  1. Chapter 15 Dynamic HTML: Filters and Transitions

  2. Outline • Introduction • Flip Filters: flipv and fliph • Transparency with the chroma Filter • Creating Image masks • Miscellaneous Image Filters: invert, gray and xray • Adding shadows to Text • Creating Gradients with alpha • Making Text glow • Creating Motion with blur • Using the wave Filter • blendTrans Transition

  3. Introduction • Better visual effects • Require IE 4.0+ • Filters • Cause changes that are persistent • Transitions • Temporary • Allow transfer from one page to another with pleasant visual effect next: filters

  4. Flip Filters: flipv and fliph • flipv and fliph filters mirror text or images vertically and horizontally, respectively

  5. <table> <tr> <td style = "filter: fliph">Text</td> <td>Text</td> </tr> <tr> <!-- More than one filter can be applied at once --> <td style = "filter: flipv fliph">Text</td> <td style = "filter: flipv">Text</td> </tr> </table>

  6. Transparency with the chroma Filter • chroma filter applies transparency effects dynamically • Without using a graphics editor to hard-code transparency into the image • e.g. <img src= "happy.gif" style="Filter: Chroma(color = yellow)"> • onchange • Fires when the value of a form changes

  7. chroma.html(1 of 3)

  8. chroma.html(2 of 3)

  9. Creating Image masks • Using the mask filter to create an effect: • Background is a solid color • Foreground is transparent to the image or color behind it • e.g. <span style="width: 357; height: 50; Filter: Mask(color=red)"> "Now, Stop That!."</span> • Renders the span element with the specified background color (red), and transparent foreground color

  10. mask.html(1 of 2)

  11. More Image Filters: invert, gray and xray • invert filter • Negative image effect • Dark areas become light and light areas become dark • gray filter • Grayscale image effect • All color is stripped from the image, only brightness data remains • xray filter • X-ray effect • Inversion of the grayscale effect

  12. <tr> <td>Normal</td> <td>Grayscale</td> </tr> <tr> <td><img src = "hc.jpg" alt = "normal scenic view" /></td> <td><img src = "hc.jpg" style = "filter: gray" alt = "gray scenic view"/> </td> </tr> <tr> <td>Xray</td> <td>Invert</td> </tr> <tr> <td><img src = "hc.jpg" style = "filter: xray" alt = "xray scenic view"/> </td> <td><img src = "hc.jpg" style = "filter: invert" alt = "inverted scenic view"/> </td> </tr>

  13. Adding shadows to Text • shadow filter • adds depth to text • Showing effect • Three-dimensional appearance

  14. shadow.html(1 of 2)

  15. shadow.html(2 of 2)

  16. Creating Gradients with alpha • alpha filter • Gradient effect • Gradual progression from starting color to target color • Properties: • opacity, finishopacity, style, startx, starty, finishx, finishy  • opacity and finishopacity • determine at what percent opacity the gradient starts and finishes • style • Uniform opacity (value 0) • Linear gradient (value 1) • Circular gradient (value 2) • Rectangular gradient (value 3)

  17. alpha.html(1 of 3)

  18. alpha.html(2 of 3)

  19. alpha.html(3 of 3)

  20. Making Text glow • glow filter adds an aura of color around text • e.g. <span style = " filter: glow( color = #FFFF00, strength = 10 )"> Glowing Text </span>

  21. Creating Motion with blur • blur filter creates an illusion of motion by blurring text or images in a certain direction • Add • Adds a copy of the original image over the blurred image • Direction • Determines in which direction the blur filter is applied • strength • Determines how strong the blurring effect is

  22. Creating Motion with blur • Examples: • <img src="sun.gif" style="filter: blur(add = 0, direction = 225, strength = 10)"> • <span style="width: 357; height: 50; filter: blur(add = 1, direction = 225, strength = 10)">"SunShine!"</span>

  23. Using the wave Filter • wave filter allows user to apply sine-wave distortions to text and images on Web pages • add • Adds a copy of the text or image underneath the filtered effect • freq • Determines the frequency of the wave applied • phase • Indicates the phase shift of the wave

  24. wave.html(1 of 2)

  25. wave.html(2 of 2)

  26. blendTrans Transition • Example of the blendTrans transition • Creates a smooth fade-in/fade-out effect

  27. blendtrans.html(1 of 2)

  28. Resources • http://www.fred.net/dhark/demos/css/css_filter_examples.html • http://msdn.microsoft.com/workshop/samples/author/dhtml/DXTidemo/DXTidemo.htm
