireless Personal Area Network (WPAN) Working Group • e.g. BlueTooth, ... • 802.16 Broadband Wireless Access Working Group • wireless MAN • 802.17 Resilient Packet Ring Working Group • 802.18 Radio Regulatory TAG • 802.19 Coexistence TAG • 802.20 Mobile Broadband Wireless Access (MBWA) Working Group • Link Security Executive Committee Study Group    Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking

  9. Metropolitan Area Networks • Three components • the access network for end-users • at the end-user you may find a LAN again... • connect to long-haul access points • specifically serve enterprises • e.g. file storage, disparate locations • Requirements • diverse access technology • xDSL, cable, telephony, fiber • diverse managerial domains • home/enterprise equipment, PTT, cable company, leased lines • locally: fast, reliable and fair • similar technologies as LAN, if possible Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking

  10. MANs: examples • Regular, special purpose networks • cable TV: just broadcasting and multiplexing of signals across the same physical medium • telephony: full duplex, point to point, connection oriented • electricity • General data communication • re-use existing infrastructure Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking

  11. Cable and telephony • Cable • need to add two-way communication • sharing of cable segments • Telephone • low bandwidth UTP Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking

  12. Wide Area Networks • Long-range geographical distribution • Separation of local net and subnet • different management • subnet: just transport – wires, switches, routers (no hosts!) • Path-oriented transport through the subnet • Note: subnet properties will affect WAN services Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking

  13. Routing (path oriented) Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking

  14. Internetworks • Connecting distinct networks • add a subnet: WAN • connect using multi-ported devices in an existing network • e.g. WAN-connected LANs • No clear terminology for Internetworks but • must have different technologies • and different managerial domains • Note: • technicaldistinctions (WAN, LAN, MAN...) are vanishing • managerial distinctions are most relevant Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking

  15. Wireless • Bandwidth sharing in cells • Two modes • point-to-point • base-station (star) • Overlap issues • Three distance scales • Wire-replacement • LAN technology • WAN technology Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking

  16. Wireless (cnt’d) • Wire-replacement • relatively low bandwidth : main focus on system interconnect (BlueTooth, wireless USB); P2P • cells roughly 10m • LAN technology • include link layer technology • ‘high’ bandwidth (i.e., only a factor of 10-100 slower than wired); e.g. HiperLan, IEEE 802.11 (‘WiFi’) • cells up to 100m • P2P or base-stations • WAN technology • use long-haul connections, e.g. GSM, GPRS, UMTS • cells up to 3 km • base-stations Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking

  17. Home networks • Special requirements • diverse hardware and interconnect • Information, Communication, Entertainment, Control • must work, reliable, foolproof • low cost • much streaming, rather than bursty traffic • high capacity • does not work well with ethernet • evolutionary path • equipment is there for years to stay • safe, secure, privacy protection Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking

  18. Connecting everything: the Internet Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking

  19. Exercises • Exercise 38 on page 84 Johan J. Lukkien, j.j.lukkien@tue.nl TU/e Computer Science, System Architecture and Networking
